Power Amp(L) & Controls Part List - Phonic MAX 860 Service Manual

Ref.
R281
R416
R241.242.243.248.249.250
R240.247
R153
R272
R280.269
R215.218
CDS1.2
NTC401
SVR201
VR1.2
C404.405
C103.104.105.114.115.116
L401
RA1
D204.205.402.405.406
D214.215
D207-210.219.220
D211.212.216.217.221.222
D101.102
LED101.102.105.106
LED405
LED103.104
LED1
Q205.221
Q215.216.217
Q203.401
Q209
Q222.223.224
Q202.416
Q206
Q210.228
IC2.3.4.5
IC201
TMP1
SW1.2.3.4
PHONIC CORPORATION
Phonic Part No.
003-20071-602-0
003-22071-602-0
003-22093-602-0
006-10003-420-0
006-10073-420-0
006-27023-420-0
006-33023-420-0
006-47083-420-0
010-00001-010-0
011-10020-001-0
020-47138-000-6
023-50230-050-0
046-10414-060-0
050-33404-001-0
075-10082-100-0
076-02421-050-0
090-00007-020-0
090-00016-000-0
090-02004-000-0
090-02007-000-0
090-10000-000-0
100-00010-030-0
100-00040-000-0
100-00050-000-0
100-00070-030-0
120-00005-000-0
120-00008-600-0
120-00008-800-0
120-00009-500-0
121-00006-000-0
121-00006-100-0
121-00007-200-0
122-00002-600-0
160-00007-500-0
160-00021-900-0
210-10090-001-0
210-60001-000-0
MAX860/1500/2500 SERVICE MANUAL
Specification
CEMENT RES. 20 J 2W
CEMENT RES. 22 J 2W
CEMENT RES. 0.22 J 5W
MF RES. 100F 0.5W M
MF RES. 10F 0.5W M
MF RES.27K F 0.5W M
MF RES.33K F 0.5W M
MF RES. 4.7 F 0.5W M
CDS P873-G35-552 HAMAMATSU
THERMISTER NSA05C310-301
T/VR 470J T-085C-B470 0.5W
D.ROT/VR 5KA
M/C 0.1MF J 100V 5 T
M.M/C 0.33MF J 100V 10
INDUCTANCE 1UH K M
RELAY PCF-124D1M
DIODE IN4004 SILTEK T
DIODE 1N5404
DIODE 1N4935 T
DIODE FR602
B/DIODE PB154
LED BL-B5141 RED
LED 204YD YLW
LED BL-B2141 GRN
LED 204UBD D3 BLUE
TRAN MJE340 MOTOROLA
TRAN 2SC5200-O TOSHIBA
TRAN MJE802 MOTOROLA
TRAN 2SC4793-M TOSHIBA
TRAN 2SA1943-O TOSHIBA
TRAN MJE350 MOTOROLA
TRAN 2SA1837-M TOSHIBA
MOSFET IRFP260N IR
IC NJM 2068D JRC
IC NJM5534D JRC
TMP/SW US-602SXRFQC
SLD/SW SLD-43-10
Page 13
