Outside Assembly
1
(2) 8-32 x 3/4"
Flat Head
Combination Screws
3
2
(2) 8-32 x 3/4"
Flat Head
Combination Screws
Components
Directions
Quick Start Instructions
Before installation, disassemble the inside assembly, as shown above, by
removing the inside lever with the lever removal tool provided and separating
Installation Instructions
the support assembly from the inside escutcheon. Remove the battery cover
Door Marker
from the inside escutcheon by unscrewing the hex screw, using the Allen wrench
Outside Touchscreen Assembly
provided, and sliding the battery cover up and off (the hex screw does not come
completely out). The outside assembly remains assembled.
Inside Support Assembly
Refer to complete installation instructions for more information if changing hands
Inside Escutcheon Assembly:
or adjusting door thickness is required.
• Inside Support Assembly
1. Install latchbolt in door. Attach with two screws provided.
• Inside Escutcheon
Note: Be sure that bevel edge of bolt faces strike.
• Inside Lever Handle
2. Install strike on the door frame.
• Battery Cover
3. Insert outside assembly through door.
4 AA Alkaline Batteries
a. Guide motor cable (red and black wires) through 2-1/8" diameter hole.
Latchbolt
b. Guide touchscreen cable through 3/4" diameter upper hole.
Strike
4. Guide motor cable through rectangular hole on inside support assembly.
Allen Wrench 3/32" (2.5 mm)
5. Slide inside support assembly over outside assembly, lining up top and
Screw Pack (7 screws)
bottom screw guides with holes in door. Secure both assemblies with
2 Keys (If Cylinder Included)
(2) 10-32 x 2-1/2" flat head machine screws. Do not over-tighten.
6. Attach motor cable connector to the inside escutcheon PC board header
For Technical Assistance call Arrow:
marked "MOTOR."
1-800-221-6529.
P/N 80-9150-0064-010 Rev A
An ASSA ABLOY Group brand
Quickstart Guide
Inside Assembly
Touchscreen
Cable
3b
5
3a
4
Support Assembly Screws
Motor Cable
(2) 10-32 x 2-1/2" Flat
1
Head Machine Screws
Escutcheon Screw
(1) 10-32 x 3/4" Pan Head
With Star Washer Screw
9
12
10
11
7. Attach the touchscreen cable connector to the inside escutcheon PC board
header as illustrated.
8. Select EASY or ADVANCED Mode using the switch on the back of the PC board.
9. Slide inside escutcheon over inside support assembly.
CAUTION:
a. Position motor cable against inside support assembly. Avoid pinching wires
against the steel shank of the assembly.
b. "Z" fold touchscreen wire cable and lay against the back recessed area of
the escutcheon assembly. Position and bend wires to prevent binding when
installing the escutcheon over the support assembly.
10. Install and secure the 10-32 x 3/4" pan head screw through the center of the
battery housing into the barrel nut of the outside assembly.
11. Slide on inside lever and push in to attach.
12. Insert four (4) AA alkaline batteries. The lock responds, "Welcome to the
Arrow Digital World."
Note: Refer to other side of this Quickstart Guide for EASY Mode programming directions
prior to the completion of step 13. For more details and Advanced Mode programming,
please refer to the complete Programming Instructions.
13. Install battery cover and tighten hex head screw with Allen wrench
provided with lock.
HARDWARE INSTALLATION
Easy /
13
Advanced
8
Mode
EASY
EXT-PWR / REMOTE /
ADVANCED
EXT-PWR / REMOTE /
Touchscreen Cable
9b
Routing
Touchscreen
Cable
7
Connector
MOTOR
6
MOTOR
"Z" Fold
