WIRING SCHEMATIC
Infared
Transmitter
Yellow
Blue
Blue
Circuit
24 V.D.C.
Board
Black
251 Wedcor Avenue, Wabash IN 46992
e-mail: info@martinyale.com
web site: www.martinyale.com
Phone: 1-(260)563-0641 or Toll Free 1-(800)225-5644
Fax: 1-(260)563-4575
Manufactured in Taiwan
Infared
Receiver
Red
Black
24 V.D.C. Motor
Red
Black
Model
Desktop Letter
INSTRUCTION MANUAL
10/30/12
P6200
Folder
