DESIGN
BEFORE USING YOUR APPLIANCE, PLEASE READ THIS MANUAL, PAYING SPECIAL ATTENTION TO THE IMPORTANT
SAFETY INSTRUCTIONS LOCATED IN THE NEXT SEVERAL PAGES
The Use and Care Manual is divided into several sections:
• The Safety Section informs you about significant safety precautions when installing and operating your new appliance:
THIS IS A MUST READ SECTION OF THE MANUAL.
• Quick Start and Installation Section describes how to unpack the unit, what to save and what to discard, installation dimensions, gas and
electrical connections, and how to identify the primary parts of the product so you can better understand what's going on "under the hood".
• How to Use Your Product shows you how to get the most from your new cooktop
• The Care and Maintenance and Troubleshooting and Service Sections discuss how to keep your product in good operating condition, how to
identify what might be going wrong with the unit, and how to communicate your observations with authorized field service technicians.
• Warranty
© 2017 American Range
13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com
All Rights Reserved
INSTALLATION AND USE & CARE MANUAL FOR
VITESSE DROP-IN COOKTOPS
ABOUT THIS MANUAL
RETAIN THIS MANUAL FOR FUTURE REFERENCE
Installation Date: ______________________________
Installation Company: ___________________________
Installation Rep's Name: _________________________
Installers Address: _____________________________
Installer's Phone: ______________________________
* As specified on Range Nameplate
CLASS
FUNCTION
Advertisement
Table of Contents
Related Manuals for American Range VITESSE ARDCT-305
Summary of Contents for American Range VITESSE ARDCT-305
- Page 1 • Warranty RETAIN THIS MANUAL FOR FUTURE REFERENCE © 2017 American Range 13592 Desmond St., Pacoima, CA 91331 818.897.0808 tel 888.753.9898 toll free www.americanrange.com All Rights Reserved...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS FOR YOUR SAFETY! Do not store or use gasoline or other flammable vapors YOUR YOUR SAFETY or liquids in the vicinity of this or any other appliance. SAFETY WARNING! Improper installation, adjustment, alteration, service or maintenance WARNING can cause property damage, injury or death and will void warranty. - Page 3 • The required use of a GFI is normally related to the location of the receptacle to its proximity to significant sources of water or moisture. • American Range will not warranty any problems resulting from GFI outlets which are not installed properly or do not meet the requirements below.
- Page 4 IMPORTANT SAFETY INSTRUCTIONS WARNING IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOW EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING DAMAGE, PERSONAL INJURY OR DEATH INSTALLATION AND SERVICE MUST BE PERFORMED BY A CERTIFIED / LICENSED INSTALLER, SERVICE AGENCY OR THE GAS SUPPLIER »...
- Page 5 IMPORTANT SAFETY INSTRUCTIONS DANGER Do not store items of interest to children above or near the appliance. Children, as well as adults, must never be allowed to sit, stand or climb on any part of the appliance. Serious personal injury may occur. WARNING Always DISCONNECT the electrical plug from the wall outlet power source before servicing the unit.
- Page 6 IMPORTANT SAFETY INSTRUCTIONS CAUTION Purchase a kitchen fire extinguisher for your home and store it in close proximity to your appliance. Should an uncontrolled fire occur, never use water on grease fires. Never pick up a flaming pan. The oven door interior and exterior, especially the glass can get hot during operation.
- Page 7 IMPORTANT SAFETY INSTRUCTIONS To reduce the risk of appliance shifting, it must be secured to the countertop with properly installed WARNING hold-down brackets. CAUTION Purchase a kitchen fire extinguisher for your home and store it in close proximity to your appliance. Should an uncontrolled fire occur, never use water on grease fires.
-
Page 8: Installation
INSTALLATION The location selected for the countertop must meet the following A manual gas shut-off valve must be remotely installed and criteria. If any of these criteria are not met, select another location. easily accessible within the cabinet. The regulator inlet is for a 1/2 inch gas line. - Page 9 INSTALLATION SAMPLE RATING PLATE RATING PLATE - The information on the rating plate defines the model, serial number, gas type (natural or liquid propane), operating pressures and burner BTU ratings. Keep this information for future reference. It is essential for proper identification of the unit when requesting additional information or factory support.
-
Page 10: Installation Checklist
INSTALLATION CHECKLIST TO VALIDATE YOUR WARRANTY, YOU MUST MAIL, EMAIL OR FAX THIS FORM WITH A COPY OF YOUR RECEIPT TO: AMERICAN RANGE CUSTOMER SERVICE, 13592 DESMOND STREET, PACOIMA, CA 91331 EMAIL: info@americanrange.com FAX: 818.897.8839 This checklist has been developed to assure proper installation of your appliance. -
Page 11: Model And Parts Identification
MODEL AND PARTS IDENTIFICATION (Package Contents) PART DESCRIPTION PART NO. ARDCT-305 ARDCT-365 ARDCT-366 Knob, Blk/Chrome Dual R32090 Knob, Blk/Chrome Sgl R32091 Knob, Blk/Chrome Dual, Front R32092 Knob, Blk/Chrome, Sgl, Rear R32093 Knob, Blk/Chrome, Sgl, Rear R32094 GRATE, ARDCT Grate, Side (not shown) R17593 Grate, Left (not shown) R17596... - Page 12 BURNER AND KNOB IDENTIFICATION Single Burners (4) ARDCT-305 Single 1. Dual Burner Knob - with Simmer (1) Burner 2. Single Burner Knobs (4) Knobs 3. Grates (2) Dual Burner Knob Single Burner Knobs ARDCT305 Dual Burner (1) Single Burners (3) ARDCT-365 1.
-
Page 13: Operating Your Cooktop
OPERATING YOUR COOKTOP BEFORE USING YOUR NEW COOKTOP • Before using the cooktop for the first time, wash the outside area with soap and water to remove any shipping & factory residue. • The burner grates are designed in sections and are easy to remove and clean. They are made of cast iron with a porcelain coating and will remain hot after the burner is turned-off creating a residual heat for continued cooking. - Page 14 OPERATING YOUR COOKTOP AUTO RE-IGNITION The surface burners are equipped with a special ignition and re-ignition system that senses the presence of flame and re-ignites the burner should the flame disappear while gas is still flowing to the burner. Strong drafts, spills and general grime influence the operation of the automatic re-ignition system – A CLEAN SYSTEM WILL FUNCTION BETTER THAN A DIRTY SYSTEM.
-
Page 15: Cleaning The Cooktop
CLEANING THE COOKTOP The cooktop is constructed from brushed stainless steel with brass burner heads. The burner cap, grates and optional wok ring are steel coated with porcelain. To help protect your cooktop from scratches, do not use abbrasive cleansers, rough towels, steel CAUTION wool or scrubbers to clean your cooktop. -
Page 16: Troubleshooting
Should the equipment require service during the standard warranty period, the receipt proving certified installation must be made available to American Range for verification. If installation was not performed by a certified/licensed contractor be prepared to submit a major credit card for payment for proper installation prior to service.
