LTE3301 Series
LTE Indoor Gateway
Version 1.00
Edition 1, 03/2015
Quick Start Guide
Default Login Details
LAN IP Address
User Name
Password
www.zyxel.com
http://192.168.1.1
admin
1234
Copyright © 2015 ZyXEL Communications Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LTE3301 Series and is the answer not in the manual?

Questions and answers

Related Manuals for ZyXEL Communications LTE3301 Series

Summary of Contents for ZyXEL Communications LTE3301 Series

  • Page 1 LTE3301 Series LTE Indoor Gateway Version 1.00 Edition 1, 03/2015 Quick Start Guide Default Login Details LAN IP Address http://192.168.1.1 User Name admin Password 1234 www.zyxel.com Copyright © 2015 ZyXEL Communications Corporation...
  • Page 2 Panels POWER ANTENNA ANTENNA RESET ON/OFF CONNECTOR2 CONNECTOR1 BUTTON BUTTON PORTS 1-4 WLAN USIM/SIM ON/OFF CARD SLOT BUTTON DC POWER IN WPS ON/OFF BUTTON...
  • Page 3 Requirements Make sure you have the following before you start: • INTERNET ACCESS: You need a SIM card from an LTE ISP (Internet Service Provider). You may also need a PIN code, APN, or IP address to use the SIM card. •...

  • Page 4: Hardware Connections

    Hardware Connections Make sure the LTE3301 is off and follow the steps listed below for the hardware connections. 1. Install the antennas. 2. SIM CARD: Insert your SIM card to the SIM card slot for the LTE network access. 3. LAN: Use an Ethernet cable to connect a computer to one of these ports for initial configuration and/or Internet access.
  • Page 5 Look at the LEDs (lights) on the front panel. LTE SIGNAL WLAN/ INTERNET POWER STRENGTH • The POWER light is green when the LTE3301 is receiving power and functioning properly. It blinks when the LTE3301 is in the process of starting up. •...
  • Page 6 Set Up a Wireless Connection The LTE3301’s wireless LAN is enabled by default. Use the wireless SSID (network name) and encryption key on the back panel to manually add a wireless client to the network. Refer to the User’s Guide if you wish to use WPS (Wi-Fi Protected Setup) instead.
  • Page 7 2. Select the LTE3301’s SSID name and click Connect (A). The SSID “SecureWirelessNetwork” is given here as an example. 3. When prompted for a password, enter the (WPA2-PSK) encryption key from the back panel of the LTE3301 and click Connect. 4.
  • Page 8  If you cannot connect wirelessly to the LTE3301, check that you selected the correct SSID and entered the correct security key. Make sure the LTE3301’s WLAN is enabled and the WLAN/WPS LED is on.

  • Page 9: Connect To The Internet

    Connect to the Internet 1. Open your browser and go to http://192.168.1.1. • If your service provider’s LTE login page appears instead of your default Home page then all you need to do is enter the login information that you were given and follow the on- screen instructions.
  • Page 10 3. Change a new password. 4. If the INTERNET light is off, manually configure the Internet connection. Click Configuration > Network > WAN and then the Modify icon. The APN identifies the LTE network to which your LTE Modem connects. 5.
  • Page 11 6. Wait for the INTERNET light to turn on and then try browsing to a website. • For more information see the WAN section in the User’s Guide. • To configure wireless access, go to Configuration > Network > Wireless LAN. •...
  • Page 12 Using the Wizard You can use the wizard to quickly configure your login password, time zone, the WAN and WLAN settings. 1. Click the Wizard icon at the top-right corner of the screen. 2. The Setup Wizard screen displays. Click Next. 3.
  • Page 13 4. Enter the APN name which your ISP gave you and select the country where the LTE3301 is currently located and your ISP. Click Next. 5. Configure the wireless LAN settings and then click Next.
  • Page 14 For more information, please refer to the User’s Guide at the www.zyxel.com download library. Network standby power consumption < 12W Off mode power consumption < 0.5W EU Importer: ZyXEL Communication A/S, Generatorvej 8D, 2860 Søborg, Denmark. http://www.zyxel.dk US Importer: ZyXEL Communications, Inc | 1130 North Miller Street Anaheim, CA 92806-2001 | http:// www.us.zyxel.com...
