- Page 1 MULTI ELEC Electric Boilers TECHNICAL MANUAL PO Box 11 Ashton Under Lyne OL6 7TR +44. (0) 161 621 5960 Fax +44. (0) 161 621 5966 info@atlantic2000.co.uk www.atlanticboilers.com...
-
Page 3: Table Of Contents
CONTENTS DESCRIPTION……… ………………………………...……………………………………1 …. PERFORMANCE……………………………………………………………………………… SCHEMATIC……………………………………………………………………………… … …. CONTROL PANEL DIAGRAM COMMAND ELECTRIC DIAGRAM……………… ……………….……………………5 ….. POWER ELECTRIC DIAGRAM…………………….……………………………….……… FUSES………………………………………………………………………………………….. CONTROL PANEL + REGULATION……………………………………………………….. INSTALLATION……………………………………………………………………………….10 STARTING THE BOILER…… ……..……………………….……. ……………………………………… SERVICING…………………………………………………………………………………….11 THE COMMISSIONING OF THE MULTI-ELEC……………………………………………27 THE GUARANTEE ON THE MULTI-ELEC……………………………………………….32... -
Page 4: Description
DESCRIPTION The “Multi Elec” electric boilers have been designed for any heating system (maximum working pressure 4 Bars) They are Class 1 boilers that required earth connections IP21 / IK 08 BOILER CONTROL PANEL - 1 waterproof control panel mounted on the boiler including:... -
Page 5: Performance
PERFORMANCE, DIMENSIONS & CONNECTIONS Pressure No.of kW per Boiler Boiler Overall drop OUTPUT elements element dimensions Volume Flow rate l/s Ø dimensions max flow weight rate kPA Foot Height Litres Maxi H x L x P print 1200x600x3 520 1330 12.0 12.0 1400x800x3... - Page 6 OPTIONAL ACCESSORIES SHUNT PUMP with contact relay and run/lock-out lamps MOUNTING PACK with automatic air release, water flow switch, drain ball valve, safety relief valve and temperature & pressure relief valve Automatic air release Two relief valves Water flow switches Drain ball valve...
-
Page 7: Schematic
SCHEMATIC 1) Conventional Pipework 2) Weather compensated Pipework 3) Weather compensated pipework Radiators or under-floor heating... - Page 8 4) Heating and hot water pipework Radiators expansion pressure relief auto air vessel valve vent pressure & isolating ball valve temperature relief pump valve Fill loop non return 3 port valve valve NB: Boiler pump flow should be 5% superior to the sum of heating and DHW primary pump...
-
Page 9: Control Panel Diagram
CONTROL PANEL DIAGRAM MAINS POWER 400V, THREE PHASES + EARTH (NO NEUTRAL Ka1 Terminal Fuses MAIN SWITCH EARTH COPPER PLATE FLEXIBLE TERMINAL ISOLATED COPPER LINKS (from 216 kW) - Page 10 VIEW OF THE CONTROL PANEL...
-
Page 11: Command Electric Diagram 5
COMMAND ELECTRIC DIAGRAM 415 Volts 3Phases supply Sensor Digital 415/240 Regulation Power Lockout Lockout Fan V from 216 kW F1-F2-F3 and Transfowill vary according to boiler output Earth : Green/Yellow 4mm² S1: Power Switch Green Wires 0 to 6 : Red 1mm² I 1: Controller Switch Wire 9 : Black 1mm²... - Page 12 BOILER ELECTRICAL OUTPUT Output per step control Output Step 1 Step 2 Step 3 90 kW 120 kW 150 kW 180 kW 210 kW 245 kW 280 kW 315 kW 350 kW 385 kW 420 kW 455 kW 490 kW 525 kW 560 kW 595 kW...
- Page 13 BOILER ELECTRICAL PROTECTION Selection of fuses Fuses F1, F2 & F3 - cartridge size 8.5 x 31.5 90kW to 280kW F1 - 1A type aM F2 - 1A type gG F3 - 0.5A type gG 315kW to 630kW F1 - 1A type aM F2 - 2A type gG F3 - 0.5A type gG Fuses F4, F5 &...
-
Page 14: Control Panel + Regulation
CONTROL PANEL + REGULATION CONTROL PANEL Power Lockout REGULATION FRONT BACK Boiler temperature 240V White Stage3 Point Sensor Stage1 Stages 1 = Stage1 Stage2 2 =Stage2 5 =Stage3 Factory Settings (Heating Circuit) Set Point Temperature : 80°C Stage 1 77°C Stage 2 74°C Stage 3... - Page 15 Increase the set point temperature: Press the key Decrease the set point temperature: Press the key Never press the PGM and EXIT keys For other settings, please contact Atlantic. Information on the control panel Identification number plate on the control panel The maximum acceptable current is Icw = 23 kA.
-
Page 16: Installation
INSTALLATION The “multi-elec” electric boiler should be installed in a louvered plantroom in order to ensure an ambient temperature below 30ºC and relative humidity between 30 and 80%. The boiler should not be used in a corrosive atmosphere or in an external position. Adequate access should be left around the boiler in order to carry out maintenance. -
Page 17: Starting The Boiler
STARTING THE BOILER Remove the power fuses Check that the boiler is filled with water Check that the immersion heaters are sound. If isolation is below 2MΏ, please find the reason and remdy it. Turn the power on using the main switch and the key switch ... -
Page 18: Servicing
SERVICING Loss of water velocity through the boiler can lead to temperature rise Consider a sediment vessel on the return to capture sediment deposit Blocking immersion heaters irrigation can destroy them NOTE : The immersion heaters can be destroyed by blockage of the water flow It is essential that a periodical cleaning is carried out on the main heat exchanger and the sensors. - Page 19 The following check list should be satisfied before the commissioning takes place. To arrange the commissioning Atlantic should be given a minimum of ten days notice of the date and time required.
- Page 20 5) When a replacement item is supplied for a defective item, the defective item must be returned to ACM Atlantic at their registered office within 6 weeks of the date of notification of the defect carefully labeled with registration number of the boiler and the name and the order reference of the purchaser of the boiler.
