Sandwich/Salad Prep Table
Under-counter Freezer
Worktop Freezer
Service, Installation and Care Manual
Please read this manual completely before attempting to install or operate this equipment.
Notify carrier of damage! Inspect all components immediately. See page 2.
IMPORTANT INFORMATION
READ BEFORE USE
PLEASE SAVE THESE INSTRUCTIONS
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Saturn PUC28F
Summary of Contents for Saturn PUC28F
- Page 1 Sandwich/Salad Prep Table Under-counter Freezer Worktop Freezer Service, Installation and Care Manual Please read this manual completely before attempting to install or operate this equipment. Notify carrier of damage! Inspect all components immediately. See page 2. IMPORTANT INFORMATION READ BEFORE USE PLEASE SAVE THESE INSTRUCTIONS...
-
Page 2: Table Of Contents
Service and Installation Manual CONTENTS RECEIVING & INSPECTING EQUIPMENT………………………………………..…………………2 SPECIFICATIONS…………………………………………………….……………………….………3 INSTALLATION………………………………………………………………………….…………..….4 OPERATION………..……………………………………………………………………..……………5 MAINTENANCE……………………………………………………………………….……………….7 WIRING DIAGRAM…………………………………………………………………………………9 All rights reserved. Reproduction without written permission is prohibited. SERIAL NUMBER INFORMATION The serial numbers of all self-contained refrigerators and freezers is located inside the unit on the left hand panel near the top. -
Page 3: Specifications
Service and Installation Manual SPECIFICATION STORAGE SHELF SHIP CAPACITY CAPACITY CHARGE WEIGHT NEMA MODEL# V/Hz/Ph AMPS Cu-ft PLUG Sq-ft PUC28F 115/60/1 3500 12.3 5-15P... -
Page 4: Installation
Service and Installation Manual INSTALLATION Location Units represented in this manual are intended for indoor use only. Be sure the location chosen has a floor strong enough to support the total weight of the cabinet and contents. A fully loaded unit can weigh as much as 1500 pounds. -
Page 5: Operation
Service and Installation Manual OPERATION Do not throw items into the storage area. Failure to heed these recommendations could result in damage to the interior of the cabinet. Refrigerated cabinets Temperature range for the internal cabinets is 28° F to 50° F for all food prep, undercounter and worktop refrigerator units;... - Page 6 Service and Installation Manual 1.1 Function of LEDS 2. MAIN FUNCTIONS 2.1 HOW TO VIEW THE SET POINT 1. Push and immediately release the SET key. The display will show the set point value. 2. Push and immediately release the SET key or wait for 5 seconds to display the sensor value again.
-
Page 7: Maintenance
Service and Installation Manual MAINTENANCE The power switch must be turned to OFF and the unit disconnected from the power source whenever performing service, maintenance functions or cleaning the refrigerated area. Freezer The interior and exterior can be cleaned using soap and warm water. If this is not sufficient, try ammonia and water or a nonabrasive liquid cleaner. - Page 8 Service and Installation Manual MAINTENANCE Cleaning solutions need to be alkaline based or non-chloride cleaners. Any cleaner containing chlorides will damage the protective film of the stainless steel. Chlorides are also commonly found in hard water, salts, and household and industrial cleaners. If cleaners containing chlorides are used, be sure to rinse repeatedly and dry thoroughly upon completion.
-
Page 9: Wiring Diagram
Service and Installation Manual WIRING DIAGRAM MODEL: PUC28F... - Page 10 Service and Installation Manual WIRING DIAGRAM MODEL: PUC28F...
