Installation Guide Of Kia K5
Navigation& Entertainment System
Navigation& Entertainment System
Navigation& Entertainment System
Navigation& Entertainment System
Installation Flow
Installation Flow
Installation Flow
Installation Flow
(V1.0)
(V1.0)
(V1.0)
(V1.0)
01
Original car CD panel． ． ． ．
03
Use insulating cutter to pry the above of the
decoration panel.
05
To loose the right bottom of the panel.
07
Take out the 8 screws of the panel． ． ． ．
02
Use insulating cutter to loose right side of the
decoration panel.
04
Use insulating cutter to pry the upright of the
decoration panel． ． ． ．
06
Take out the decoration panel． ． ． ．
08
Use insulating to loose upper side of the panel.
