Page 1: User Manual
ElektraLite LED eyeBall Warm White USER MANUAL ElektraLite (a division of Group One), 70, Sea Lane, Farmingdale, NY11735, U.S.A. T. +1 (631)-396-0184. F. +1 (631)-396-0190 WWW.MYELEKTRALITE.COM... -
Page 2: Safety Instructions
ElektraLite WW be grounded. So under no circumstances break off the ground pin on the Edison plug or use the fixture where a ground is not present. A ground pin, like the fuse for the ElektraLite WW is there for safety. -
Page 3: General Guidelines
Do not clamp the safety cable to the U bracket or clamp. That is not a secondary safety point. A secondary safety point is any point that will adequately hold the ElektraLite WW if the "C" clamp or half cheesboro fails. Then the safety cable would be the backup and stop the fixture from falling to the ground. -
Page 4: Dmx-512 Control Connection
The DMX terminator is simply a 5 pin XLR plug (male) with a 120 Ω resistor connected between pins 2 and 3. It is then plugged into the output XLR socket of the last ElektraLite WW or other dmx device in the chain. Please see illustration below. - Page 5 6. Menus in the fixture. Root Menu Sub Menu 1 Sub Menu 2 STAT (STATIC LOOK) 000-255 STROBE 000-255 AUTO (AUTOMATIC PROGRAMS) EFFECT 1 (inbuilt program 1) EFFECT 2 (inbuilt program 2) EFFECT 3 (inbuilt program 3) DMX 512 SLAVE ADDRESS ASSIGN DMX CHANNEL 001-512...
-
Page 6: Auto Programs
Do not press MENU as this will get you out to the Root directory and out of the static look. 8. Auto Programs. In Auto Program there are three programs (or shows) in the ElektraLite WW are Effect 1, Effect 2 and Effect 3. Chose the one best suit for the venue. -
Page 7: Key Lock
11. Personalities. There are three different choices on how the fixture will operate. What these "Personalities" do in terms of their channel assignments is detailed in the tables on page 7. To change a Personality use the Menu button to get to PERS Press Enter then using the ↑... - Page 8 15. DMX Channel Assignments for Personalities. STAG1： 0-255 WW output…dimming 0-50 Linear dimmer speed（DIM=0） 51-100 Non-linear dimmer speed 1（DIM=1） 101-150 Non-linear dimmer speed 2（DIM=2） 151-200 Non-linear dimmer speed 3（DIM=3） 201-255 Non-linear dimmer speed 4（DIM=4） STAG2: DMX data Function 0-255 WW output…..dimming STROBE NO FUNCTION 10-49...
-
Page 9: Cleaning And Maintenance
The clear front plastic cover for the lenses should be cleaned so the light output is maintained. With the ElektraLite WW turned off, use only a moist lint-free cloth, and clean the plastic cover. Never use alcohol or solvents to clean the fixture. Never spray anything onto the fixture at the front or in any place on the fixture. -
Page 10: Other Products
18. Other Products. For other great products that are manufactured under the ElektraLite product line, please go to the website at www.myElektraLite.com A preview of the products include:- ElektraLite ML602... - Page 11 ElektraLite LightStream ElektraLite DazerIP65 in white...
