INTRODUCTION
This manual provides detailed procedures to install your new ARISTEL DV-96
Digital Key Telephone System.
Please read this entire section before
proceeding with the actual installation.
The National Electrical Code (NEC) requires the local telephone company
(Telecom) to provide the primary protection devices for the telephone lines
terminating at the customer's site. Make sure that a primary protection device
has indeed been installed by the Telecom. If no such device is present, notify
the Telecom before installing your Aristel system.
Arista Systems Corporation
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the DV-96 and is the answer not in the manual?

Questions and answers

Related Manuals for Aristel DV-96

Summary of Contents for Aristel DV-96

  • Page 1 DV-96 System Installation Manual INTRODUCTION This manual provides detailed procedures to install your new ARISTEL DV-96 Digital Key Telephone System. Please read this entire section before proceeding with the actual installation. The National Electrical Code (NEC) requires the local telephone company (Telecom) to provide the primary protection devices for the telephone lines terminating at the customer’s site.

  • Page 2: General Description

    PCBs. All functions can be programmed to Macro keys, enabling complex functions to covert into single-keypad operation. This is an excellent option for the new digital age; Aristel DV-38 is the best partner to lead you into the diverse broadband world of telecommunications...
  • Page 3 DV-96 System Installation Manual Aristel DV-96 Digital Intelligent Key Phone System Multiple Processors. Time Division Multiplexing. Unique ARISTEL ASIC Chip “A-SERIES” Arista Systems Corporation...

  • Page 4: System Configuration

    DV-96 System Installation Manual SYSTEM CONFIGURATION System Capacity and Specifications Expandable DV-96 Basic Capacity Max. Capacity Capacity POTS CO Line ISDN (BRI) 0 ~ 8 ISDN (PRI) Key phone Digital 16/0 48/0 64/0 Single Line Phone Auto Attendant Voice Voice Mail...

  • Page 5: Key Telephone Specification

    DV-96 System Installation Manual KEY TELEPHONE SPECIFICATION DIGITAL KEY TELEPHONE Key Phone Model DKP30 DKP31 DKP32 DKP33 DKP50 DKP51 DKP52 DKP53 DSS Function Key 12 Keys 12 Keys 12 Keys 12 Keys 25 Keys 25 Keys 25 Keys 25 Keys 2 * 16 digits LCD …...

  • Page 6: System Model Description

    DV-96 System Installation Manual SYSTEM MODEL DESCRIPTION Model Description Remark Main Service Unit - Consisting of Metal Cabinet + D2MBUB + D2-416DK Standard Shipment D2PWUA + D1TKUC + D2DLUA Main Service Unit - Consisting of Metal Cabinet + D2MBUB +...
  • Page 7 DV-96 System Installation Manual Expansion Flash Memory - Software control with 4 hours store D1VMFA Optional Card WP5007 25-Pair Amphenol Cable – (for Station Wiring Connection) Optional Required ENVIROMENTAL REQUIREMENT Only authorized personnel should install the Key System Unit (KSU) at a clean, dry and secure location accessible.

  • Page 8: Equipment Requirement

    DV-96 System Installation Manual EQUIPMENT REQUIREMENT Prior to installation, carefully inspect all packages for evidence of damage. Compare the equipment received against equipment ordered to ensure that ALL components have been received. The following materials are required (not provided) for installation: Exterior grade plywood backs board for the KSU.

  • Page 9: Power Supply And Ksu Installation

    DV-96 System Installation Manual POWER SUPPLY AND KSU INSTALLATION Attach the plywood backboard to the selected location with the appropriate fasteners. A surge protector should be installed at the dedicated AC outlet. Connect Male-Tail, and connect the plug to each station board for station wiring;...

  • Page 10: Pcb And Cabinet Layout

    DV-96 System Installation Manual PCB AND CABINET LAYOUT SYSTEM INTER-CIRCUIT LAYOUT D2PWUA D2DLUA D2SLUA D1SLCB D2HYUA D2MBUB D1VSCA D1VMCA D1TKUC D1RPCA D1DTKA D1DTKB D1RSCC D1MFCA AC Power Inlet. AC Power Switch. Power Indicator¡ ] LED Type¡ ^ . DC Power Switch.
  • Page 11 DV-96 System Installation Manual D2MBUB (Mother Board Unit) Product: DV-96 Mother Board Unit Item: D2MBUB Size: 310 mm x 130 mm Function: 1. The motherboard control entire system functions and audio switching. 2. Motherboard supports External Music Source Input Terminal.
  • Page 12 10. SLC: 13P*2 Wafer Connector for D1SLCB connection. 11. DTA1~4: 30P*2 Header Connector for D2SLUA, D2HYUA and D2DLUA connection. 12. ASIC: Aristel proprietary ASIC. 13. LCD: Additional LCD connector for engineering system maintenance. 14. JP1: 3Pins Wafer Jumper to turn ON/OFF Li battery power.
  • Page 13 DV-96 System Installation Manual D2PWUA (POWER BOARD UNIT) Product: DV-96 POWER UNIT Item: D2PWUA Size: 270 mm x 95 mm Function: 1. To supply entire system power. 2. The input AC Voltage ranges are AC110V~240V 3. Support 24V Battery Charger for external Back-up Battery.
  • Page 14 Function: Support Polarity Reverse detection for each CO lines. A maximum of 4 D1TKUC boards can be installed onto the DV-96 main frame. Support either D1CIDC (FSK/DTMF CLI interface) or D1MDCA (Meter Pulse Detection Card) connections on each CO line.
  • Page 15 DV-96 System Installation Manual D1DTKA (ISDN BRI Trunk Unit) Product: DV-96 ISDN TRUNK UNIT Item: D1DTKA (ISDN BRI CARD) Size: 162 mm x 122 mm Function Supports 2 lines of 2B+D interface which support 4 voice channels. The system provides 4 slots of ISDN Trunk Unit connector. (Maximum expansion capability: 8 lines for 2B+D or 16 lines for Voice channel.)
  • Page 16 DV-96 System Installation Manual Line status indication, red” on” mean line fault. Green “ on” mean off hook. JP1: Short: line termination enable (default). N/C: line termination disable. JP2: Short: line termination enable (default). N/C: line termination disable. JP3: please see below table for reference.
  • Page 17 DV-96 System Installation Manual D1DTKB (ISDN PRI Trunk Unit) Product: DV-96 ISDN TRUNK UNIT Item: D1DTKB (ISDN PRI CARD) Size: 162 mm x 122 mm Function 1. Supports 1 lines of 30B+D interface, which support 30 voice channels. 2. Maximum one card install per system, when install D1DTKB; system cannot support D1DTKA as same time.
  • Page 18 Size: 162 mm x 155 mm Function: 1. Support 16 ports of digital key phone interface. 2. Totally 4 pieces of D1DLUA could be installed onto the DV-96 main frame (64 Extensions Maximum) 3. D2DLUA is fully compatible with DV-Series Key Telephones. Ex: DKP-30, DKP-31, DKP-32 DKP-33, DKP-50, DKP-51, DKP-52, DKP-53.
  • Page 19 Size: 195 mm x 69 mm Function: 1. D2SLUA provides 16 SLT Station Ports. 2. Totally 4 pieces of D2SLUA could be installed onto the DV-96 main frame. (64 SLT Maximum). The Installation Site of D2SLUA 1. Flat cable connector to D2MBUB STA1~4 slots.
  • Page 20 Function: 1. D2HYUA provides 4 Digital Key Station ports plus 12 SLT Stations Ports. 2. Totally 4 pieces of D2HYUA could be installed onto the DV-96 main frame 3. Digital Key Station ports fully compatible with DV-Series Key Telephones. Ex: DKP-30, DKP-31, DKP-32 DKP-33, DKP-50, DKP-51, DKP-52, DKP-53.
  • Page 21 DV-96 System Installation Manual 1. Flat cable connector to D2MBUB STA1~4 slots. 2. Centronic connector for WP5007 cable wiring. 3. Reset button to reset the D2HYUA on-board micro-controller. 4. LED (Red) for power indication and on-board micro-controller activity. Arista Systems Corporation...
  • Page 22 DV-96 System Installation Manual D1SLCB (Single Line Station Card, 2 SLT Station Ports) Product: DV-96 SINGLE LINE STATION CARD Item: D1SLCB Size: 195 mm x 69 mm Function: 1. D1SLCB provides 2 SLT Stations Ports. It is installed on a special socket instead of occupying Extension ports socket.
  • Page 23 Item: D1RSCA Size: 51.5 mm x 69 mm Function: 1. 2400/9600 bps Serial interfaces are used for SMDR and Aristel’s WinSM applications. The Installation Site of D1RSCC CN: 10-Pins Male Wafer Connector. Connect to the position of Point 9 in Figure 1 by the special DB9 Cable [FD-10-9-400, Male Type] for the connection of either PC COM Port or Serial Printer.
  • Page 24 DV-96 System Installation Manual Transmit (SYS¡ ö Serial Printer) 3.2 JP3: 3-Pins Jumper Selection. Receive Transmit 2.2 JP2: 3-Pins Jumper Selection. PC COM Port (SYS¡ ö PC) Transmit (SYS¡ ÷ Serial Printer) ¥ Ò ¡ B JP1: 3-Pins Jumper Selection.
  • Page 25 DV-96 System Installation Manual CAUTION! A. If the system’s RS232 is connected to PC, please make ALL jumpers to be [PIN1 + PIN2] SHORTED. B. If the system’s RS232 is connected to Serial Printer, please make ALL jumpers to be [PIN2 + PIN3] SHORTED.
  • Page 26 DV-96 System Installation Manual D1VSCA/B (Voice Service Card, 2 Voice Channel) Product: DV-38 D1VSCA/D1VSCB Model: D1VSCA/D1VSCB Size: 138 mm x 69 mm Function: 1. D1VSCA is consisting of 2 voice service channels which provide 60 seconds nonvolatile memory space in each.
  • Page 27 Relay Switch, 2 Ports of Multifunction Sensor interface, 2 ports of External Paging interface. Multi function card is an important interface of communicating others related products in our DV-96 .ex, Sensor Control, Relay Control, External Paging, Fire Alarm, and Emergency Alarm. . Etc The Installation Site of D1MFCA...
  • Page 28 DV-96 System Installation Manual SEN2: Terminal-Block Connector for the 2 Sensor Connection. SEN2: Terminal-Block Connector for the 1 Sensor Connection. External Page: Terminal-Block Connector for External Page Connection. DOOR2: Terminal –Block Connector for the 2 Door Phone Connection. DOOR1: Terminal –Block Connector for the 1 Door Phone Connection.
  • Page 29 DV-96 System Installation Manual D1MDCA (Metering Pulse Card) Product: DV-96 Metering Pulse CARD Item: D1MDCA Size: 91 mm x 21 mm Function: Provide signal channel of the POTS CO line 12/16KHz Metering Pulse detection. The Installation Site of D1MDCA CN2: To connect to the position [CH1~4B] where upon the D1TKUC.
  • Page 30 DV-96 System Installation Manual D1CIDC (FSK/DTMF CLI Interface) Product: DV-96 CALLER ID CARD Item: D1CIDC Size: 91 mm x 21 mm Function: Provide signal channel of the POTS CO line DTMF/FSK Calling Line Identification detection. The Installation Site of D1CIDC...
  • Page 31 Item: D1RPCA Size: 70.5 mm x 69 mm Function: 1. Standard 2400bps Modem. 2. Cooperate with Aristel’s Win-SM for system remote programming and Maintenance. The Installation Site of D1RPCA 1. RPC: 26-Pin Connector to connect to [RPC] position where upon the D2MBUB.
  • Page 32 DV-96 System Installation Manual D1VMCA (Voice Mail Card) Product: DV-96 VOICE MAIL CARD Item: D1VMCA Dimension: 225 mm x 124 mm Function: 1. Support 2 basic Voice mail on board and could be expanded up to 4 ports by D1VMEA.
  • Page 33 DV-96 System Installation Manual D1VMEA (Voice Mail Expansion Card) Product: DV-96 Voice Mail Expansion Card Item: D1VMEA Dimension: 41 mm x 41 mm Function: 1. Signal channel of Voice Mail for port expansion where upon the designated socket. 2. Basic 2 channels on one board, Maximum capability can be expanded to 4 channels.
  • Page 34 DV-96 System Installation Manual D1VMFA (Expansion Flash Memory) Product: DV-96 Expansion Flash Memory Item: D1VMFA Size: 30 mm x 25 mm Function: 1. Each Expansion Flash Memory Card provides 8 hours memory space. 6 hours basic capacity on the D1VMCA, 3 expansion flash memory cards could expand the memory up to 30 hours Maximum (6+24=30 hours).

  • Page 35: Installation And Wiring

    DV-96 System Installation Manual INSTALLATION AND WIRING AC POWER AND DC BATTERY BACK-UP INSTALLATION Installation Figure 18. AC Power and DC Battery Back-Up Arista Systems Corporation...
  • Page 36 DV-96 System Installation Manual NOTE. AC Power input to the system can be either 115VAC or 230VAC. The system can detect the input voltage automatically. CAUTION There are Hazardous voltages present in the Power Supply. We recommend that the Power be...
  • Page 37 DV-96 System Installation Manual D2MBUB JUMPER SETTING Please refer Figure 2 the D2MBUB plot for detail positions. 1. Li Battery installation and jumper setting. 1.1 [JP1] – Li Battery power ON/OFF. CAUTION Danger of explosion if battery is incorrectly replaced.
  • Page 38 DV-96 System Installation Manual POTS CO LINE WIRING FOR D1TKUC PFR1+PFT1 PFR1 ===> PF Tel. 1 PFT1 FAX-R+ FAX-T FAX-R ===> FAX Machine FAX-T COR4+COT4 COR4 ===> CO Line 4 COT4 1. There are 4 CO Line Ports that can be wired on D1TKUC, each CO Line Port containing 2-wires.
  • Page 39 DV-96 System Installation Manual D1CIDC and D1MDCA INSTALLATION D1CIDC / D1MDCA D1TKUC CH4A CH4B 1-TKUB CH3B CH3A CH2B CH2A CH1B CH1A Figure 20. Metering Pulse Detection Card Installation 1. There is a maximum of 4 D1CIDC cards that can be installed in each D1TKUB, one card for one CO Line.
  • Page 40 DV-96 System Installation Manual Digital Keyphone Wiring for D2DLUA, D2HYUA and D2SLUA D2DLUA Phone Box 4 Wires Figure 21. Digital Key Station Wiring on D2DLUA 1. (ST1)~(ST8) are all for the Digit Key Telephone connections. 2. BT/BR is the Data/Audio/Power pair¡ ] no polarity¡ ^ .
  • Page 41 DV-96 System Installation Manual 50 Pins (25 Pairs) Male Amphenol Connector Layout Station Pair D2DLUB/D2HYUA/D2SLUA Station 1 Pair 1 Station 2 Pair 2 Station 3 Pair 3 Station 4 Pair 4 Station 5 Pair 5 Station 6 Pair 6 Station 7...
  • Page 42 DV-96 System Installation Manual Single Line Phone Wiring For D1SLCB D1-SLCA SLT #1 SLT #2 Phone Box Wire Single Line Telephone Figure 23. SLT Station Wiring on D1SLCB Connect D1SLCB on D2MBUB. Only for 2 SLT ports (SLT1) and (SLT2) provided on D1SLCB can connect with Single Line Telephone.
  • Page 43 DV-96 System Installation Manual 2-Wires Door Phone Installation PAGE PAGE Figure 24. Door Phone Wiring on D1MFCA 1. D1MFCA is an option, which must be installed to provide 2 Door Phone Connection. 2. This option allows the user to connect any kind of external 2-Wires Door Phone device.
  • Page 44 DV-96 System Installation Manual Sensor Installation PAGE PAGE Figure 25. External Sensor Wiring on D1MFCA 1. D1MFCA is an option, which must be installed to provide 2 Sensor Connections. 2. This option allows the user to connect any kind of external SENSOR device, such as Door Sensor, Smoke Detector, or Heat Sensor, among others.
  • Page 45 DV-96 System Installation Manual Door Switch Installation Connect to Door Switch Power PAGE PAGE Figure 26. Door Switch Wiring on D1MFCA 1. D1MFCA is an option, which must be installed to provide 2 Relay Connections. 2. This option allows the user to connect any kind of external Relay Control device, such as Door Switch, Loud Bell among others.
  • Page 46 DV-96 System Installation Manual External Music Source Installation D2MBUB External Music Source Figure 27. External Music Source Wiring on D2MBUB 1. Connect 2-conductor wiring cord from External Music Source to (EXMUSIC) on D2MBUB. Arista Systems Corporation...
  • Page 47 DV-96 System Installation Manual RS232¡ ] Serial Printer or PC¡ ^ Installation View from the D1MBUB Male DB9 which is RS232 front of DB9 Output Port of the system D1TKUB Wiring table Inside Wiring table Female DB9(Pin Female DB9(Pin positions are...
