For Parts Call K&T 606-678-9623 or 606-561-4983
IMPORTANT MANUAL
OWNER'S MANUAL
MODEL:
PDGT26H48B
LAWN TRACTOR
Always Wear Eye Protection During Operation
Do Not Throw Away
www.mymowerparts.com
02139
WARNING:
Read the Owner's Manual and fol-
low all Warn ings and Safety In struc -
tions. Fail ure to do so can result
in serious injury.
186714 Rev. 1 06.06.03 JH/TR
00993-poulan_pro
Printed in U.S.A.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PDGT26H48B and is the answer not in the manual?

Questions and answers

Related Manuals for Poulan Pro PDGT26H48B

Summary of Contents for Poulan Pro PDGT26H48B

  • Page 1 MODEL: Read the Owner's Manual and fol- low all Warn ings and Safety In struc - tions. Fail ure to do so can result PDGT26H48B in serious injury. LAWN TRACTOR Always Wear Eye Protection During Operation 186714 Rev. 1 06.06.03 JH/TR Printed in U.S.A.

  • Page 2: Safety Rules

    For Parts Call K&T 606-678-9623 or 606-561-4983 SAFETY RULES SAFE OPERATION PRACTICES FOR RIDE-ON MOWERS IMPORTANT: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROW ING OBJECTS. FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH. I.

  • Page 3: Table Of Contents

    For Parts Call K&T 606-678-9623 or 606-561-4983 SAFETY RULES SAFE OPERATION PRACTICES FOR RIDE-ON MOWERS • Be sure the area is clear of other people before mowing. Stop machine if anyone enters the area. WARNING: In order to prevent ac- •...

  • Page 4: Product Specifications

    For Parts Call K&T 606-678-9623 or 606-561-4983 CONGRATULATIONS on your purchase of a new tractor. PRODUCT SPECIFICATIONS It has been designed, engineered and manu fac tured to give Gasoline Capacity 5.0 Gallons you the best possible dependability and performance. and type: Unleaded Regular Should you experience any problem you cannot easily rem- Oil Type (API-SF-SJ):...

  • Page 5: Unassembled Parts

    For Parts Call K&T 606-678-9623 or 606-561-4983 UNASSEMBLED PARTS Steering Wheel Gauge Wheels Steering Sleeve (4) Washers 3/8 x 3/4 x 14 Ga. (4) Wheels (4) Adjusting Bars Steering (4) Clevis Pins Sleeve Premium Extension Steering Adapter Steering Wheel Insert (4) Retainer Springs Seat (4) Locknuts...

  • Page 6: Assembly

    For Parts Call K&T 606-678-9623 or 606-561-4983 ASSEMBLY Your new tractor has been assembled at the factory with exception of those parts left unassembled for shipping purposes. To ensure safe and proper operation of your tractor all parts and hardware you assemble must be tightened securely. Use the correct tools as necessary to insure proper tightness.

  • Page 7: Assemble Gauge Wheels To Mower

    For Parts Call K&T 606-678-9623 or 606-561-4983 ASSEMBLY • Be sure all the above assembly steps have been com- INSTALL SEAT (See Fig. 3) pleted. Adjust seat before tightening adjustment knob. • Check engine oil level and fi ll fuel tank with gasoline. •...

  • Page 8: Install Mower And Drive Belt

    For Parts Call K&T 606-678-9623 or 606-561-4983 ASSEMBLY • Lower mower linkage with attachment lift control. TO ATTACH NOSE ROLLER (See Fig. 5) • Be sure belt tension rod is in dis en gaged position. • Assemble brackets "A" and "B" to the inside of mower mounting brack ets as shown.
  • Page 9 For Parts Call K&T 606-678-9623 or 606-561-4983 ASSEMBLY ✓CHE CKLIST CHECK TIRE PRESSURE BEFORE YOU OPERATE AND ENJOY YOUR NEW TRAC- The tires on your tractor were overinfl ated at the factory TOR, WE WISH TO ASSURE THAT YOU RE CEIVE THE for shipping purposes.

  • Page 10: Operation

    For Parts Call K&T 606-678-9623 or 606-561-4983 OPERATION These symbols may appear on your tractor or in literature supplied with the product. Learn and understand their mean- ing. FAST IGNITION REVERSE HIGH SLOW NEUTRAL CHOKE LIGHTS ON ENGINE START ENGINE ON PARKING BRAKE ENGINE OFF PARKING BRAKE...
  • Page 11 For Parts Call K&T 606-678-9623 or 606-561-4983 OPERATION KNOW YOUR TRACTOR READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR. Compare the illustrations with your tractor to familiarize yourself with the location of various controls and adjustments. Save this man ual for future reference. HOURMETER LIGHT SWITCH POSITION...

  • Page 12: To Move Forward And Backward

    For Parts Call K&T 606-678-9623 or 606-561-4983 OPERATION The operation of any tractor can result in foreign objects thrown into the eyes, which can result in severe eye dam age. Always wear safety glass es or eye shields while op- erating your tractor or per form ing any adjustments or repairs.
  • Page 13 For Parts Call K&T 606-678-9623 or 606-561-4983 OPERATION TO ADJUST GAUGE WHEELS (See Fig. 9) LIFT LEVER Gauge wheels are properly adjusted when they are slightly HIGHEST POSIITON off the ground when mower is at the desired cutting height in operating position. Gauge wheels then keep the deck in proper position to help prevent scalping in most terrain conditions.

  • Page 14: Before Starting The Engine

    For Parts Call K&T 606-678-9623 or 606-561-4983 OPERATION CAUTION: Alcohol blended fuels (called gas o hol or using ethanol or methanol) can at- tract moisture which leads to sep a ra tion and for ma tion of acids during storage. Acidic gas can damage the fuel system of an engine while in storage.

  • Page 15: Mowing Tips

    For Parts Call K&T 606-678-9623 or 606-561-4983 OPERATION • Remove retainer spring from the drive belt tension • Engage transmission by placing freewheel control in handle to relieve belt tension. driving position (See “TO TRANSPORT” in this sec tion of manual). •...

  • Page 16: Maintenance Schedule

    For Parts Call K&T 606-678-9623 or 606-561-4983 MAINTENANCE MAINTENANCE SCHEDULE FILL IN DATES AS YOU COMPLETE REGULAR SERVICE SERVICE DATES Check Brake Operation Check Tire Pressure Check Operator Presence and Interlock Systems Check for Loose Fasteners Sharpen/Replace Mower Blades Lubrication Chart Check Battery Level Clean Battery and Terminals Check Transaxle Cooling...

  • Page 17: Maintenance

    For Parts Call K&T 606-678-9623 or 606-561-4983 MAINTENANCE TRACTOR MANDREL BLADE ASSEMBLY Always observe safety rules when performing any main- te nance. CENTER HOLE BRAKE OPERATION If tractor requires more than six (6) feet stopping distance BLADE BOLT (SPECIAL) at high speed in highest gear, then brake must be adjusted. (See “TO ADJUST BRAKE”...
  • Page 18 For Parts Call K&T 606-678-9623 or 606-561-4983 MAINTENANCE TO CLEAN BATTERY AND TERMINALS NOTE: Although multi-viscosity oils (5W30, 10W30 etc.) improve starting in cold weather, these multi-viscosity oils Corrosion and dirt on the battery and terminals can cause will result in increased oil consumption when used above the battery to “leak”...
  • Page 19 For Parts Call K&T 606-678-9623 or 606-561-4983 MAINTENANCE CLEAN AIR SCREEN MUFFLER Air screen must be kept free of dirt and chaff to prevent Inspect and replace corroded muffl er and spark arrester engine dam age from overheating. Clean with a wire brush (if equipped) as it could create a fi...

  • Page 20: Service And Adjustments

    For Parts Call K&T 606-678-9623 or 606-561-4983 SERVICE AND ADJUSTMENTS WARNING: TO AVOID SERIOUS INJURY, BEFORE PERFORMING ANY SER VICE OR AD JUST MENTS: • Depress brake pedal fully and set parking brake. • Place attachment clutch in “DISENGAGED” position. •...

  • Page 21: To Level Mower Housing

    For Parts Call K&T 606-678-9623 or 606-561-4983 SERVICE AND ADJUSTMENTS NOTE: To assist in locating hole in fl anged pin, the hole in pin is inline with notch on head of pin. If necessary, move SUSPENSION mower side-to-side to give space between plate and mower brackets.
  • Page 22 For Parts Call K&T 606-678-9623 or 606-561-4983 SERVICE AND ADJUSTMENTS MOWER DRIVE BELT INSTALLATION (See Fig. 24) BOTH FRONT PLATE LINKS MUST BE • Install belt in both idlers. EQUAL IN LENGTH • Install new belt onto electric clutch pulley. •...
  • Page 23 For Parts Call K&T 606-678-9623 or 606-561-4983 SERVICE AND ADJUSTMENTS TO REPLACE MOWER BLADE (SEC OND ARY) SEC OND ARY DRIVE BELT (See Fig. 25) SPRING IDLER ARM IDLER Park the tractor on level surface. En gage parking brake. L.H. MAN DREL SEC OND ARY PUL LEY SPRING ARM...
  • Page 24 For Parts Call K&T 606-678-9623 or 606-561-4983 SERVICE AND ADJUSTMENTS TO CHECK AND ADJUST BRAKE TRANSAXLE MOTION CONTROL LEVER NEUTRAL ADJUSTMENT (See Fig. 28) If tractor requires more than fi ve (5) feet to stop at highest speed in high est gear on a level, dry concrete or paved The motion control lever has been pre set at the factory and surface, then brake must be checked and ad just ed.
  • Page 25 For Parts Call K&T 606-678-9623 or 606-561-4983 SERVICE AND ADJUSTMENTS TO REMOVE WHEEL FOR REPAIRS TO ATTACH JUMPER CABLES - • Connect one end of the RED cable to the POSITIVE FRONT WHEEL (See Fig. 29) (+) terminal of each battery(A-B), taking care not to •...
  • Page 26 For Parts Call K&T 606-678-9623 or 606-561-4983 SERVICE AND ADJUSTMENTS TO REMOVE HOOD AND GRILL ASSEMBLY KEPS NUT (See Fig. 32) TERMINAL ACCESS HEX BOLT • Raise hood. DOOR • Unsnap headlight wire connector. • Stand in front of tractor. Grasp hood at sides, tilt toward engine and lift off of tractor.
  • Page 27 For Parts Call K&T 606-678-9623 or 606-561-4983 SERVICE AND ADJUSTMENTS ENGINE STOP TO AD JUST THROTTLE CON TROL CABLE (See Fig. 33) The throttle control has been preset at the factory and ad just ment should not be necessary. Check adjustment as described below before loosening cable.

  • Page 28: Storage

    For Parts Call K&T 606-678-9623 or 606-561-4983 STORAGE ENGINE Immediately prepare your tractor for storage at the end of the season or if the tractor will not be used for 30 days or more. FUEL SYSTEM IMPORTANT: IT IS IMPORTANT TO PREVENT GUM DEPOSITS WARNING: Never store the trac tor with FROM FORMING IN ES SEN TIAL FUEL SYSTEM PARTS SUCH gas o line in the tank inside a building...

  • Page 29: Troubleshooting Points

    For Parts Call K&T 606-678-9623 or 606-561-4983 TROUBLESHOOTING POINTS PROBLEM CAUSE CORRECTION Will not start Out of fuel. Fill fuel tank. Engine not “CHOKED” properly. See “TO START ENGINE” in Operation section. Engine fl ooded. 3. Wait several minutes before attempting to start. Bad spark plug.
  • Page 30 For Parts Call K&T 606-678-9623 or 606-561-4983 TROUBLESHOOTING POINTS PROBLEM CAUSE CORRECTION Engine continues to run Faulty operator-safety presence control system. Check wiring, switches and connections. If not when operator leaves seat corrected, contact an authorized service center/ with attachment clutch department.
  • Page 31 For Parts Call K&T 606-678-9623 or 606-561-4983 TRACTOR - MODEL NUMBER PDGT26H48B, PRODUCT NUMBER 954 56 95-30 SCHEMATIC BLACK BATTERY SOLENOID FUSE AMMETER STARTER (OPTIONAL) WHITE BLACK WHITE WHITE BLACK ELECTRIC CLUTCH CLUTCH / BRAKE (PEDAL UP) IGNITION BLACK SWITCH...

  • Page 32: Repair Parts - Tractor

    For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS TRACTOR - MODEL NUMBER PDGT26H48B, PRODUCT NUMBER 954 56 95-30 ELECTRICAL D .C www.mymowerparts.com...
  • Page 33 For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS TRACTOR - MODEL NUMBER PDGT26H48B, PRODUCT NUMBER 954 56 95-30 ELECTRICAL PART DESCRIPTION 144927 Battery 74760412 Bolt Hex Head 1/4-20 x 3/4 7603J Tray, Bat tery 145211 Bolt Btr Frt 1/4-20 x 7.5 zinc...
  • Page 34 For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS TRACTOR - MODEL NUMBER PDGT26H48B, PRODUCT NUMBER 954 56 95-30 CHASSIS AND ENCLOSURES chassis-stealth_37-vgt www.mymowerparts.com...
  • Page 35 For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS TRACTOR - MODEL NUMBER PDGT26H48B, PRODUCT NUMBER 954 56 95-30 CHASSIS AND ENCLOSURES PART PART DESCRIPTION DESCRIPTION 180375 Rail, Frame RH 17490508 Screw, Thd 5/16-18 x 1/2 175282 Drawbar, Gt 74780716...
  • Page 36 For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS TRACTOR - MODEL NUMBER PDGT26H48B, PRODUCT NUMBER 954 56 95-30 GROUND DRIVE 135 137 drive_6-vgt www.mymowerparts.com...
  • Page 37 For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS TRACTOR - MODEL NUMBER PDGT26H48B, PRODUCT NUMBER 954 56 95-30 GROUND DRIVE PART PART DESCRIPTION DESCRIPTION 74780716 Bolt Fin Hex 7/16-14 x 1 - - - - - - - Transaxle Hydro Gear...
  • Page 38 For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS TRACTOR - MODEL NUMBER PDGT26H48B, PRODUCT NUMBER 954 56 95-30 STEERING ASSEMBLY steering_10-vgt www.mymowerparts.com...
  • Page 39 For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS TRACTOR - MODEL NUMBER PDGT26H48B, PRODUCT NUMBER 954 56 95-30 STEERING ASSEMBLY PART DESCRIPTION 180656 Wheel, Steering 178557 Axle Asm., Front 6855M Fitting, Grease 161849 Spindle Asm, LH 161848 Spindle Asm., RH...
  • Page 40 For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS TRACTOR - MODEL NUMBER PDGT26H48B, PRODUCT NUMBER 954 56 95-30 ENGINE SPARK ARRESTER KIT engine-intek-ELS_10-vgt PART PART DESCRIPTION DESCRIPTION - - - - - - - Engine Briggs, Model No. 446777...
  • Page 41 For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS TRACTOR - MODEL NUMBER PDGT26H48B, PRODUCT NUMBER 954 56 95-30 LIFT ASSEMBLY 35 73 lift_rh_8 PART PART DESCRIPTION DESCRIPTION 121006X Rod Asm., Lever 137167 Rod, Adj Lift 180045 Shaft Asm., Lift Vgt...
  • Page 42 For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS TRACTOR - MODEL NUMBER PDGT26H48B, PRODUCT NUMBER 954 56 95-30 SEAT ASSEMBLY seat_6-vgt PART PART DESCRIPTION DESCRIPTION 171684 Seat 123740X Spring, Cprsn. 140551 Bracket, Pivot Seat 123976X Nut, Lock 1/4 Lg. Flg. Gr. 5 127018X Bolt, Shoulder 5/16-18 x .62...
  • Page 43 For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS TRACTOR - MODEL NUMBER PDGT26H48B, PRODUCT NUMBER 954 56 95-30 DECALS 19 6 PART PART DESCRIPTION DESCRIPTION 164097 Decal, Dash 185443 Decal, Battery 175291 Decal, V-Belt Schematic 184858 Decal, Engine 176272...
  • Page 44 For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS TRACTOR - MODEL NUMBER PDGT26H48B, PRODUCT NUMBER 954 56 95-30 MOWER DECK mower_deck.48prem_2 www.mymowerparts.com...
  • Page 45 For Parts Call K&T 606-678-9623 or 606-561-4983 REPAIR PARTS TRACTOR - MODEL NUMBER PDGT26H48B, PRODUCT NUMBER 954 56 95-30 MOWER DECK PART PART DESCRIPTION DESCRIPTION 180358X421 Deck Weldment Mower 48 73680600 Nut, Crownlock 3/8-16 Unc 178915 Bracket Asm., Sway Bar 72110612 Bolt, Carr.

  • Page 46: Limited Warranty

    For Parts Call K&T 606-678-9623 or 606-561-4983 LIMITED WARRANTY The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in materi- als and work man ship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we fi...
  • Page 47 SUGGESTED GUIDE FOR SIGHTING SLOPES FOR SAFE OPERATION ONLY RIDE UP AND DOWN HILL, NOT ACROSS HILL 15 DEGREES MAX. WARNING: To avoid serious injury, operate your tractor up and down the face of slopes, never across the face. Do not mow slopes greater than 15 degrees.

  • Page 48: Parts And Service

    PARTS AND SERVICE Your POULAN PRO product has been expertly en gi neered and carefully manu fac tured to rigid quality stan dards. As with all mechanical products, some adjustments or part replacement may be necessary during the life of your unit.
