IMPORTANT MANUAL
OWNER'S MANUAL
MODEL:
PDGT26H54A
LAWN TRACTOR
Always Wear Eye Protection During Operation
Do Not Throw Away
02139
WARNING:
Read the Owner's Manual and fol low
all Warn ings and Safety In struc tions.
Fail ure to do so can result in seri-
ous injury.
188724 Rev. 2 4.16.04 TR/MH
Printed in U.S.A.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Poulan Pro PDGT26H54A
Summary of Contents for Poulan Pro PDGT26H54A
- Page 1 IMPORTANT MANUAL OWNER'S MANUAL MODEL: PDGT26H54A LAWN TRACTOR Always Wear Eye Protection During Operation Do Not Throw Away 02139 WARNING: Read the Owner's Manual and fol low all Warn ings and Safety In struc tions. Fail ure to do so can result in seri- ous injury.
-
Page 2: Safety Rules
SAFE OPERATION PRACTICES FOR RIDE-ON MOWERS IMPORTANT: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROW ING OBJECTS. FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH. I. GENERAL OPERATION • Read, understand, and follow all instructions in the manual and on the machine before starting. -
Page 3: Table Of Contents
SAFE OPERATION PRACTICES FOR RIDE-ON MOWERS • Be sure the area is clear of other people before mowing. Stop machine if anyone enters the area. • Never carry passengers or children even with the blades off. • Do not mow in reverse unless absolutely necessary. Al ways look down and behind before and while backing. -
Page 4: Product Specifications
PRODUCT SPECIFICATIONS Gasoline Capacity 5.0 Gallons and type: Unleaded Regular Oil Type (API-SG-SL): SAE 30 (above 32°F) SAE 5W-30 (below 32°F) Oil Capacity: W/Filter: W/O Filter: 3.75 Pints Spark Plug: Champion QC12YC (Gap: .040") Ground Speed (MPH): Forward: Reverse: Tire Pressure: Front: Rear: Charging System:... -
Page 5: Unassembled Parts
UNASSEMBLED PARTS Steering Wheel Steering Sleeve Steering Sleeve Premium Extension Steering Adapter Seat (1) Washer 17/32 x 1-3/16 x 12 Gauge (1) Knob Nose Roller Nose Roller Brackets (2) Hex Bolts 5/16-18 x 1 (4) Adjusting Bars Steering Wheel Insert (4) Retainer Springs (2) Flanged Pins Keys... -
Page 6: Assembly
Your new tractor has been assembled at the factory with exception of those parts left unassembled for shipping purposes. To ensure safe and proper operation of your tractor all parts and hardware you assemble must be tightened securely. Use the correct tools as necessary to insure proper tightness. TOOLS REQUIRED FOR ASSEMBLY A socket wrench set will make assembly easier. -
Page 7: Assemble Gauge Wheels To Mower
INSTALL SEAT (See Fig. 3) Adjust seat before tightening adjustment knob. • Remove adjustment knob and fl at washer securing seat to cardboard packing and set aside for assembly of seat to tractor. • Pivot seat upward and remove from the cardboard pack- ing. -
Page 8: Install Mower And Drive Belt
TO ATTACH NOSE ROLLER (See Fig. 6) • Assemble brackets "A" and "B" to the inside of mower mounting brack ets as shown. Tighten securely. NOTE: Be sure bracket tabs are po si tioned in tab holes in mower brackets. •... -
Page 9: Assembly
IMPORTANT: CHECK BELT FOR PROPER ROUTING IN ALL MOWER PULLEY GROOVES. • Engage belt tension rod on locking bracket. CAUTION: Belt tension rod is spring loaded. Have a tight grip on rod and engage slowly. • Raise attachment lift lever to highest position. •... -
Page 10: Operation
These symbols may appear on your tractor or in literature supplied with the product. Learn and understand their mean- ing. REVERSE NEUTRAL LIGHTS ON ENGINE ON ENGINE OFF OIL PRESSURE FUEL OVER TEMP LIGHT ATTACHMENT ATTACHMENT CLUTCH ENGAGED CLUTCH DISENGAGED FREE WHEEL (Automatic Models only) Failure to follow instructions... -
Page 11: Know Your Tractor
KNOW YOUR TRACTOR READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR. Compare the illustrations with your tractor to familiarize yourself with the location of various controls and adjustments. Save this man ual for future reference. THROTTLE CONTROL BRAKE PEDAL MOTION DRIVE BELT TENSION... -
Page 12: How To Use Your Tractor
The operation of any tractor can result in foreign objects thrown into the eyes, which can result in severe eye dam age. Always wear safety glass es or eye shields while op- erating your tractor or per form ing any adjustments or repairs. We rec om mend a wide vision safety mask over spectacles or stan dard safety glasses. -
Page 13: To Operate On Hills
TO ADJUST GAUGE WHEELS (See Fig. 10) Gauge wheels are properly adjusted when they are slightly off the ground when mower is at the desired cutting height in operating position. Gauge wheels then keep the deck in proper position to help prevent scalping in most terrain conditions. -
Page 14: Before Starting The Engine
02219 FIG. 12 TOWING CARTS AND OTHER AT TACH - MENTS Tow only the attachments that are recommended by and comply with specifi cations of the manufacturer of your trac- tor. Use common sense when towing. Too heavy of a load, while on a slope, is dangerous. -
Page 15: Mowing Tips
• Remove retainer spring from the drive belt tension handle to relieve belt tension. • Start engine and allow it to warm up for three (3) min- utes. • Shut-off engine and engage parking brake. • Engage drive belt tension handle and replace the re tain er spring. -
Page 16: Maintenance Schedule
MAINTENANCE SCHEDULE FILL IN DATES AS YOU COMPLETE REGULAR SERVICE Check Brake Operation Check Tire Pressure Check Operator Presence and Interlock Systems Check for Loose Fasteners Sharpen/Replace Mower Blades Lubrication Chart Check Battery Level Clean Battery and Terminals Check Transaxle Cooling Check V-Belts Check Engine Oil Level Change Engine Oil (with oil filter) -
Page 17: Operator Presence System
TRACTOR Always observe safety rules when performing any main- te nance. BRAKE OPERATION If tractor requires more than six (6) feet stopping distance at high speed in highest gear, then brake must be adjusted. (See “TO ADJUST BRAKE” in the Service and Ad just ments section of this manual). -
Page 18: Engine Lubrication
TO CLEAN BATTERY AND TERMINALS Corrosion and dirt on the battery and terminals can cause the battery to “leak” power. • Remove terminal guard. • Disconnect BLACK battery cable fi rst then RED bat- tery cable and remove battery from tractor. •... - Page 19 CLEAN AIR SCREEN Air screen must be kept free of dirt and chaff to prevent engine dam age from overheating. Clean with a wire brush or com pressed air to re move dirt and stubborn dried gum fi bers. AIR FILTER Your engine will not run properly using a dirty air fi...
-
Page 20: Service And Adjustments
SERVICE AND ADJUSTMENTS WARNING: TO AVOID SERIOUS INJURY, BEFORE PERFORMING ANY SER VICE OR AD JUST MENTS: • Depress brake pedal fully and set parking brake. • Place attachment clutch in “DISENGAGED” position. • Turn ignition key to “STOP” and remove key. •... -
Page 21: Service And Adjustments
SERVICE AND ADJUSTMENTS • If adjustment is necessary, make adjustment on one side of mower only. • To raise one side of mower, tighten lift link ad just ment nut on that side. • To lower one side of mower, loosen lift link ad just ment nut on that side. - Page 22 SERVICE AND ADJUSTMENTS TO REPLACE MOWER DRIVE BELT (See Fig. 24) MOWER DRIVE BELT REMOVAL • Park tractor on a level surface. En gage parking brake. • Lower attachment lift lever to its lowest position. • Disengage belt tension rod from lock bracket. CAUTION: Belt tension rod is spring loaded.
- Page 23 SERVICE AND ADJUSTMENTS TO ADJUST ATTACHMENT CLUTCH (See Fig. 25) The electric clutch should provide years of service. The clutch has a built-in brake that stops the pulley within 5 seconds. Eventually, the internal brake will wear which may cause the mower blades to not engage, or, to not stop as required.
- Page 24 SERVICE AND ADJUSTMENTS TO AD JUST STEER ING WHEEL ALIGN- MENT If steering wheel crossbars are not horizontal (left to right) when wheels are positioned straight forward, remove steer- ing wheel and reassemble per instructions in the Assembly section of this manual. FRONT WHEEL TOE-IN/CAMBER The front wheel toe-in and camber are not adjustable on your tractor.
-
Page 25: Service And Ad Just Ments
SERVICE AND ADJUSTMENTS REPLACING BATTERY (See Fig. 30) WARNING: Do not short battery ter- mi nals by allowing a wrench or any other object to contact both terminals at the same time. Before connecting battery, remove metal bracelets, wristwatch bands, rings, etc. Positive terminal must be connected fi... -
Page 26: Storage
Immediately prepare your tractor for storage at the end of the season or if the tractor will not be used for 30 days or more. WARNING: Never store the trac tor with gas o line in the tank inside a building where fumes may reach an open fl... -
Page 27: Trou Ble Shoot Ing
TROUBLESHOOTING POINTS PROBLEM CAUSE Will not start Out of fuel. Engine not “CHOKED” properly. Engine fl ooded. Bad spark plug. Dirty air fi lter. Dirty fuel fi lter. 7. Water in fuel. Loose or damaged wiring. Carburetor out of adjustment. Engine valves out of adjustment. - Page 28 TROUBLESHOOTING POINTS PROBLEM CAUSE Engine continues to run Faulty operator-safety presence control system. when operator leaves seat with attachment clutch engaged Poor cut - uneven 1. Worn, bent or loose blade. Mower deck not level. Buildup of grass, leaves, and trash under mower. Bent blade mandrel.
-
Page 29: Warranty
The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in materi- als and work man ship. For a period of two (2) years from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replacing parts, any part which we fi... -
Page 30: Suggested Guide For Sighting Slopes For Safe Operation
SUGGESTED GUIDE FOR SIGHTING SLOPES FOR SAFE OPERATION WARNING: To avoid serious injury, operate your tractor up and down the face of slopes, never across the face. Do not mow slopes greater than 15 degrees. Make turns gradually to prevent tipping or loss of control. -
Page 31: Parts And Service
PARTS AND SERVICE Your POULAN PRO product has been expertly en gi neered and carefully manu fac tured to rigid quality stan dards. As with all mechanical products, some adjustments or part replacement may be necessary during the life of your unit.
