NOTE
The antenna should only be connected and
disconnected when the IsatDock LITE is not
powered. Connecting the antenna after power-up
can result in prolonged acquisition time.
ISD710
ISD700
Marine Antenna
Directional/Fixed
3) Connect the Privacy Handset
(Active) with Pole
Antenna (Passive)
Bracket
with Bracket
(Optional – Extra Order)
The IsatDock LITE provides a RJ9 audio
socket on the bottom of the docking unit, for
ISD715
connection to the Beam privacy handset. This
Magnetic
provides a local handset function, conveniently
Mounting
mounted next to the IsatDock LITE cradle.
ISD720
1.
The Privacy Handset Kit (purchased/ordered
Bolt
separately) contains a mounting bracket,
Transport Antenna
Mounting
(Active)
space plate, screws, washers and nut bolts.
NOTE
Refer to the section "Antenna Installation" for more
information on antenna placement and installation.
16
2.
Mount the handset cup to the mounting
plate, it can be installed to the left or right side
of the dock by simply rotating the bracket.
Secure the cup with the washer and nut
bolt behind the bracket.
3 screws
M4 x 14
Left and right configuration
3.
Mount the spacer plate and the mounting
bracket to the rear of the IsatDock LITE, by
using the longer screws provided with the
kit. The original RAM® arm-bracket plate
is also re-installed behind these plates.
Install in the following order:
4.
a
b
c
d
e
+
+
+
+
[a] Rear of IsatDock LITE
[b] Spacer
[c] Mounting plate
[d] RAM base
[e] 3 x Mounting screws & washers
4) Connecting the DC Power Cable
The DC power cable supplied has three wires,
RED, BLACK and YELLOW.
3 Long Screws
M4 x 18 &
The RED and BLACK wires are used for the
washers
power connection while the YELLOW wire can
be connected to a vehicle's accessories, ignition
or a switch.
By default, the IsatDock LITE will stay on for 20
5.
Plug the Privacy Handset RJ9 connector
minutes after this input is switched off. If a call
into the bottom of the docking unit, as
is in progress while this occurs, the IsatDock
per image below. Privacy Handset mode
LITE will stay on for 20 minutes after the call
is enabled when the handset is removed
is terminated. Please follow the steps below
from the cup. Please ensure to re-dock the
to connect the DC power cable to the vehicle
Privacy Handset when not in use.
battery power and the IsatDock LITE.
1.
Route the wire end of the DC power
cable to the connection point. DO NOT
apply power until the following steps
IsatDock LITE - Installation & User Manual
are completed.
2.
Connect the BLACK wire to the negative
terminal of the battery (10A fuse
recommended) or the vehicle chassis (if
negatively grounded chassis).
YELLOW
3.
Connect the RED wire to the positive
RED
terminal of the battery. It is recommended
BLACK
to add a 5A fuse (supplied) between them.
4.
Connect the YELLOW wire to the vehicle
accessory power. If the accessory power
is unavailable, this may be connected
to a vehicle ignition voltage. It is
recommended to add a 1A fuse between
them. The accessory wire enables the
IsatDock LITE to turn on and off as the
vehicle key is enabled or disabled. If this
function is not required, the YELLOW wire
MUST be connected to the RED wire.
5.
Connect the 4-way Microfit connector on
the DC power cable to the 4-way power
connector on the rear cable loom of the
IsatDock LITE.
RED
(+) Vin 10 to 32VDC
To Battery Positive Terminal
(Requires 5A Fuse)
BLACK
(-) OV Power Ground
To Negative Terminal or chassis
YELLOW ON/SLEEP
To ON/OFF switch
(1A Fuse recommended)
17
