- Page 1 ViewSonic ® PJ458D - User Guide DLP Projector - Guide de l’utilisateur - Bedienungsanleitung - Guía del usuario - Guia do usuário - Руководство пользователя - 使用手冊 (繁體) - 使用手冊 (簡體) - 사용자 안내서 Model No. : VS10872 www.azulmarina.com...
-
Page 2: Compliance Information
www.azulmarina.com Compliance Information FCC Statement This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 3: Important Safety Instructions
ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 4: Declaration Of Rohs Compliance
4. Lead as an allotting element in steel containing up to 0.35% lead by weight, aluminium containing up to 0.4% lead by weight and as a cooper alloy containing up to 4% lead by weight. ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 5: Copyright Information
Microsoft, Windows, Windows NT, and the Windows logo are registered trademarks of Microsoft Corporation in the United States and other countries. ViewSonic, the three birds’ logo, OnView, ViewMatch, and ViewMeter are registered trademarks of ViewSonic Corporation. VESA is a registered trademark of the Video Electronics Standards Association. -
Page 6: Notes On Ac Power Cord
We highly recommend using a video source device also equipped with a grounding type AC line plug to prevent from signal interference due to voltage fluctuation. Ground Ground For Australia and For the U.S.A. and Canada Mainland China Ground Ground For Continental Europe For the U.K. ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 7: Table Of Contents
Menu Options ......................4 Image ......................5 Video .......................8 Display......................9 Language ......................0 Advanced ...................... Audio ....................... Maintenance ...................... Cleaning the Lens ................... Cleaning the Projector Housing............... Replacing the Lamp ..................4 Technical Specifications ..................6 Appendix.........................7 Indicator Messages ..................7 Preset Signals ....................8 ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 8: Product Introduction
00-watt, user-replaceable lamp ® Compatibility with Macintosh computers Compatibility with NTSC, PAL, SECAM, and HDTV Multi-function remote control D-Sub 15-pin cable for analog video connectivity User-friendly, multi-language on-screen display (OSD) Advanced electronic keystone correction * means compressed. ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 9: Package Contents
Save the original shipping carton and packing material; they will come in handy if you ever to ship your unit. For maximum protection, repack your NOTE unit as it was originally packed at the factory. Accessories and components may vary by retailer and region. ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 10: Getting To Know The Projector
Front View 6. Focus ring . Lens cap . Lens cap strap 7. Control panel 8. Speaker . Lens 4. Ventilation holes (intake) 9. Front IR remote control sensor 5. Zoom ring 0. Ventilation holes (exhaust) ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 11: Rear View
Rear View . Interface connector . Rear IR remote control sensor 3. Security lock receptacle 4. AC power socket 5. Ventilation holes (intake) 6. Foot adjuster 7. Foot adjuster button Bottom View . Lamp cover ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 12: Interface Connector
3. COMPUTER IN (D-SUB) connector Connect image input signal (analog) to this connector. 4. S-VIDEO connector Connect S-Video output from video equipment to this jack. 5. VIDEO connector Connect composite video output from video equipment to this jack. ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 13: Remote Control Components
AUTO SOURCE 4. Enter button 5. Keystone / buttons 6. Volume / buttons MENU 7. Source button ENTER BLANK 8. Mute button 9. Blank button LASER 10. 4:3/16:9 button VOLUME 4:3/16:9 KEYSTONE . Auto button MUTE ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 14: Installation
Installation Connecting the Projector A. Connecting to a computer AC Power Cord VGA Cable (D-SUB to D-SUB) Desktop type Laptop type ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... - Page 15 B. Connecting to a Video Source 1.Connecting with S-Video Cable AC Power Cord S-Video Cable Audio Cable ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com...
- Page 16 2.Connecting with Composite Video Cable AC Power Cord Composite Video Cable Audio Cable ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com...
- Page 17 3.Connecting with HDTV Cable AC Power Cord D-SUB to HDTV Cable Audio Cable When connecting cable, power cords of both a projector and external equipment should be disconnected from AC outlet. ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com...
-
Page 18: Powering On/Off The Projector
Remote Control again to turn off the power. Wait until the lamp LED indicator turns off. Please wait until the fan motor and the lamp LED turn off before removing the AC power cord from the projector. ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 19: Adjusting The Projected Image
You may turn the foot adjuster to make fine adjustment of the height. To avoid damaging the projector, make sure that the foot adjuster is fully retracted before placing the projector in its carrying case. ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 20: Adjusting The Projector Zoom And Focus
A still image is recommended for focusing. Adjusting Projection Image Size Refer to the graphic and table below to determine the screen size and projection distance. Distance between the screen and the center of the lens ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... - Page 21 NOTE Make sure the heat ventilation holes are not blocked. Do not use the projector in a smoky environment. Smoke residue may cause buildup on critical parts (i.e. DMD, lens assembly, etc.) ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com...
-
Page 22: Using The Projector
Automatically adjusts frequency and phase. 5. Four direction buttons The four direction buttons /// can be used to scroll through OSD (On- Screen Display) menus and make adjustments. 6. SOURCE () Manually selects an input source. ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 23: Remote Control
8. Mute Cuts off the sound temporarily. 9. Blank Cuts off the screen temporarily. 10. 4:3/16:9 Press the 4:3/16:9 to switch the image aspect ratio from 4: to 6:9. . Auto Automatically adjusts frequency and phase. ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 24: Battery Replacement
Do not dispose of the used battery along with household waste. Dispose of used batteries according to local regulations. Avoid excessive heat and humidity. Danger of explosion may happen if a battery is incorrectly replaced. Replace only with the same type recommended by the manufacturer. ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 25: Remote Control Operation
Do not drop the remote control or jolt it. Keep the remote control out of locations with excessively high temperature or humidity. Do not get water on the remote control or place wet objects on it. Do not disassemble the remote control. ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... - Page 26 MENU\ENTER button. On the Remote Control: press the Menu button. The illustrations in this manual are for the purpose of explanation and may NOTE differ from the actual setting of your projector. ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com...
-
Page 27: Image
(through VGA cable) of resolution less than SVGA (800 x 600). If the input signal is a computer signal greater than SVGA or component 1080i / 720p, only 6:9 or 4: aspect ratio will be available. ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... - Page 28 Color Temperature Adjusts the color temperature. With the higher temperature, the screen looks colder; with the lower temperature, the screen looks warmer. Red, Green and Blue mode activate only if the Color Temperature is set to “User”. ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com...
- Page 29 Press the button to increase the color temperature. Blue Manually adjusts blue. Select the desired setting with the / buttons: Press the button to decrease the color temperature. Press the button to increase the color temperature. ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com...
-
Page 30: Video
Press the button to increase the amount of red in the image. Sharpness Adjusts the sharpness of the image. Select the desired setting with the / buttons: Press the button to decrease the sharpness. Press the button to increase the sharpness. ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 31: Display
Press the button to move the image right. V.Position Adjusts the vertical position. Select the desired setting with the / buttons: Press the button to move the image up. Press the button to move the image down. ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 32: Language
Select the language you prefer with the / buttons, and confirm the selection with the MENU\ENTER button on the Projector Control Panel or the Enter button on the Remote Control. English Deutsch Français Español Português Italiano ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 33: Advanced
Displays operating hours since lamp timer reset. Lamp hour counter is displayed in read-only format, and this setting cannot be manually adjusted. Color Space Manually selects signal type. Select the input signal type with the / buttons: YCbCr YPbPr ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 34: Audio
Select the desired setting with the / buttons: Press the button to decrease the volume. Press the button to increase the volume. Mute Cuts off the sound temporarily. Select the desired setting with the / buttons: ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 35: Maintenance
Make sure the lens is cool before cleaning. NOTE Do not use detergents or chemicals other than those noted above. Do not use benzene or thinners. Do not use chemical sprays. Use a soft cloth or lens paper only. ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 36: Replacing The Lamp
Leave the area immediately if the lamp shatters while being operated and ventilate the area for at least 0 minutes in order to avoid the inhalation of mercury fumes. Otherwise it could be harmful to user’s health. ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... - Page 37 Do not reuse the old lamp. This could cause the lamp to explode. Be sure to turn off the projector and unplug the AC power cord before replacing the lamp. Do not use the projector with the lamp cover removed. ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com...
-
Page 38: Technical Specifications
AC 100 - 240 V, 50 - 60 Hz Power Consumption 50 Watts Dimension (W x D x H) 254 x 202 x 98 mm Weight 2.2 kg (4.9 lb) Note: Design and Specifications are subject to change without prior notice. ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 39: Appendix
LED turns off. The fan motor will turn off when the lamp has cooled. Lamp LED Amber Flashing Temperature is too high. The lamp will turn off. ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 40: Preset Signals
H(+), V(+) 1568 1280 x 960 SXGA VESA 60 Hz 60.000 60.000 H(+), V(+) 1800 SXGA VESA 75 Hz 75.000 75.000 H(+), V(+) 1680 1280 x 1024 SXGA VESA 60 Hz 63.981 60.020 H(+), V(+) 1688 ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 41: Hdtv Preset Signals
Preset Signals Horizontal Frequency (kHz) Vertical Frequency (Hz) 480i 15.8 kHz 60 Hz 480p 31.5 kHz 60 Hz 720p 45.0 kHz 60 Hz 1080i 33.8 kHz 60 Hz Note: Specifications are subject to change without notice. ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 42: Other Information
T= 886 2 2246 3456 www.ap.viewsonic.com service@sd.viewsonic.com Other countries F= 886 2 2249 1751 Hong Kong www.hk.viewsonic.com T= 852 3102 2900 service@hk.viewsonic.com Macau www.hk.viewsonic.com T= 853 700 303 service@hk.viewsonic.com Korea www.kr.viewsonic.com T= 080 265 9080 service@kr.viewsonic.com ViewSonic PJ458D www.azulmarina.com ventas@azulmarina.com... -
Page 43: Limited Warranty
ViewSonic warrants its products to be free from defects in material and workmanship during the warranty period. If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will at its sole option repair or replace the product with a like product. - Page 44 www.azulmarina.com www.azulmarina.com ventas@azulmarina.com...
