Summary of Contents for Cruisers Yachts 48 Cantius
- Page 1 48 Cantius Table of Contents 1. Introduction......................1-1 2. Model Specific Information................2-1 3. Controls and Indicators ..................3-1 4. Basic Systems Operation ................. 4-1 V2510200 (Rev. 0) 48 Cantius...
- Page 2 This Page Intentionally Left Blank 48 Cantius...
-
Page 3: Table Of Contents
Skipper’s Kit ..............1-2 Dealership Responsibilities..........1-5 Your Responsibilities ............1-5 Owner’s Manual ..............1-2 Warranty Service ..............1-5 Safety Symbols ..............1-3 Safety Label Location Layout........1-6 Safety................. 1-3 Owner’s Manuals for Onboard Systems and Components..............1-4 48 Cantius... -
Page 4: Welcome Aboard
The Skipper’s Kit contains the 48 Cantius owner’s manual. Also included is information about onboard systems and components We wish to thank you for making our 48 Cantius your recreational furnished by suppliers other than Cruisers Yachts. choice for boating enjoyment. Extensive design and engineering research went into the development of all Cruisers Yachts. -
Page 5: Safety Symbols
Section 4 contains principles of operation for the major systems The Safety Alert Symbol means onboard the 48 Cantius. ATTENTION! Be alert to the possibility of personal injury or death. The following precautions are used throughout this manual. -
Page 6: Owner's Manuals For Onboard Systems And Components
Cruisers Yachts. Depending on the options you chose, the kit may contain some or all of the following literature: •... -
Page 7: Warranty Information
You are entitled to all the benefits and services set down in the your responsibility to fill out any warranty registration that may be warranties. If a problem arises with your 48 Cantius as a result of required. workmanship or materials, contact your Cruisers Yachts Dealer as soon as possible. -
Page 8: Safety Label Location Layout
United States if such discharge causes a film or sheen upon, or discoloration of, the surface of the water, or causes a sludge or emulsion beneath the surface of the water. Violators are subject to a penalty of $5,000. WARNING WARNING 51-R001A 48 Cantius... - Page 9 A/C Upper Salon View ..........2-11 Sliding Salon Patio Door..........2-23 Plumbing Hardware ............. 2-12 Foredeck Lounge............2-23 Raw Water Hose Layout ..........2-13 Lifting and Storing Your Boat ........2-24 Engine General Layout - Twin IPS......2-14 48 Cantius...
-
Page 10: Specifications
*Weights are estimates and can vary from options and equipment added. Engines GAS: Volvo Penta IPS 500G, T-375 HP (T-280 KW) DIESEL: Volvo Penta IPS 500 D6, T-370 HP (T-276 KW) Volvo Penta IPS 600 D6, T-435 HP (T-324 KW) 48 Cantius... -
Page 11: Deck Hardware General Layout
20. Flushmount 2.1 cu. ft. Refrigerator 32. Rope Locker Lid 33. Swim Ladder Hatch 9. Grab Rail 21. Cockpit Grill 22. Flushmount Ice Maker 34. Day Hatch 10. Access Door 11. Bow Roller Ladder Purple = optional equipment 32 29 1 51-R005D 48 Cantius... -
Page 12: Upper Salon General Layout
13. Freshwater Washdown Faucet 20. Stern Seat 21. Hydraulic Swim Platform 6. High / Low Table 14. Stereo Remote Control 7. Engine Room Access 15. Sink 22. Fender Storage 8. Grill Purple = optional equipment 5 6 7 51-R005D.1 48 Cantius... -
Page 13: Lower Salon General Layout
21. Helm 12V Breaker Panel Access 6. TV 14. TV 22. AC/DC Main Breaker Panel 15. Dinette Table Top Storage 7. Refrigerator / Freezer 23. A/C Unit 8. DVD Player 16. Forward Vanity 24. Storage Drawers Purple = optional equipment 9 10 51-R005D.2 48 Cantius... -
Page 14: Stereo / Tv Layout - Upper Salon
Section 2 STEREO / TV LAYOUT - UPPER SALON 1. TV, 32" 2. Stereo 3. Stereo Remote 4. Exterior Speaker 5. Subwoofer 6. Interior Speaker 7. DVD Player Purple = optional equipment 51-R015B.1 48 Cantius... -
Page 15: Stereo / Tv Layout - Lower Salon
Model Specific Information STEREO / TV LAYOUT - LOWER SALON 1. TV, 32" 2. TV, 22" US, 20" Int’l. 3. DVD Player 4. Stereo 5. Stereo Remote 6. Speaker Purple = optional equipment 51-R015B.2 48 Cantius... -
Page 16: Upper Salon Lighting And Outlet Layout
14. Transom Seat Switch 7. Auxiliary Stereo USB Input Cockpit Transom Switch Panel = 12V White LED Light Port Salon Dual Receptacle Box Dual GFCI Receptacle Box = 12V Hardtop Light Purple = optional equipment = 12V Overhead Square Light 51-R007D 48 Cantius... -
Page 17: Lower Salon Lighting And Outlet Layout
4. Dual GFCI Receptacle Box 10. Inline Blower 15. 2-Way Light Switch 20. 3-Way Light Switch 5. 18" Fluorescent Light = 12V White LED Button Light = 12V Overhead Square Light 13 15 6 10 3 3 11 15 51-R007D.1 48 Cantius... -
Page 18: A/C Lower Salon View
8. Forward Plenum to Forward Head 9. Aft Plenum to Salon 10. Forward Plenum to FSR 11. Aft Plenum to MSR 12. Port A/C to Salon 13. Port A/C to Forward Plenum 14. MSR A/C to Aft Plenum 51-R006D.1 2-10 48 Cantius... -
Page 19: A/C Upper Salon View
1. A/C Unit 2. Upper Salon Cabin Vent 3. Upper Salon Aft Vent 4. Port A/C to Aft Vent 5. Port A/C to Forward Vent 6. Starboard A/C to Aft Vent 7. Starboard A/C to Forward Vent 51-R006D 2-11 48 Cantius... -
Page 20: Plumbing Hardware
7. Bilge Pump Float Switch 11. A/C Raw Water Pump 15. Washer / Dryer Combo 4. Galley Faucet / Sink 8. A/C Unit 12. A/C Unit 16. Hot Water Heater Purple = optional equipment 11 13 11 10 9 51-R001D.2 2-12 48 Cantius... -
Page 21: Raw Water Hose Layout
8. Starboard Salon A/C Drain 19. Aft Head Floor Drain 28. Water Heater Drain 9. Port Salon A/C Drain 20. Forward Shower Drain 10. Lower Salon Aft A/C Inlet 18 16 15 14 17 23 20 Purple = optional equipment 51-R001D.4 2-13 48 Cantius... -
Page 22: Engine General Layout - Twin Ips
7. Cranking Battery Bank 8. 12V Deep Cycle Battery Bank 9. Genset Strainer 10. Genset Valve 11. Genset Muffler 12. Cockpit A/C Raw Water Pump 13. Shore Power Cord 14. Vented Loop 15. Genset 16. Intake Water Strainer 51-R002D.1 2-14 48 Cantius... -
Page 23: Engine Room Panels - Bulkhead Views
12. Voltage Relay 13. Terminal Block Bus Bar 14. 750A Fuse Block 15. 150A DC Circuit Breaker 16. 80A DC Circuit Breaker 17. 50A / 12V Battery Charger 18. 50A Barrier Strip 19. 3-Valve Reverso Oil Pump 51-R002D.2 2-15 48 Cantius... -
Page 24: Fuel Tank And Fittings
Section 2 FUEL TANK AND FITTINGS 1. Ball Valve 2. Male Adapter VENT VENT 3. Adapter 4. Connector 5. Plug 6. Elbow 7. Adapter GENERATOR ENGINE FEED ENGINE RETURN FEED/RETURN 51-R004C 2-16 48 Cantius... -
Page 25: Freshwater Layout
28. Anchor Washdown Cold Water Hose, Blue 9. Water Pump Water Pump Cold Water Hose, Blue Cockpit Ice Maker Tubing 10. Hot Water Heater, 11 Gal. Port Hot Water Hose, Red Windshield Washer Tubing Purple = optional equipment 51-R001D 2-17 48 Cantius... -
Page 26: Waste Layout
7. Aft Head Waste Hose 2. Short Forward Head 3. Tall Aft Head 8. Forward Head Waste Hose 9. Waste Tank Pump-Out Hose to Deck Plate 4. Macerator Pump 10. Macerator Hose 5. Seacock Purple = optional equipment 51-R001D.3 2-18 48 Cantius... - Page 27 7. Forward Head 3. Waste Tank 12. Tank to Waste Plate Hose 8. Macerator Pump 4. Waste Tank Vent Hose Assembly 13. Waste Deck Plate 9. Macerator Pump-Out Hose 5. Flush Vent Purple = optional equipment 51-R001D.1 2-19 48 Cantius...
-
Page 28: Hardtop - Port Drain Layout
HARDTOP - PORT DRAIN LAYOUT 2, 3 2, 3 2, 3 1. Tee 2. Reducer Fitting 3. Nipple Fitting 4. Aft Drain to Tee 5. Forward Drain to Tee 6. Drain Hose (Tee to Port Plenum) 51-R020B.1 2-20 48 Cantius... -
Page 29: Hardtop - Starboard Drain Layout
Model Specific Information HARDTOP - STARBOARD DRAIN LAYOUT 1. Tee 2. Reducer Fitting 3. Nipple Fitting 2, 3 2, 3 4. Aft Drain to Tee 5. Forward Drain to Tee 6. Drain Hose (Tee to Starboard Plenum) 51-R020B.2 2-21 48 Cantius... -
Page 30: Dinette Tables
TRANSOM GATES The transom gates can be locked into an open position to access the swim platform and locked when the yacht is underway. Keep the gates in their closed position and locked while the yacht is underway. 2-22 48 Cantius... -
Page 31: Sliding Salon Patio Door
Maintain clear visibility at all times. Return the DANGER backrests to the DOWN position before getting To prevent exhaust fumes and water from entering underway. cabin, keep cabin door closed with engines or generator running. LOCK RELEASE CSR_360_006 CSR_0023 2-23 48 Cantius... -
Page 32: Lifting And Storing Your Boat
DO NOT lift a yacht with a large amount of water in the any cradle or hull distortion. Contact your Cruisers Yachts Dealer to bilge! Undue stress will be put on the hull that may order a cradle. -
Page 33: Controls And Indicators
Throttle Controls ..............3-2 Helm Rocker Switch Panel ..........3-3 Engine Ignition Starting / Stopping - Key Switch Panel ..3-2 Drink Holder................ 3-4 Fireboy Alarm..............3-2 Dash Layout ..............3-5 High Water Alarm............... 3-3 Helm Wheel Tilt..............3-3 48 Cantius... -
Page 34: Dash Panel Layout
The lamp should glow when the ignition switch is in the ON position, indicating a charged system. Should the system discharge, the lamp will not glow. Refer to the fire suppression owner’s manual in the Skipper’s Kit for complete details. 48 Cantius... -
Page 35: High Water Alarm
The WINDLASS ENABLE switch must be powered before the ▲ (raise) or ▼ (lower) switch will work. you are underway. • To trim the bow of your boat down, push the top halves of both Windshield Wiper - This switch operates the windshield wipers. switches. 48 Cantius... -
Page 36: Drink Holder
“Table ▲, Table ▼” - This switch raises and lowers the cockpit table. DO NOT continue to operate the switch once the table is completely up or down; damage to the table system can occur. 48 Cantius... -
Page 37: Dash Layout
Controls and Indicators DASH LAYOUT 13 12 51-R011D 48 Cantius... - Page 38 Section 3 This Page Intentionally Left Blank 48 Cantius...
-
Page 39: Basic Systems Operation
US Stds 60 Hz (240V / 120V AC) ........4-13 Cooling System ..............4-4 Intl Stds 32 Amp (230V AC)..........4-14 Propellers ................4-5 AC Electrical System ............4-15 Fuel System..............4-6 AC Master Panel............... 4-15 AC Panel Circuit Breaker Functions ......... 4-17 Steering System............. 4-6 48 Cantius... -
Page 40: Working Deck
Section 4 WORKING DECK WORKING DECK 51-R001A.1 48 Cantius... -
Page 41: Handling Dock And Mooring Lines
Fasten the bow line to the bow cleat and pull forward at about a 45° angle to keep the yacht from moving astern. Fasten the stern line to an “after” cleat and pull astern at about a 45° angle to keep the yacht from moving forward. 48 Cantius... -
Page 42: Power Train
• Transmission oil temperature exceeds specified limits and level is • Ignition switches are ON, engines are OFF To test the alarm system, turn the ignition switch to the ON position. Depending upon the engine, the alarm may sound immediately, or after a few seconds’ delay. 48 Cantius... -
Page 43: Propellers
Cruisers Yachts recommends that you consult with, and remove the emergency stop switch clip, if your and employ the skills of, your Cruisers Yachts Dealer yacht is equipped with stop switches, to prevent accidental starting of the engines. Do not use when contemplating a propeller change. -
Page 44: Fuel System
DO NOT operate your yacht if you suspect a problem with the steering system. Have your Cruisers Yachts The fuel tank outlets to the engines have a manual valve for fuel Dealer inspect the steering system if you suspect a shutoff in the event of a line break. -
Page 45: Trim Tabs
(cylinders) which lower the trim tabs. To raise the trim tabs, the rocker switch is moved, which allows oil to flow from the actuator to the pump. TRIM TAB TRIM PUMP ROCKER SWITCHES SOLENOIDS TRIM TAB ZINC PLATE CSR480-1A 48 Cantius... -
Page 46: Electrical System
This will facilitate shocks. Any modifications to the system should electronics installation. In addition, the handrails are attached to the always be done by an authorized Cruisers Yachts bonding system. Dealer not only to protect your warranty, but to protect All batteries are isolated from each other by a battery isolator. -
Page 47: Dc Master Panel
DC power by automatically opening the circuit should a short or overload condition occur. The resettable circuit breakers protect the system receiving the DC power by automatically opening the circuit should a short or overload occur. 48 Cantius... -
Page 48: Dc Panel Circuit Breaker Functions
Put the breaker in the ON position to connect power to the salon and dinette light switches. DINETTE LIGHTS GALLEY Put the breaker in the ON position to connect power to the galley light switches. REFRIGERATOR Put the breaker in the ON position to connect power to the galley refrigerator. GALLEY 4-10 48 Cantius... - Page 49 This breaker connects power to the panel lights and metering. The breaker is connected to the +12-volt house METERING battery switch, bypassing the DC MAIN circuit breaker for continuous panel light settings and metering of panel components. Reset this breaker immediately if it is tripped. 4-11 48 Cantius...
- Page 50 Beneath Helm TRIM WNDLS BATT WIPER HORN ELEC SPOT U WTR HRDTP TABS MOTOR ROOF SEAT 12 VDC ELEX BRKRS ELEX PADAR CHART CHART SONAR SMART RADIO E120 E120 UNIT PILOT N SW ACC 1 MAIN UNIT CSR_480_002 4-12 48 Cantius...
-
Page 51: Us Stds 60 Hz (240V / 120V Ac)
Basic Systems Operation US Stds 60 Hz (240V / 120V AC) 51-E018D 4-13 48 Cantius... -
Page 52: Intl Stds 32 Amp (230V Ac)
Section 4 Intl Stds 32 Amp (230V AC) 51-E019 4-14 48 Cantius... -
Page 53: Ac Electrical System
AC POWER The circuit breakers’ function is twofold: they allow you to manually The standard AC electrical system in the 48 Cantius is wired for enable or interrupt a circuit by flipping the switch to ON or OFF, and 120/240V AC, 50-amp, single-phase, 60-hertz power. This allows the they also protect the system receiving the AC load by automatically system to have two lines, L1 and L2, at 120V AC and also 240V AC. - Page 54 ON position. Then check the AC/DC panel POWER SOURCE AVAILABLE indicator lights. The 120V AC LINE 1, V AC DOCKSIDE and 120V AC LINE 2 indicator lights should be ON. The REVERSED POLARITY light should be OFF. 4-16 48 Cantius...
-
Page 55: Ac Panel Circuit Breaker Functions
Put the breaker in the ON position to connect power to the port lower salon 120V AC outlets. STBD OUTLETS Put the breaker in the ON position to connect power to the starboard lower salon 120V AC outlets. 4-17 48 Cantius... - Page 56 Put the breaker in the ON position to connect power to the windshield defroster. DEFROSTER GRILL COCKPIT Put the breaker in the ON position to connect power to the cockpit grill. Refer to the Skipper’s Kit for grill operation instructions. 4-18 48 Cantius...
- Page 57 Cruisers Yachts or separation of the stringers or composite structure. This does deterioration of underwater components (h) statements and facilities without the prior written consent of Cruisers Yachts.
- Page 58 This Page Intentionally Left Blank 48 Cantius...
