380 Express Series
Table of Contents
1. Introduction........................................................................................................ 1-1
2. Model Specific Information............................................................................... 2-1
3. Controls and Indicators .................................................................................... 3-1
4. Basic Systems Operation ................................................................................. 4-1
V2569900 (Rev. 0)
380 Express Series
Advertisement
Chapters
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cruisers Yachts 380 express series
Summary of Contents for Cruisers Yachts 380 express series
- Page 1 380 Express Series Table of Contents 1. Introduction......................1-1 2. Model Specific Information................2-1 3. Controls and Indicators ..................3-1 4. Basic Systems Operation ................. 4-1 V2569900 (Rev. 0) 380 Express Series...
-
Page 2: Express Series
380 Express Series This Page Intentionally Left Blank 380 Express Series... -
Page 3: Table Of Contents
Warranty Information ........... 1-5 Skipper’s Kit ..............1-2 Dealership Responsibilities ..........1-5 Your Responsibilities ............1-5 Owner’s Manual ..............1-2 Warranty Service ............... 1-5 Safety................. 1-3 Safety Label Location Layout........1-6 Owner’s Manuals for Onboard Systems and Components............. 1-4 380 Express Series... -
Page 4: Welcome Aboard
The Skipper’s Kit contains the 380 Express Series owner’s manual, as well as information about onboard systems and components We wish to thank you for making our 380 Express Series your furnished by suppliers other than Cruisers Yachts. recreational choice for boating enjoyment. Extensive design and engineering research went into the development of all Cruisers Owner’s Manual... -
Page 5: Safety
Section 4 contains principles of operation for the major systems on the 380 Express Series. The following precautions are used throughout this manual. DANGER Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. -
Page 6: Owner's Manuals For Onboard Systems And Components
Cruisers Yachts. Depending on the options you choose, the kit may contain some or all of the following literature: •... -
Page 7: Warranty Information
Cruisers Yachts are located inside the Skipper’s owner’s manuals and service guides. Kit. Your Cruisers Yachts Dealer will go through these with you. It is your responsibility to fill out any warranty registration that may be Warranty Service required. -
Page 8: Safety Label Location Layout
FUEL VALVES NOTE: Valves Open When In Line With Flow OPERATION NORMAL: Open Outside Valves and Close Center EMERGENCY: Close Valve to Empty or Contaminated 380 Label Loc Tank and Open Center Do Not Open All Three Valves 380 Express Series... - Page 9 Rumble Seat - Optional ..........2-34 Sun Deck Lounge ............2-35 Fuel Tanks ..............2-16 Engine Room Access..........2-36 Fuel Crossover Assembly - Gas......... 2-18 Fuel Crossover Assembly - Diesel ......2-19 Forward Engine Room Bulkhead - V-Drive....2-20 380 Express Series...
-
Page 10: Specifications
Dead Rise ................16 Degrees Bridge Clearance with Arch ..........11'0" / 3.3 m Bridge Clearance without Arch .........8'6" / 2.59 m Sleeping Accommodations ........... 4 persons *Weights are estimates and can vary from options and equipment added. 380 Express Series... -
Page 11: Deck Hardware General Layout
Swim Ladder Port Grab Rail Access Door Access Door Washdown Shower System Starboard Grab Rail Cockpit Courtesy Light Table Base Chain Snubber Drink Holder Bow Roller Spotlight Sun Deck Lounge Purple = optional equipment 29 27 26 48-R006D 380 Express Series... -
Page 12: Interior General Layout - Stereo
Section 2 INTERIOR GENERAL LAYOUT - STEREO 1. TV, 15" 2. DVD Player 3. CD Changer 4. Stereo Amplifier 5. Speaker 6. Stereo 7. TV, 20" 8. DVD Player Purple = optional equipment 48-R010B 380 Express Series... -
Page 13: Cockpit Stereo/Entertainment Plan Layout
Model Specific Information COCKPIT STEREO/ENTERTAINMENT PLAN LAYOUT 1. Speaker 2. Subwoofer 3. Speaker 4. Stereo Remote 5. TV, 20" Purple = optional equipment 48-R010BA 380 Express Series... -
Page 14: Cockpit Light And Outlet Plan Layout
Section 2 COCKPIT LIGHT AND OUTLET PLAN LAYOUT 1. Courtesy Light 2. Cockpit Light Switch 3. Dual Receptacle Box, GFCI 48-R008D 380 Express Series... -
Page 15: Interior Light And Outlet Plan Layout
4. Fluorescent Light 5. Reading Light 6. Overhead Light 7. Fluorescent Light 8. Dual Receptacle Box 9. Dual Receptacle Box, GFCI 10. 1-Module Switch 11. 2-Module Switch 12. 3-Module Switch 13. 2-Module Switch 14. 1-Module Switch 48-R008DA 380 Express Series... -
Page 16: Head Ventilation Layout
Section 2 HEAD VENTILATION LAYOUT 1. Blower 2. Vent 3. Vent Hose 48-R022B 380 Express Series... -
Page 17: A/C Ducting Layout And Plan
9. A/C Unit Plenum to ASR 10. Galley Plenum to FSR 11. Galley Plenum to Galley 12. A/C Unit Plenum to Galley Plenum 13. A/C Unit to A/C Unit Plenum 12 2 11 3 1 9 6 13 PLAN VIEW 48-R009D 380 Express Series... -
Page 18: Plumbing Hardware
22. Head Drain 23. Galley Drain 7. Faucet High Water Alarm 24. Waste Tank Purple = optional equipment Galley Faucet 16. Float Switch 1 20 4 3 9 19 10 12 2 14 27 28 48-R002D 2-10 380 Express Series... -
Page 19: Gas Engine General Layout And Genset - V-Drive Models
11. Port Tank Feed to Crossover 12. Crossover to Port Engine 13. Starboard Tank Feed to Crossover 14. Crossover to Starboard Engine 15. Port Tank Genset Feed to Genset 16. Genset Anti-Syphon = optional equipment Purple 48-R012D 2-11 380 Express Series... - Page 20 12. Starboard Tank Feed to Crossover 13. Crossover to Starboard Engine PROFILE 14. Port Tank Genset Feed to Genset STARBOARD ENGINE FUEL LINES 15. Genset Anti-Syphon Purple = optional equipment PORT PROFILE GENSET FUEL LINES 48-R012DA 2-12 380 Express Series...
-
Page 21: Engine Room General Layout - V-Drive
9. Water Heater 10. Trim Pump 11. Generator 12. Battery Box – 12V Deep Cycle 13. Battery Box – 12V Cranking 14. Generator Muffler 15. Terminal Bar 16. Oil Exchange System Purple = optional equipment 15 13 48-R001DA 2-13 380 Express Series... -
Page 22: Engine Room General Layout - Stern Drive
5. Engine Room Battery Block-Off 6. Seacock/Thru Hull 7. Genset Muffler 8. Genset Strainer 9. Water Heater 10. Extinguisher 11. Trim Tabs Pump 12. Oil Exchange System 13. Engine Room Panel 14. Generator Purple = optional equipment 48-R011D 2-14 380 Express Series... -
Page 23: Fuel Tank Fittings
ENGINE FEED - MERC W/O CROSSOVER 1. Elbow 2. Anti-Syphon Valve 3. Elbow 4. Elbow 5. Hose, Barb 6. Anti-Syphon Valve ENGINE FEED - VOLVO W/CROSSOVER ENGINE FEED - VOLVO W/O CROSSOVER FUEL TANK VENT GENSET FEED 48-R026B 2-15 380 Express Series... -
Page 24: Fuel Tanks
Section 2 FUEL TANKS 1. Plug Purple = optional equipment 48-R024B 2-16 380 Express Series... - Page 25 Model Specific Information FUEL TANKS (CON’T.) 1. Port Fuel Tank or Starboard Fuel Tank 2. Neoprene 3. Soundfoam 48-R025B 2-17 380 Express Series...
-
Page 26: Fuel Crossover Assembly - Gas
Section 2 FUEL CROSSOVER ASSEMBLY - GAS 1. Ball Valve 2. Tee 3. Nipple 4. Elbow 5. Elbow 6. Hose, Barb 7. Crossover Mounting Board 48-R001B 2-18 380 Express Series... -
Page 27: Fuel Crossover Assembly - Diesel
4. Bolt 5. Fuel Hose 6. Fuel Hose 7. Valve Bracket 8. Mounting Board 9. Washer 10. Hose, Barb 11. Elbow 12. Hose Clamp 13. Hose Clamp 14. Hose, Barb 15. Elbow 16. Hose, Barb 99-R007C 2-19 380 Express Series... -
Page 28: Forward Engine Room Bulkhead - V-Drive
FORWARD ENGINE ROOM BULKHEAD - V-DRIVE 1. Blower/Mounting Board 2. Extinguisher 3. Engine Room Electrical Panel 4. Battery Switch Panel 5. Breaker Panel 6. Hatch Breaker Panel 7. Battery Charger 8. Terminal Block 9. Terminal Bar 48-R001D 2-20 380 Express Series... -
Page 29: Gas Engine General Layout And Genset - I/O Models
11. Port Tank Feed to Crossover 12. Crossover to Port Engine 13. Starboard Tank Feed to Crossover 14. Crossover to Starboard Engine 15. Port Tank Genset Feed to Genset 16. Genset Anti-Syphon Purple = optional equipment 48-R010DA 2-21 380 Express Series... - Page 30 6. Crossover, Gas 14. Crossover to Starboard Engine 7. Port Fuel Tank Vent Hose 15. Port Tank Genset Feed to Genset 8. Starboard Fuel Tank Vent Hose 16. Genset Anti-Syphon 3 10 5 16 15 48-R010D 2-22 380 Express Series...
-
Page 31: Engine Room Electrical Panel
Model Specific Information ENGINE ROOM ELECTRICAL PANEL 1. Battery Switch Panel 2. Battery Charger 3. Hatch Breaker Panel 4. Engine Room Breaker Panel 48-R001DB 2-23 380 Express Series... -
Page 32: Engine Room Bulkhead
3. Fire Extinguisher 4. Oil Exchange System 5. Electrical Panel 6. Battery Switch Panel 7. Engine Room Breaker Panel 8. Hatch Breaker Panel 9. Battery Charger 10. Terminal Block 11. Terminal Bar Purple = optional equipment 48-R011DB 2-24 380 Express Series... -
Page 33: Freshwater Layout
5. Cockpit Faucet 14. Water Tank Fill Hose 6. Washdown Shower System 15. Water Tank Vent Hose 7. Head Faucet 16. Cold Water Hose 8. Galley Faucet 17. Hot Water Hose 9. Shower Mixer 17 16 48-R002DG 2-25 380 Express Series... - Page 34 19. Water Tank Transfer Hose 20. Elbow 21. Adapter 22. Shower Mixer 23. Tee 24. Vent 25. Water Deck Plate 26. Head Faucet 27. Galley Faucet 28. Head 29. Hot Water Line 30. Cold Water Line 31. Adapter 48-R002DA 2-26 380 Express Series...
-
Page 35: Waste Layout W/Macerator
2. Head 3. Waste Deck Plate 4. Vent 5. Thru Hull Fitting/Seacock/Elbow 6. Macerator Pump 7. Waste Tank Pump-Out Hose 8. Waste Tank Vent Hose 9. Head Hose 10. Macerator Hose Purple = optional equipment 48-R002DB 2-27 380 Express Series... - Page 36 7. Head to Waste Tank Hose 8. Elbow 9. Elbow 10. Adapter 11. Macerator 12. Macerator Hose 13. Elbow 14. Seacock 15. Thru Hull Fitting 16. Waste Tank 17. Hose Clamp 18. Elbow 19. Vent Hose 20. Vent 17 18 48-R002DC 2-28 380 Express Series...
-
Page 37: Waste Layout W/O Macerator
Model Specific Information WASTE LAYOUT W/O MACERATOR 1. Waste Tank 2. Head 3. Waste Deck Plate 4. Vent 5. Waste Tank Pump-Out Hose 6. Waste Tank Vent Hose 7. Head Hose 48-R002DD 2-29 380 Express Series... -
Page 38: Raw Water Layout
20. A/C Raw Water Hose 5. Strainer 13. Head Sink Drain Hose 6. Air Conditioning Pump 14. Galley Sink Drain Hose 7. Air Conditioner 15. Head Shower Drain Hose 8. Shower Sump Pump 16. Shower Sump Pump-Out Hose 48-R002DE 2-30 380 Express Series... -
Page 39: A/C Plumbing Layout
6. Air Conditioner Pump 7. Elbow 8. Raw Water Pickup Hose 9. Elbow 10. Basket Strainer 11. Elbow 12. Hose Clamp 13. Adapter 14. Seacock 15. Thru Hull Intake 16. Hose Clamp 17. Shower Sump Pump 48-R002DF 2-31 380 Express Series... -
Page 40: Dinette Tables
The screen or shade will lock into position when it is stowed or when in use. Make sure to hold the screen or shade hand guide when opening or stowing to prevent the screen or shade from returning to its stowed position too quickly. 2-32 380 Express Series... -
Page 41: Aft Settee
A and B by lifting cushion B first, then A. Place the cushions onto the supports, making sure the pins on the aft support To close the lounge, pull the upper strap while guiding the lounge position the cushions. closed. CSR_360_007 CSR_360_003 2-33 380 Express Series... -
Page 42: Rumble Seat - Optional
CARBON MONOXIDE AND SPINNING PROPELLER HAZARD Exposure to carbon monoxide or a spinning propeller will cause death or serious injury. DO NOT use the rumble seat when the engines are running. CSR_360_002 For models with optional rumble seat. 2-34 380 Express Series... -
Page 43: Sun Deck Lounge
WARNING OBSTRUCTED VISIBILITY HAZARD Obstructed visibility can cause death or serious CSR_360_006 injury. Maintain clear visibility at all times. Return the backrests to the DOWN position before getting underway. For models with optional foredeck chaise lounge. 2-35 380 Express Series... -
Page 44: Engine Room Access
CAUTION The engine hatch is heavy and may require more than one person to lift. When lifting the hatch, position one person at each end and lift straight up. 2-36 380 Express Series... -
Page 45: Controls And Indicators
12-Volt Outlet ..............3-3 Throttle Controls ..............3-6 Stereo Remote..............3-3 Ignition Switches..............3-6 Switch Panel (Blowers, Battery Link) ......... 3-3 Helm Wheel Tilt ..............3-6 Switch Panel (Lights, Battery Parallel) ....... 3-3 VHF Radio ................. 3-4 380 Express Series... -
Page 46: Dash Panel Layout
Section 3 DASH PANEL LAYOUT 48-R007D 380 Express Series... -
Page 47: Dash Panel Components
Push once to turn on the navigation/anchor lights. Push again to turn off the navigation lights and the anchor light will remain on. Push again to turn off the anchor light. The LED will turn on when either light is active. 380 Express Series... -
Page 48: Vhf Radio
RPMs are approximately one-half of engine crankshaft RPMs. Refer energized, connecting the two cranking batteries in parallel. When it is to your engine owner’s manual for the appropriate engine speed. released, the solenoid is deenergized. This function should be used 380 Express Series... -
Page 49: Plotter Color Display
Refer to your engine owner’s manual for Use this gauge in combination with the trim switches located in the details, and see your Cruisers Yachts Dealer for more information. throttle control. TEMPERATURE GAUGES - ENGINE 14 - Plotter Color Display These gauges indicate cooling water temperature inside the engines. -
Page 50: Switch Panel
The throttle control lever for the port engine is the port side lever and the throttle control lever for the starboard engine is the starboard lever. NEUTRAL is at the center, FORWARD is forward (away from you) one detent and REVERSE is aft (toward you) one detent. 380 Express Series... -
Page 51: Basic Systems Operation
AC Panel Circuit Breaker Functions ......... 4-21 Strut and Cutlass Bearing - Inboards, V-Drives ....4-6 Propellers ................4-6 Fuel System (Crossover Valve) ........4-8 Steering System............. 4-9 Steering Wheel ..............4-9 Rudder - Inboards, V-Drives ........... 4-10 380 Express Series... -
Page 52: Working Deck
Section 4 WORKING DECK 48-R005B WORKING DECK 380 Express Series... -
Page 53: Handling Dock And Mooring Lines
• Fasten the bow line to the bow cleat and pull forward at about a 45° angle to keep the yacht from moving astern. • Fasten the stern line to an “after” cleat and pull astern at about a 45° angle to keep the yacht from moving forward. 380 Express Series... -
Page 54: Power Train
Each engine is cooled by seawater entering the yacht through a seacock in the hull bottom. The water enters the engine through the engine water jacket and is returned to the sea through the exhaust system. 380 Express Series... -
Page 55: Transmission
SHAFT LOG AND SHAFT SEAL CAUTION The shaft seal and rubber hose should be inspected monthly for wear, leakage and deterioration. Excessive water entry, especially if unattended, could result in the submergence of the engine compartment, or the entire yacht. 380 Express Series... -
Page 56: Strut And Cutlass Bearing - Inboards, V-Drives
RPM at full throttle. NOTE Variations from average loadings, bottom condition and/or engine condition could call for a propeller change to achieve the performance desired. CUTLASS BEARING CSR161-7A 380 Express Series... - Page 57 Cruisers Yachts recommends that and engine failure. Cruisers Yachts recommends that you consult with, and employ the skills of, your...
-
Page 58: Fuel System (Crossover Valve)
4. With the port handle pointing aft and the starboard handle pointing outboard, both engines receive fuel from the starboard tank. 5. With the port handle pointing outboard and the starboard handle pointing aft, both engines receive fuel from the port tank. 380 Express Series... -
Page 59: Steering System
DO NOT operate your yacht if you suspect a problem 2. If both valves point toward one another, each engine receives fuel with the steering system. Have your Cruisers Yachts from its respective tank. The port engine receives fuel from the... -
Page 60: Rudder - Inboards, V-Drives
For center-to-center dimensions, contact your Cruisers Yachts Dealer. RUDDER BEARING AND SEAL 51-1/4" (1.30 m) 48-13/16" (1.24 m) CENTER TO CENTER CENTER TO CENTER OF RUDDER POSTS OF BALL JOINTS CSR173-59 CSR_360_004A 4-10 380 Express Series... -
Page 61: Trim Tabs
(cylinders) which lower the trim tabs. To raise the trim tabs, the rocker switch is moved which allows oil to flow from the actuator to the pump. TRIM TAB TRIM PUMP ROCKER SWITCHES SOLENOIDS TRIM TAB ZINC PLATE CSR164-15A 4-11 380 Express Series... -
Page 62: Electrical System
Any modifications to the system should always bonding system. be done by an authorized Cruisers Yachts Dealer not only to protect your warranty, but also to protect you All batteries are isolated from each other by a battery isolator. When from hazardous shock. -
Page 63: Dc Master Panel
DC power by automatically opening the circuit should a short or overload condition occur. The resettable circuit breakers protect the system receiving the DC power by automatically opening the circuit should a short or overload occur. 4-13 380 Express Series... -
Page 64: Dc Panel
MAIN MAIN LIGHTS STEREO/TV CABIN LIGHTS REFRIGERATOR CKPT LIGHTS REFRIGERATOR HEAD PORT STBD CKPT WASH/ FRESH WTR HOUSE SPARE PUMP HEAD PUMP BATTERY BANK SELECT MACERATOR/ SPARE SPARE LIGHT PANEL MONITORS STEREO/DVD SHOWER MEMORY SUMPS 48-E001D 4-14 380 Express Series... -
Page 65: Dc Panel Circuit Breaker Functions
Put the breaker in the ON position to turn on the accessory assigned to this circuit, if equipped. CO MONITORS This breaker is for the carbon monoxide detectors. STEREO/DVD This breaker is for the stereo/DVD memory. MEMORY 4-15 380 Express Series... - Page 66 There are three additional circuit breaker panels located in the yacht for localized functions. The panel locations CIRCUIT BREAKER and functions are shown. PANELS EPLEX PANEL LOCATED AT HELM PANEL LOCATED FORWARD IN ENGINE ROOM CSR_360-009 4-16 380 Express Series...
-
Page 67: Us Stds 2-30 Amp (120 Volts)
CHARGER OUTLETS AC LINE SELECT HEAD/CKPT REFRIGERATOR OUTLETS SHORE 1 SHORE 2 INTERIOR MICROWAVE OUTLETS WATER RANGE HEATER CKPT REFRIG-ICE AC/HTR SPARE AC PUMP/ CKPT GRILL/ SPARE SPARE CENTRAL VAC CKPT CLIMATE CONT/ SPARE SPARE 48-E002D 4-17 380 Express Series... -
Page 68: Intl Stds 2-30 Amp (220 Volts)
BATTERY SPARE CHARGER AC VOLTS CKPT GRILL/ SPARE CKPT CLIMATE CONT/ MICROWAVE SPARE RANGE POWER AVAILABLE GALLEY SHORE GENERATOR OUTLETS HEAD/CKPT OUTLETS INTERIOR OUTLETS WATER HEATER AC/HTR AC PMP/ SPARE CENTRAL VAC/ SPARE SHORE GENERATOR 48-E003D 4-18 380 Express Series... -
Page 69: Ac Electrical System
AC POWER The circuit breakers’ function is twofold; they allow you to manually The standard AC electrical system in the 380 Express Series Yacht enable or interrupt a circuit by flipping the switch on or off, and they is wired for 120/240 volts AC, 50 amps, single-phase, 60-hertz power. - Page 70 Disconnecting Shore Dockside Power: Switch the yacht DOCKSIDE 240/120V AC circuit breaker off. Switch the yacht dockside power circuit breaker off. Switch the shore dockside power circuit breaker off. The dockside power cable may then be disconnected. 4-20 380 Express Series...
-
Page 71: Ac Panel Circuit Breaker Functions
Switch the breaker on to connect power to the air conditioner water pump. The pump must be switched on when the salon air conditioner or the optional cockpit air conditioner is on. CENTRAL VAC/SPARE Switch the breaker on to connect power to the optional central vacuum cleaner. 4-21 380 Express Series... - Page 72 Section 4 This Page Intentionally Left Blank 4-22 380 Express Series...
- Page 73 Yachts and Cruisers Yachts obligation to repair or replace pursuant to this paragraph shall be at the discovering any defect and the selling dealer shall submit to Cruisers Yachts a service and parts request form sole discretion of Cruisers Yachts. This warranty does not include blisters or defects in the gelcoat that together with any documentation to support the claim.
- Page 74 This Page Intentionally Left Blank...
