Life Span Style User Manual

Hide thumbs Also See for Style:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
STYLE
USER'S
MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Style and is the answer not in the manual?

Questions and answers

Related Manuals for Life Span Style

Summary of Contents for Life Span Style

  • Page 1 STYLE USER’S MANUAL...
  • Page 2 This is HIGH-POWER item; please DO NOT USE THE SAME OUTLET WITH OTHER HIGH-POWER HOUSEHOLD APPLIANCE like air-conditioning etc. Please choose an outlet exclusively for the machine and make sure the fuse is 10A. Special tips: Before installation and operation, please read this operation manual carefully.
  • Page 3 cause over load . 13、 Turn off the power at wall outlet when the equipment is not in use. Do not pull on power lead to unplug always use the plug to remove from wall . IMPORTANT SAFETY PRECAUSTION 1. Plug the power cord of the treadmill directly into a dedicated grounded circuit carrying 10 amps. Grounding Instructions: This product must be grounded.

  • Page 4: Spare Parts List

    ASSEMBLY INSTRUCTIONS When you open the carton, you will find the below spare parts: Spare parts list: DES. Specification Nos. DES. specification Nos. main frame Lock washer lock washer S=13、14、15 5# Allen Wrench Bolt M8*16 Screw ST4.2*12 Left handle bar cover L Left handlebar cover R Right handle bar cover L Right handlebar cover R...
  • Page 5 ASSEMBLY STEP ONE： Open the carton， get out the above spare parts ， put the MAIN FRAME on the ground. ASSEMBLY STEP TWO: Pull up the computer and upright as arrow direction. Notice: When you pull up them, make sure the upright not press the wires in upright;...
  • Page 6 ASSEMBLY STEP FOUR: Use the 5# allen wrench, drill through the bolt (46) to Lock washer(66), then lock the Right upright (4) onto MAIN FRAME (1) ASSEMBLY STEP FIVE: Use the 5# allen wrench, drill through the bolt (46) to Lock washer(66), then lock the COMPUTER (64) onto R&L upright (3,4).

  • Page 7: Pulling Down

    FOLDING INSTRUCTION Pulling up: Support place A with hand, then pull up following the arrow direction, till hearing the sound that the cylinder (10) is locked into the round tube Pulling down: Support place A with hand , depress the place B of air pressure control bar, then base frame...

  • Page 8: Technical Parameter

    TECHNICAL PARAMETER This product must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped with a cord having an equipment-grounding conductor and a grounding plug.

  • Page 9: Window Display

    WINDOW DISPLAY: 1.“SPEED” window:Display speed, show range: 1.0-18KM/h. 2.“INCL” window：Show the incline, the incline range is 0-20 level; 3、“TIME” window:Show the running time, count from 0:00 to 99:59. When up to 99:59, The machine will stop smoothly and show ‘END’ in the computer; When you set the time count down, it will count down from the setting data to 0, when down to 0:00, the machine will stop smoothly and show ‘END’...

  • Page 10: Start-Up Quickly(Manual)

    count,after that ,press the START button to start this treadmill. 3．“START”button：when start the power and attach the magnet end of the safety pulling rope to the computer. Press the button at any time, it can start motor. 4. “STOP”button: press this button while running,it can stop motor and set program default; 5.

  • Page 11: Inner Install Program

    the STOP, the treadmill will stop. Inner install program Press “PROGRAM” button SPEED window will display P1-P12 to choose the program you like. Setting of running time, then the TIME window display glittering. Display the advance setting time10:00, press “SPEED+”, “SPEED-”, “INCLINE+”、 “INCLINE –“ to set up the exercise time what you need. Press “START”...

  • Page 12: Safety Lock Function

    TIME(MIN:SECOND) 0:00 15:00 5:00-99:00 0:00－99:59 INCLINE(LEVEL) 0-20 0-20 SPEED(K/h) 1.0-18 1.0-18 DISTANCE(K) 0.5-99.9 0.00－99.9 PULSE(hypo/min) 50-200 CALORIE(THERM) 10-999 0－999 BODY TESTER: At the beginning state, press “ PROGRAM” continuely entering FAT body fat tester, press “ MODE “ enter F-1、F-2、F-3、F-4、F-5 ( F-1 SEX, F-2 AGE, F-3 HEIGHT, F-4 WEIGHT, F-5 FAT TESTER ), Press “SPEED+”、“SPEED -”...

  • Page 13: Exercise Instructions

    Colse up the power: You can close up the power to stop the treadmill, it won’t be damaged at any time. Caution: 1. We recommend that you maintain a slow speed at the beginning of a session and hold on to the handrails until you become comfortable and familiar with the treadmill.

  • Page 14: Maintenance

    To tone muscle while on your Treadmill you will need to have the resistance set quite high. This will put more strain on our leg muscles and may mean you cannot train for as long as you would like. If you are also trying to improve your fitness you need to alter your training program.

  • Page 15: Every Week

    EVERY WEEK Clean underneath the treadmill, following these steps: • Turn off the treadmill with the on/off switch, then unplugs the power cord at the wall outlet. • Fold the treadmill into the upright position, making sure that the lock latch is secure.
  • Page 16 SERVICING: IF YOU FAIL TO COMPLY WITH LIFESPAN’S MAINTENANCE AND SERVICING STEPS ABOVE, YOU MAY VOID YOUR WARRANTY. IF YOU REQUIRE A SKILLED LIFESPAN REPRESENTATIVE TO UNDERTAKE ONE OF THE STEPS ABOVE, PLEASE EMAIL US AT lifespanfitness@hotmail.com. General Cleaning  Use a soft, damp cloth to wipe the edge of the belt and the area between the belt edge and frame.
  • Page 17 Use a soft, dry cloth to wipe the area between the belt and deck. Spread lubricant onto the inside surface of belt and deck evenly (make sure the machine is turned off and power is disconnected). Periodically lubricate the front and rear rollers to keep them at there peak performance.

  • Page 18: Belt Tracking Adjustment

    approximate 2-3 inches off the board. Belt Tracking Adjustment This treadmill is designed to keep the belt reasonably centred while in use. It is normal for some belts to drift near one side while the belt is running with no one on it. After a few minutes of use, the belt should have a tendency to centre itself.

  • Page 19: Parts List

    PARTS LIST...
  • Page 20 DESCRIPTION DESCRIPTION REMARK REMARK MAIN FRAME LEFT BOTTLE BRACKET RIGHT BOTTLE BASE FRAME BRACKET LEFT HANDLEBAR LEFT UPRIGHT COVER L LEFT HANDLEBAR RIGHT UPRIGHT COVER R COMPUTER BRACKET LOCK NUT M8*30 MOTOR BRACKET BOLT INCLINE MOTOR BRACKET LOCK NUT TURNING BUSHING LOCK NUT FRONT ROLLER BOLT...

  • Page 21: Troubleshooting Guide

    PARTS LIST PULSE UP WIRE PULE WITH SWITCH UP WIRE PULSE SPEED UP WIRE COMPUTER UP WIRE 1 COMPUTER UP WIRE COMPUTER MIDDLE WIRE COMPUTER BOTTOM WIRE LABEL SAFETY KEY SWITCH BOARD POWER WIRE SQUARE SWITCH OVERLOAD PROTECTER AC SINGLE LINE BROWN 150 AC SINGLE LINE BLUE 150...
  • Page 22 control board didn’t connected well or the transformer was burnt out. Check the each wire from computer to control board, make sure they are connected well. If the wire is destroyed , change it. If the above can not settle the problem, try to change a good transformer. 2、E01: Message failure.
