- Page 1 RLM4619SME PETROL LAWN MOWER Original Instructions Important! It is essential that you read the instructions in this manual before assembling, operating and maintaining this machine.
-
Page 2: General Safety Rules
English Thank you for buying a Ryobi lawn mower. ■ Use the right appliance. Do not use the lawn mower for any job except that for which it is intended. Your new lawn mower has been engineered and ■ Clear the work area before each use. Remove all manufacturer to Ryobi’s high standard for dependability,... -
Page 3: Maintenance
English running. ■ Check all nuts, bolts, and screws at frequent intervals for proper tightness to be sure the equipment is in safe ■ Do not leave the mower unattended while running. working condition. ■ Avoid holes, ruts, bumps, rocks, or other hidden ■... - Page 4 English SYMBOLS Important: Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOLS EXPLANATION Precautions that involve your safety. To reduce the risk of injury, user must read and understand operator’s manual before using this product.
- Page 5 English Set the throttle lever to max down against the handle. Pull the starter cord until the engine runs. The rear grass catcher Mulching plug option The guaranteed sound power level is 98 dB. The guaranteed sound pressure level is 86 dB. C-Tick compliance.
-
Page 6: Specifications
English SPECIFICATIONS WARNING Do not attempt to modify this product or create Engine 190cc OHV accessories not recommended for use with this product. Any such alteration or modification is misuse and could No-load speed 2,700/min. (RPM) result in a hazardous condition leading to possible Cutting path 460 mm serious personal injury. -
Page 7: Operation
English ASSEMBLING THE GRASS CATCHER FILLING THE TANK See figure 4. See figure 6. ■ Snap the filter in place on the inner side of the top cover. WARNING ■ Snap together the top and bottom parts of the grass Always shut off engine before fuelling. -
Page 8: Starting/Stopping The Mower
English ■ Remove the oil cap/dipstick. Wipe clean and reseat in ■ Repeat on the other side of the handle. oil fill hole but do not screw in. MOWING TIPS ■ Remove the oil cap/dipstick again and check oil level. Add oil as needed. -
Page 9: Replacing The Cutting Blade
English ■ Turn on the water supply. MAINTENANCE ■ Start the mower and run at full revolutions. WARNING ■ Run the engine in place for approximately 30 seconds. When servicing, use only identical replacement parts. ■ Shut off the engine. Use of any other parts may create a hazard or cause ■... -
Page 10: Replacing Wheels
NOTE: An improperly tightened spark plug will become ■ Replacement air filter elements can be purchased very hot and could damage the engine. from Ryobi through your local Bunnings Special ■ Reinstall spark plug boot. Orders desk. STORING THE MOWER... -
Page 11: Troubleshooting
English ■ If not using fuel stabilizer, allow the engine to run until ■ Do not store near corrosive materials such as fertilizer the mower is completely out of petrol. or rock salt. ■ Once the engine has stopped, allow the blade to come To lower the handle before storing to a complete stop and disconnect the spark plug wire. - Page 12 Techtronic Industries (Australia) Pty. Ltd. Level 1, 660 Doncaster Road Doncaster, VIC 3108, Australia Techtronic Industries New Zealand Ltd. 18-26 Amelia Earhart Ave Mangere, Auckland 2022, New Zealand 20130703v3...
