Summary of Contents for Ryobi RLM4619SME
- Page 1 RLM4619SME PETROL LAWN MOWER Original Instructions Important! It is essential that you read the instructions in this manual before assembling, maintaining and operating this machine.
-
Page 2: Product View And Features
RLM4619SME NOTE: Illustrations are for representation and reference purposes only and may vary from actual product and specification. Fig. 2 Fig. 1 Fig. 6 RLM4619SME Fig. 9... -
Page 3: General Safety Rules
English Thank you for buying a Ryobi lawn mower. ■ Use the right appliance. Do not use the lawn mower for any job except that for which it is intended. Your new lawn mower has been engineered and ■ Clear the work area before each use. Remove all manufacturer to Ryobi’s high standard for dependability,... - Page 4 English ■ Avoid holes, ruts, bumps, rocks, or other hidden ■ When not in use, mower should be stored in a well- objects. Uneven terrain could cause a slip and fall ventilated, dry, locked up place out of the reach of accident.
- Page 5 English SYMBOLS Important: Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOLS NAME EXPLANATION Safety Alert Precautions that involve your safety.
- Page 6 English Set the throttle lever to max down against the handle. Pull the starter cord until the engine runs. The rear grass catcher Mulching plug option The guaranteed sound power level is 98 dB. The guaranteed sound pressure level is 86 dB. C-Tick compliance.
-
Page 7: Specifications
English SPECIFICATIONS WARNING Do not attempt to modify this product or create Engine 190cc OHV accessories not recommended for use with this product. Any such alteration or modification is misuse and could No-load speed 2,700/min. (RPM) result in a hazardous condition leading to possible Cutting path 460 mm serious personal injury. -
Page 8: Operation
English ■ Snap together the top and bottom parts of the grass WARNING catcher. Always shut off engine before fuelling. Never remove the cap of the fuel tank or add petrol to a machine with a INSTALLING THE GRASS CATCHER running or hot engine. -
Page 9: Starting/Stopping The Mower
English Add oil as needed. engine. Such objects could be accidentally thrown by the mower in any direction and cause serious personal injury to the operator and others. STARTING/STOPPING THE MOWER ■ For best performance, always cut off one-third or less See figure 6. -
Page 10: Maintenance
English ■ Turn off the water supply. MAINTENANCE ■ Inspect the underside of the mower deck for WARNING cleanliness, and repeat the cleaning procedure if desired. When servicing, use only identical replacement parts. Use of any other parts may create a hazard or cause REPLACING THE CUTTING BLADE product damage. - Page 11 English The recommended torque for the disc bolt is ■ Remove the oil fill cap/dipstick. 48–55 Nm (35–40 ft.lb.). ■ Tip mower onto its side and allow oil to drain from the NOTE: It is not recommended to perform blade sharpening oil fill hole into an approved container.
-
Page 12: Troublshooting
English dry, and out of the reach of children. WARNING ■ Do not store near corrosive materials such as fertilizer Do not store the lawn mower with petrol in the tank or rock salt. inside a building where fumes may reach an open flame To lower the handle before storing or spark. - Page 13 Techtronic Industries (Australia) Pty. Ltd. Level 1, 660 Doncaster Road Doncaster, VIC 3108, Australia Techtronic Industries New Zealand Ltd. 27 Clemow Drive Mt. Wellington, Auckland 1060, New Zealand...
