OPTION 7-4. EUROPEAN OPTIONS.
74-1 Flash the LED relating to a zone if that zone if it is OPEN when the
control panel is in an UNSET condition
74-2 ⊗
2 Stage Communicator output
74-3 10 minute auto isolate of an open zone when set.
74-4 BLOCKSCHLOSS - German Setting Method.
BELLBOX CONNECTIONS
ACTIVE 5 PANEL
SONADE 2000
FLASHGUARD XL+
STARLIGHT 2000
ACTIVEGUARD
ACTIVE GUARD 3
SECURIGUARD
NOVA GUARD 2+T
SPIRIT AU1000
GENERAL
TERMINALS
You MUST check your bellbox instructions to see if you are required to make
any other links.
These terminals are given in good faith but without warranty. The manufacturers
of the bellboxes shown above have the right to change terminals without
notification to C&K systems or to you, the end user.
This product should only be used for domestic, commercial and
light industrial use only.
C&K Securitech
ST- S-
STROBE- B
STROBE- SIREN-
ST -R
STB- -S
ST- -SW
STROBE- S-
STROBE- S-
STB- TRG-
STROBE SIREN
TRIG - TRIG -
13
LEFT HAND
BELL+
TAMPER
D A
SUPPLY+ SUPPLY-
+H -H
+12V -12V
V+ V-
SUPPLY+ SUPPLY-
12V+ 12V-
HOLD HOLD
OFF + OFF -
SUPPLY+ SUPPLY-
RIGHT HAND
TAMPER
T
TAMPER
OUT
RTN
RIGHT
HAND
TAMPER
RET
LEFT
HAND
TAMPER
R
RTN-
TAMPER
RETURN
