G
I
ENERAL
NFORMATION
Specifications*
System Frequency Response
73–20,000 Hz ± 3db
Dispersion
Horizontal: 30 Degrees
Sensitivity: 89 dB/2.83 volts/meter
Impedance
6 ohms. Compatible with 4, 6, and 8 Ohm rated amplifiers.
Crossover Frequencies
460Hz, 4000Hz
Components
Air core coils
Tweeter Type
1" x 1.4" (2.6cm x 3.6cm) Folded Motion Transducer with
5.25" x 1.75" (13.3cm x 4.4cm) diaphragm.
Midrange Type: CLS™ Electrostatic
Woofer Type
Two 5.25" (13.4 cm) cast basket, aluminum cone with extended
throw driver assembly, non-resonant asymmetrical chamber format
Power Handling: 150 watts
Recommended Amplifier Power: 20–300 watts per channel
Signal Inputs: Custom binding posts
Weight: 22.5 lbs. each (10.2 kg)
Size (with stand)*
10" h × 29.75" w × 9" d
(25.4 h × 75.6 w × 22.9 d cm)
Size (with feet)
7.6" h × 29.75" w × 9" d
(19.3 h × 75.6 w × 22.9 d cm)
Size (with wall bracket)
7.3" h × 29.75" w × 7.9" d
(18.6 h × 75.6 w × 20.1d cm)
*Specifications are subject to change without notice.
30
General Information
Warranty and Registration
Your speaker is provided with an automatic Limited 90 Day
Warranty coverage. You have the option, at no additional charge,
to receive a Limited 5 Year Warranty coverage. To obtain the
Limited 5 Year Warranty coverage you need to complete and
return the Certificate of Registration, included with your speak-
er, and provide a copy of your dealer receipt, to MartinLogan
within 30 days of purchase. For your convenience MartinLogan
also offers online warranty registration at www.martinlogan.com.
MartinLogan may not honor warranty service claims unless we
have a completed Warranty Registration card on file! If you did
not receive a Certificate of Registration with your new speaker
you cannot be assured of having received new units. If this is the
case, please contact your authorized MartinLogan dealer.
Serial Number
Motif X's serial number is located near the binding posts.
Service
Should you be using your MartinLogan product in a country other
than the one in which it was originally purchased, we ask that
you note the following:
1 The appointed MartinLogan distributor for any given
country is responsible for warranty servicing only on units
distributed by or through it in that country in accordance
with its applicable warranty.
2 Should a MartinLogan product require servicing in a coun-
try other than the one in which it was originally purchased,
the end user may seek to have repairs performed by the near-
est MartinLogan distributor, subject to that distributor's local
servicing policies, but all cost of repairs (parts, labor, trans-
portation) must be borne by the owner of the MartinLogan
product.
3 If, after owning your speaker for six months, you relocate
to a country other than the one in which you purchased
your speaker, your warranty may be transferable. Contact
MartinLogan for details.
