Summary of Contents for EIRECO 740
- Page 1 Wood Burning Stoves EIRECO Wood Burning Stove 740C EIRECO Wood Burning Stove 740 Designed and manufactured in Ireland...
-
Page 2: Important Safety Note
When using the EIRECO stove in situations where children, aged and/or infirm persons are present a fireguard must be used to prevent accidental contact with the stove. -
Page 3: Table Of Contents
Maintenance: Seasonal Cleaning of Stove Warning Note Fire Safety Glass Carbon Monoxide Alarm/Detector Exploded View Illustration EIRECO 740 with part numbers Exploded View Illustration EIRECO 740C with part numbers Installation Checklist Warranty and company address Test Certificate EIRECO Wood Burning Stove Installation and Operating Instructions... -
Page 4: Installation And Operating Instructions: General
GENERAL When installing operating and maintaining your EIRECO Wood Burning Stove please conform to standards of fire safety. Read these instructions carefully before commencing the installation. Failure to do so may result in damage to persons or property. Consult your local Authority office and your insurance company to determine what regulations are applicable. -
Page 5: Important Warning
6 inches. CHIMNEY The EIRECO Wood Burning Stove is a radiant room heater and must be connected to a chimney of the proper size and type. The chimney must have a cross-sectional area of at least 124 cm 20 inches or a diameter of at least 150mm or 6 inches. -
Page 6: Down Draughts
Building Regulations and B.S. 8303: Part 1. Air vents in internal walls should not communicate with bedrooms, bedsits, toilets, bathrooms or rooms containing a shower. Air vents traversing cavity walls should include a continuous EIRECO Wood Burning Stove Installation and Operating Instructions... -
Page 7: Permanent Air Vent
Advise the user what to do should smoke or fumes be EIRECO Wood Burning Stove Installation and Operating Instructions... -
Page 8: Location
The customer should be warned to use a fire guard to BS 6539 in the presence of children, aged and/or infirm persons. LOCATION There are several conditions to be considered in selecting a location for your EIRECO Wood Burning Stove. a. Position in the area to be heated – central locations are usually best. -
Page 9: Stove Dimensions And Illustration
(3) when stoking or fuelling. STOVE DIMENSIONS and ILLUSTRATION Note: Dimensions are specified in millimetres and might be subject to a slight +/- variation. EIRECO Wood Burning Stove Installation and Operating Instructions... -
Page 10: Primary Air Setting
Note: Only use seasoned wood with a moisture content of less than 20%! If the wood moisture content is more than 20%, much of the EIRECO Stove’s heating value will be wasted in burning off the excess moisture. The stove output levels are assessed on Wood briquettes and seasoned wood of good quality. -
Page 11: Output And Efficiency Data
Mean CO Emission (at 13% O 0.16 Mean Flue Gas Temperature C Flue Gas Mass Flow g/s Appliance Weight kg EIRECO Wood Burning Stove 740 C Performance Results Output and Efficiency All efficiencies in table are Net values Wood logs Total Efficiency % 89.5... -
Page 12: Important Notes
IMPORTANT NOTES Now that your EIRECO Wood burning stove is installed we would like to give you some advice on how to get the best results from it. Please take some time to read the operating instructions, which will be of great benefit to you. -
Page 13: Lighting & Re-Fuelling Stove
2. Open glass door (3) and insert wood logs or wood briquettes. 3. Close the glass door (3) and re-adjust spin valves (2). Please remember to always wear appropriate protective stove gloves when re-fuelling or touching the stove! EIRECO Wood Burning Stove Installation and Operating Instructions... -
Page 14: De-Ashing
General cleaning must be carried out when the stove is cool. DO NOT USE ABRASIVE PADS OR OVEN CLEANSERS CONTAINING ACIDS ON THIS STOVE. ENSURE THAT THE CLEANSER MANUFACTURERS INSTRUCTIONS ARE ADHERED TO. EIRECO Wood Burning Stove Installation and Operating Instructions... -
Page 15: Maintenance: Seasonal Cleaning Of Stove
THIS SHOULD ONLY BE CARRIED OUT BY A QUALIFIED PERSON OR A CHIMNEY SWEEP. For the purpose of cleaning your EIRECO Wood Burning Stove is fitted with a removable top plate (6). The top plate (6) can be removed by untightening and removing the screws thereon. -
Page 16: Warning Note
For you own safety these must be kept clean at all times. FIRE SAFETY To provide reasonable fire safety EIRECO highly recommends: The installation of smoke detectors. A conveniently located class ‘A’ fire extinguisher to contend with small fires resulting from burning embers. -
Page 17: Glass
Replace glass only with ceramic glass 5mm or 0.2 inches thick. Carbon Monoxide Alarm/Detector EIRECO highly recommends the fitting of a Carbon Monoxide Alarm/Detector in the same room as the EIRECO Wood Burning Stove, this is a requirement under Irish/UK/European Building Regulations. -
Page 18: Exploded View Illustration Eireco 740 With Part Numbers
EIRECO WOOD BURNING STOVE 740 - EXPLODED VIEW Part No. 6: Removable Top Plate Part No. 3: Removable Glass door on hinge Part No. 4: Removable Ash-Pan Part No. 1: Fire Box Part No. 5: Exit Flue Part No. 2:... -
Page 19: Exploded View Illustration Eireco 740C With Part Numbers
EIRECO Wood Burning Stove 740C - Exploded View Part No. 6: Removable Top Plate Part No. 4: Removable Ash-Pan Part No. 5: Exit Flue Part No. 3: Removable Glass door on hinge Part No. 1: Fire Part No. 2: Part No. 7:... -
Page 20: Installation Checklist
The room in which the appliance is located should have an air vent of adequate size to support correct combustion (see Ventilation & Combustion Air Requirement Section for specific details). Warning: Use only replacement parts recommended by EIRECO. Making unauthorised modifications or using unauthorised parts will invalidate your guarantee and may cause damage or injury. -
Page 21: Warranty And Company Address
• The Warranty does not cover damage caused to the stove while in transit. If this occurs, do not operate the stove and contact your courier and/or dealer. • It is at EIRECO’s discretion whether to repair or replace the product. All shipping costs are to be paid by the consumer. -
Page 22: Test Certificate
EIRECO Wood Burning Stove Installation and Operating Instructions...
