Math Tools
Compass
You can move, size, and rotate the Compass. The Compass resizes itself to scale within the
Annotation window. The Colored tip draws the circle or arc within the Annotation Window. The
Clear Tip remains stationary so the arc or the circle can be drawn.
To change the radius of the compass, move your cursor to the colored tip until the Compass
displays the arrow. You can then drag that end to the desired radius.
1. Click the Compass icon.
2. Click the top of the Compass to move it around the Annotation Window.
3. To change the color of the pen tip, select from the Workspace palette at the bottom of
the Annotation Window.
4. Click the Compass icon to close the Compass and remove it from the Annotation
Window.
Draw an Arc with the Compass
1. Move your cursor to the colored tip until the Compass displays the arrow.
2. Click and drag the tip to the desired area. The tip changes back to the draw cursor.
3. Move the cursor to draw the arc. Workspace displays the
within the Annotation Window.
Workspace Level 1 Training Workbook
The Compass opens within the Annotation Window.
arc
