Shelves - GE SidebySide2Q2224 Use And Care And Installation Manual

Bins on Fresh Food Compartment Door
Adjustable bins cun easily be carried from refrigerator to work area.
To remove:
Lift bin straight up until
mounting hooks disengage.
To replace or relocate:
Select desired shelf height.
engage bin's hook in slots
on the tracks of the door,
and push in. Bin will lock
in piace
Shelves in Freezer Compartment
Shelves in the freezer are easily removed and replaced
(on some models).
To remove:
1. While pressing tabs on the shelf
supports on right wall, lift the.
shelf out of grooves in the supports.
2. Pull shelf sideways until the
on left wall.
Deep Door Shelves in the Freezer Compartment
Detachable shelf extenders deepen and enclose fixed
door shelves, providing more storage room and greater
storage flexibility.
To remove: Lift the shelf extender straight up until the
mounting hooks come out of the slots in the door.
To replace: Line up the hooks with the slots in the door
and push in and down.
TM
Quick Shelf Swing Down Shelf
This swing-down shelf
provides extra shelf space when
needed.
When you want to use it, pull
the shelf forward as far as it goes,
then lower it. Be careful not to
force it down before it is pulled
out all the way.
To raise it back into position, pull the shelf forward, push it up and
slide it back fully until it stops.
10
(continued)
The divider (on some models) helps prevent tipping, spilling or
sliding of small items stored on the door shelf. Place index finger and
middle finger on either side of the divider near the front and simply
move it back and forth to fit your needs.
To replace shelves
Insert the rods into the holes. Then,
while pressing the tabs, lower the
shelf into the grooves in the supports.
Be sure the shelf wire is fully inserted
into grooves.
If shelf supports at desired level on
right wall do not have tabs, merely
lower shelf into place on supports.
(on some models)
(on some models)
—-
—
