REAR PANEL OVERVIEW

3
4
WARNING
2-4
5
The CX-7 rear panel is shown above. The CX-5 rear
panel is shown on page 2-6. The rear panels are
similar, except the CX-7 amplifier includes two
additional channels.
External wiring connected to connectors marked with the
icon pictured at the left requires installation by a
qualified person or the use of ready-made leads or cords.
Lexicon
7
8
6 2 1
