- Page 1 ENG_111379 User's Manual Digital HD Satellite Receiver CCR545 English Please read the entire manual thoroughly and retain it for future reference. STB_CityCom_Sat_111379_CCR545_Eng.indd 1 2010-08-03 8:26:50...
-
Page 2: General Safety
General Safety Cautions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : To reduce the risk of electrical shock, do not remove the cover. No user serviceable parts inside. Refer any servicing to qualified Service personnel. Read this manual carefully before using the product. The cautions described below contain important information about safety, and are categorized into: Danger, Warning and Notice. - Page 3 Cautions Warning If the product is mishandled, the user might receive a serious or minor injury. Damage or loss to the user’s property might also result. • The product must not be exposed to water or liquid. If the apparatus is exposed to drips or splashes, it might cause a problem that cannot be repaired. • Do not repair, disassemble or modify this apparatus yourself. It might be seriously damaged, possibly beyond repair. • Turn off the power and unplug the power cord as quickly as possible during electric storms. They might damage the apparatus. • Remove the antenna’s power plug from the outlet as quickly as possible during electric storms, or the apparatus might be damaged.
-
Page 4: Table Of Contents
Contents General Safety ....................2 1. Functions and Installation ................ 5 1.1 Remote Control Unit ..............5 1.2 Front Panel ................7 1.3 Rear Panel ................. 7 1.4 CAM(Conditional Access Module) and Smart Card ..... 8 1.5 Connecting and Installation ..........9 2. Basic Operation ..................11 2.1 Basic Function Usage ............11 3. Main Menu Guide ..................12 3.1 Installation ................ -
Page 5: Functions And Installation
1. Functions and Installation 1.1 Remote Control Unit Basic functions 1. STANDBY Press to switch between operation and standby mode. 2. SUB-T Press to enable or disable subtitle. 3. TV/STB Press to switch between TV and Receiver mode. 4. TEXT Press to see the teletext by OSD. 5. -
Page 6: Pvr Functions
1.1 Remote Control Unit TV Control Buttons 1. TV STANDBY Press to turn on and off your TV. 2. TV Volume Press to increase or decrease the TV volume. 3. TV MUTE Press to enable or disable the TV audio temporarily. -
Page 7: Front Panel
1.2 Front Panel 1. STANDBY(POWER) 7. STOP Switch the receiver power "ON" or "OFF". To stop a recording or playback. 2. MENU 8. REC To see main menu. To record a programme. 3. EXIT 9. VFD Exit from parameter and cancel selected function. To display the current state, such as channel, time and 4. -
Page 8: Cam(Conditional Access Module) And Smart Card
1.4 CAM(Conditional Access Module) and Smart Card Caution Please do not plug in the main power supply cord until you have finished all of the connections! Although some TV and radio channels are free to view, you must subscribe to most TV and radio/music channels and a Conditional Access component is required. If you want to enjoy watching scrambled broadcasting channels, you need to purchase the CAMs and smart cards from a service provider’s sales department. However, broadcasting channels from multiple service providers call for multiple CAMs and Smart cards. Receivers which have only the CAMs and smartcards provided by the one service provider can show several broadcasting channels of the provider. Please refer to manuals provided by service providers for details because the CAM and smartcards are featured with unique menus, apart from menus given by the receiver. Watching "Free-To-Air" channel is available regardless of the CAM and smart cards. -
Page 9: Connecting And Installation
1.5 Connecting and Installation 1.5.1 How to connect the receiver to various other systems There are several ways of connecting the receiver to your TV, VCR and/or Hi-Fi SYSTEM. Consult your local supplier for assistance in setting-up your system that is best suited to your requirements. 1.5.2 To Connect Satellite Antenna DiSEqC 1.0 ♦ • Connect the coaxial cable from the LNB to the LNB IN jack on back of the receiver. •... - Page 10 1.5 Connecting and Installation 1.5.6 Connect STB to a TV set - HDMI HDMI, or high-definition multimedia interface, is a next-generation interface that enables the transmission of digital audio and video signals using a single cable without • Satellite Receiver compression. “Multimedia interface” is a more accurate name for it especially because it allows multiple channels of digital audio (5.1 channels). When connecting via HDMI, you do not need to connect Audio Cables. You only need to connect Audio cables when connecting via HDMI/DVI.
-
Page 11: Basic Operation
2. Basic Operation 2.1 Basic Function Usage 2.1.1 Program Information After the television channels have been programmed, you will see the information box each time you change the channels. • Every time you change channels you will receive program information for a few seconds. (In the Banner Time menu you can select how long this information will be shown.) • You may change channel with the UP/DOWN button. You can get Channel Banner at the bottom of the screen. • When you press the COLOR button, you can use the banner as a simple channel operation. -
Page 12: Main Menu Guide
3. Main Menu Guide 3.1 Installation Satellite Search Select the satellite list you want using UP/DOWN buttons on the satellite list. OK/RIGHT you can go to the right side with button and to the left side with the LEFT button. C/KU Switch •... - Page 13 3.1 Installation Note After the Degree, Longitude and Latitude is enterted accurately the DiSEqC Motor will automatically move to the satellite's position. After selecting all that is necessary, press RED button to scan the satellite list. • Select ON or OFF according to your Network. •...
-
Page 14: Edit Channel List
3.2 Edit Channel List From these menus, you can edit favorite lists, lock, skip, delete, or move channel. • Select “Edit Channel List” in the main menu with the UP/DOWN buttons and press the button. • If the menu lock is activated at the request window, input PIN code. If you have not entered your own PIN code, then the PIN code 0000 applies, which was set at the factory. -
Page 15: Program Guide
3.3 Program Guide The program guide displays programme information about each channel, based on the date and time. You can also reserve a recording Yellow or watch the channel by pressing the button. 3.3.1 Viewing the Program Guide Information • Select "Program Guide"... -
Page 16: System Setting
3.4 System Setting If the menu lock is activated, you will be asked to enter your PIN code before you can enter this menu. The PIN code preset to 0000 from the factory. If you want to customize the system to suit you better, you can specify some settings from the submenus in the “System Setting” menu. - Page 17 3.4 System Setting 3.4.4 SD Video Output This menu is used for viewing screen. • If the receiver and TV are connected using the composite cable, select CVBS using the UP/DOWN buttons. • If the receiver and TV are connected using the Scart cable, select SCART-RGB using the UP/DOWN buttons. 3.4.5 Screen Type Select the TV setting type. 4:3 TV 16:9 • Press the LEFT/RIGHT buttons to select either • Press the UP/DOWN buttons to select either Letter...
- Page 18 3.4 System Setting 3.4.10 Receiver Lock If you select “On”, you will have to enter the PIN code every time you start the receiver from standby. 3.4.11 Menu Lock If the Menu Lock is already set, the PIN code is needed to set the Edit Channel List and System Setting. If you want to set the Menu Lock, press the UP/DOWN buttons to select Locked and then press the OK button. 3.4.12 SPDIF Output You can hear digital audio of the Dolby 5.1 channel using S/PDIF Output. • If selecting OFF, the digital audio will not be output. • When selecting PCM, the unzipped digital audio is output through S/PDIF. • When selecting Dolby Digital, if the current channel is a Dolby audio channel, the zipped Dolby stream is output through S/PDIF. 3.4.13 Factory Reset UP/DOWN Press the button on the Setup list to select Factory Reset.
-
Page 19: Irdeto Ca Status
3.5 Irdeto CA Status In this menu, you can see the Smart Card Status, Service Status, Loader Status, Components, and Mail Box. Maturity Rating Rating” in the Irdeto CA Status menu with the Select “Maturity UP/DOWN buttons and press the button. Then the PIN code entry screen appears Enter the subscriver's PIN (master PIN) number. For the number, consult with the local provider. ON/OFF : Switches On or Off for Maturity Rating • • MODE : Changes the maturity rating settings. • SET : Switches MR On/Off or changes the profile information. • DELETE : Deletes the profile information. • PROFILE : Displays the profile number. -
Page 20: Pvr Menu
3.7 PVR Menu Connect a USB memory device to the receiver by using the USB port and select "Information" in "PVR Menu." • Image Viewer : When you connect a USB device to the receiver, this function is active. • File List : Displays the recorded files. It plays the image that has been recorded on File List. When you press the Yellow button on File List, you can select File List or Image Viewer. (Only JPG format available) In order to see a JPG image, press the Yellow button and select Image Viewer. You cannot see JPG images on File List. • Format HDD : Formats the hard disk. When you format the hard disk, the PVR folder is created. -
Page 21: Playing A Recorded File
3.8 Playing a recorded file You can play a recorded file through the File List menu. List" in the main menu with the UP/DOWN • Select "File buttons and press the button. • Select a file with the UP/DOWN button and press the button to play the select file. • Select a play option with the UP/DOWN button and press the button to start playback. - Continue: Plays from the paused point - Begin: Plays from the start 1 Status icon (Playback, Pause, Search playback, Skip playback, etc.) -
Page 22: Troubleshooting
4. Troubleshooting Problem Solution No display LED on the front panel. Power cord plug in correctly. No power supply No Picture Ensure that the STB is switched on. Check connection and correct. Check channel and video output and correct. Poor picture quality Check the signal level, if this is low then try adjusting the alignment of your dish. No Sound Check the volume level of the TV and STB. Check the mute status of the TV and STB. Check the connection of audio cord. Remote Control does not operate Point remote control directly towards the receiver. Check and replace batteries. Check that nothing blocks the front panel. - Page 23 Note STB_CityCom_Sat_111379_CCR545_Eng.indd 23 2010-08-03 8:27:01...
- Page 24 ENG_111379 STB_CityCom_Sat_111379_CCR545_Eng.indd 24 2010-08-03 8:27:01...
