INSTRUCTION ABOUT 'WEEE' SYMBOL
I/B parenthesis to offer information for user.
English
This marking shown on the product or its literature,
indicates that it should not be disposed with other
household wastes at the end of its working life.To
prevent possible harm to the environment or human
health from uncontrolled waste disposal, please
separate this from other types of wastes and recycle it
responsibly to promote the sustainable reuse of material resources.
Hosehold users should contact either the retailer where they
purchased this product, or their local government office, for details of
where and how they can take this item for environmentally safe
recygling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract.This product should not be mixed
with othercommercial wastes for disposal.
German
Die Kennzeichnung auf dem Produkt bzw. auf der
dazugehörigen Literatur gibt an,dass es nach seiner
Lebensdauer nicht zusammen mit dem normalen
Haushaltsmüll entsorgt werden darf. Entsorgen Sie
dieses Gerät bitte getrennt von anderen Abfällen,
um der Umwelt bzw. der menschlichen Gesundheit
nicht durch unkontrollierte Müllbeseitigung zu schaden
.Recyceln Sie das Gerät, um die nachhaltige Wiederverwertung von
stofflichen Ressourcen zu fördern. Private Nutzer sollten den Händler,
bei dem das Produkt gekauft wurde, oder die zuständigen Behörden
kontaktieren, um in Erfahrung zu bringen,wie sie das Gerät auf
umweltfreundliche Weise recyceln können. Gewerbliche Nutzer sollten
sich an Ihren Lieferanten wenden und die Bedingungen des
Verkaufsvertrags konsultieren. Dieses produkt darf nicht zusammen
mit anderem Gewerbemüll entsorgt werden.
User's Manual
Common Interface Digital Satellite Receiver
Digital-Crypto Works-Satellite Receiver
CCR 521S / CCR 525S
CryptoWorks CAS Embedded

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CCR 521S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CityCom CCR 521S

  • Page 1 Business users should contact their supplier and check the terms and Verkaufsvertrags konsultieren. Dieses produkt darf nicht zusammen conditions of the purchase contract.This product should not be mixed with othercommercial wastes for disposal. mit anderem Gewerbemüll entsorgt werden. CCR 521S / CCR 525S...
  • Page 2: Table Of Contents

    Table of Contents Table of Contents 1. SAFETY PRECAUTIONS 2. GENERAL FEATURES 3. HOW TO CONNECT YOUR RECEIVER 4. HARDWARE DESCRIPTION 5. SYSTEM SET-UP 6. MENU OPERATION 7. UPGRADE BY SATELLITE 8. TROUBLE SHOOTING 9. TECHNICAL SPECIFICATIONS...
  • Page 3: Safety Precautions

    1. SAFETY PRECAUTIONS 2. GENERAL FEATURES - Fully MPEG-2 & DVB Compliant This receiver has been manufactured to satisfy the international - Smart card interface for the embedded CrptoWorks safety standards. - Preprogrammed for ASTRA, Hotbird and Türksat Please read the following recommended safety precautions carefully - 2 Slots of Common Interface for Viaccess, Conax, CryptoWorks, Nagravision, Irdeto, SECA - Input Frequency 950�2150MHz...
  • Page 4: How To Connect Your Receiver

    3. HOW TO CONNECT YOUR RECEIVER 5) CONNECTING EXTERNAL AUDIO HI-FI SYSTEM Please DO NOT plug in the main power supply cord until To connect any external Audio Hi-Fi system, the receiver has been provided with two you have finished all the connections. RCA connectors at the back of the receiver, marked with Audio L and R respectively to connect the left and right Audio.
  • Page 5: Hardware Description

    4. HARDWARE DESCRIPTION 4. A. FRONT PANEL 1) POWER : This key is used to turn the receiver on and off (stand by). 4. B. REAR PANEL POWER 1) LNB IN : This port is to connect the coaxial cable from LNB of your Dish. The IF input is provided through this port and the input frequency range is 950�2150MHz.
  • Page 6 4. C. REMOTE CONTROL UNIT 1) POWER : This is used to switch the receiver to ON/STANDBY mode. 15) LAST : This key is used to return to the previous channel. LAST 2) MUTE : This key is used to toggle between normal and muted audio. 16) AUDIO : This key is used to select the soundtrack list for the current service AUDIO 3) 0-9 NUMERIC KEYS : These keys are used to enter numeric values and to...
  • Page 7: System Set-Up

    5.SYSTEM SET-UP 5.A. Automatic channel search for a satellite 5. B. Manual channel search for a transponder You can automatically detect and save all TV and Radio channels You can automatically search and save all TV and Radio channels of of a satellite as follows : a transponder as follows : ■...
  • Page 8: Menu Operation

    6. MENU OPERATION 6.1.1.A. AUTOMATIC CHANNEL SEARCH The main menu is classified into five sub menus which will carry out the When you are in the satellite window (left side of this screen), you can add, delete or edit satellite various operation individually.
  • Page 9: Edit Channels

    6.1.1.B. MANUAL CHANNEL SEARCH In normal mode, you can edit each channel separately. You can add to the selected channel into the favorite list. When you are in the transponder window (right side of this screen), you can add, delete or edit And you can also delete, lock/unlock or rename each transponder information and also scan the selected transponder to find the channels.
  • Page 10 6.1.2.C. Delete channel – F3 key TV Select : Select video output mode - CVBS or RGB Select channel that you want to delete using the “ up / down ” keys and the “ page up/ down ” keys. RF Channel : Select or change RF channel number when your receiver is When you want to delete multiple channels at a time, set channels as block by pressing “OK”...
  • Page 11 On time : Set the time when the receiver will be automatically turned on Receiver lock Lock or unlock your receiver. When receiver is locked, the PIN code will Off time : Set the time when the receiver will be automatically turned off. be required whenever you turn on the receiver.
  • Page 12: Channel List

    6.1.4. COMMON INTERFACE (CI Model Only) When you press “ i ” key again, the event description box will be displayed if the current channel includes EPG information. Otherwise the information box will be closed. Press “ Exit ” key to close the information box or the This receiver is equipped with two PCMCIA slots.
  • Page 13: Zoom Function

    6.2.5. Subtitle ♬ When you press the “ ” key, you can alternatively select TV or radio channel guide. Press the “GUIDE”key again to view the one channel Guide. When the current channel that you are watching includes the subtitle, you can popup the subtitle Press the “menu”...
  • Page 14: Upgrade By Satellite

    7. UPGRADE BY SATELLITE Do not switch off the Receiver during the data download! You can upgrade your receiver up to date, when the new software is available. Select “Receiver upgrade” in the “Receiver Settings” Menu to enter Software download. 1.C.
  • Page 15: Trouble Shooting

    8. TROUBLE SHOOTING 9. TECHNICAL SPECIFICATIONS 1. Power Supply Problem Solution About the Receiver : SMPS Type : 95�240V AC 50/60 Hz Input Voltage Does not display LED on the - Connect the power cord to the power outlet : 250V/T2A Fuse Rating front panel or the receiver has no power.
  • Page 16 5. Audio Decoder : MPEG-1 ISO/IEC 11172-3 System Decoding Layer I & II : Mono, Dual, Stereo, Joint Stero Audio Mode : 32, 44.1, 48 KHz Sampling Frequency 6. Audio/Video Output : CVBS, RGB, Audio L/R TV SCART : CVBS, Audio L/R VCR SCART : CVBS, Audio L/R RCA Jack...
