Nano Water Purifi er
Instruction Manual
Introduction
Specifi cation
Components
Cartridge and Filters
Parts of main body
Tubing connection
Installation
Cartridges replacement
Filters replacement
Operation steps
FAQ
Spare parts
All For Your Long Life
Series N
2
3
4
5
6
8
9
10
11
12
14
15
PRODUCT OF
THAILAND
1
Advertisement
Table of Contents
Related Manuals for Allfyll Series N
Summary of Contents for Allfyll Series N
- Page 1 All For Your Long Life Nano Water Purifi er Series N Instruction Manual Introduction Specifi cation Components Cartridge and Filters Parts of main body Tubing connection Installation Cartridges replacement Filters replacement Operation steps Spare parts PRODUCT OF THAILAND...
- Page 2 Introduction Water purifi er with Nano fi ltration (NF) Series N is for production of pure drinking water by Nano fi ltration technology. It consists of 5-7 hight quality fi lters and a NF fi lter which can removes particles down to 0.001 micron up to 99%, some ions, heavy metals, organic compounds, bacterias and visruses up to 95%.
-
Page 3: Specification
Specifi cation Model Specifi cation Number of stages for water purifi cation Flowarte (gallons per day / liters per hour) • • • • PP 5 micron cartridge • • • • CTO cartridge • • • • Resin cartridge •... - Page 4 Components Components Part No. Faucet AF-4004 Housing wrench AF-4005 Deliver-valve AF-4006 Water supply connector AF-4007 Tubing, 3m AF-4009...
- Page 5 Model Cartridges and Filters Part No. PP 5micron inline fi lter for removing of dirts, rusts and sand particles down to 5 microns. Allfyll®, Thailand • • • • AF-3101 Life time > 6 months CTO inline fi lter For removing of chlorine, taste and odor and organic chemicals Allfyll®, Thailand...
- Page 6 Parts of main body Post carbon Inline Filter NF Inline Filter Pressure Gage 1st Housing (with PP Cartridge) 2nd Housing (with CTO Cartridge) 3rd Housing (with Resin Cartridge)
- Page 7 Parts of main body NF Inline Filter Post carbon Inline Filter Pressure Gage...
-
Page 8: Tubing Connection
Tubing connection Connect the A tubing to the water supply connector. Connect the B tubing to the sink top faucet. Connect the C tubing to the drain saddle. Faucet Input water Drain... -
Page 9: Installation
Installation Input water : To Nano system Deliver valve water source faucet pipe Install European ceramic Install drain saddle : faucet : Drill a 1/4” hole into the drain pipe. Mount drain saddle aligning holes. Assemble Filters :... - Page 10 Cartridges replacement Turn off water Prepare a source. housing wrench. To Nano system Open housings clockwise with a wrench. Drain out 1 Gallon of water Put the replacement fi lters in the to purify replacement fi lters. housings and double O’ ring. Be sure tighten with O-ring to prevent from...
-
Page 11: Filters Replacement
Filters replacement 1. Remove the old fi lters. 2. Replace with the new fi lilters. -
Page 12: Operation Steps
Operation steps 1. With everything connected, turn on the water, check for leaks. 2. Open the sink top faucet. 3. Within a few minutes (up to 15) the water will start to run from the faucet slowly. 4 Let the water run for at least 30 minutes. This fl ushes the carbon fi lters on fi rst time use. - Page 13 Operation guide Let the water run for at least Turn on water source. 30 minutes. This fl ushes the carbon fi lters on fi rst time To Nano system use.
- Page 14 Q: What is the guarantee on the Allfyll water purifi er? The Allfyll water purifi er (excluding cartrifges and fi lters) is guaranteed for 1 year for material and workmanship. All defective parts will be replaced free within the fi rst year under normal breakdown.
-
Page 15: Spare Parts
Spare parts Spare Parts Part No. ® Allfyll 5 micron PP Cartridge, 10” AF-3101 ® Allfyll CTO Inline Filter, 10” AF-3102 ® Allfyll Resin Inline Filter, 10” AF-3103 ® Hidrotek NF Filter 150GPD AF-5105 ® Allfyll Post Carbon Inline Filter, 10”... -
Page 16: Maintenance Time Table
Post Carbon Alkaline Date Cartridge Cartridge Cartridge Inline Filter Inline Filter Inline Filter lamp All For Your Long Life Allfyll (Thailand) Co., Ltd. 8 Thaiyanon 12, Nonthaburi 46, Muang-Nonthaburi, Nonthaburi 11000 Tel: +66 2950-2121-2 Fax: +66 2950-2120 Email: sales.th@allfyll.com Website: www.allfyll.com...
