- Page 1 All For Your Long Life RO Water Purifi er Series A Instruction Manual Introduction Specifi cation Components Cartridge and Filters Parts of main body Display Tubing connection Installation Cartridges replacement RO membrane replacement Operation steps Spare parts PRODUCT OF THAILAND...
-
Page 2: What Is Reverse Osmosis
Introduction Water purifi er with Reverse Osmosis (RO) Series A is for production of pure drink- ing water by Reverse Osmosis technology. It consists of 5 hight quality fi lters and a RO membrane which can removes particles down to 0.0001 micron up to 95%, ions, heavy metals, organic compounds and bacterias up to 99%. -
Page 3: Specification
Specifi cation Model Specifi cation A300 A600 Number of stages for water purifi cation Flowarte (gallons per day) Booster pump 300GPD • • PP 5 micron cartridger • • CTO cartridge • • Resin cartridge RO membrane 300GPD • •... - Page 4 Components Standard accessories Part No Faucet AF-4004 20G Water storage tank AF-0022 Housing wrench, 20” AF-4033 Chromed Ball valve 3/8” AF-4006 T-WAY Connector 1/2”, side port 3/8” AF-4038 Tank ball shut-off valve AF-4008 Tubing 3/8”, 3m AF-4034 Tubing 1/4”, 3m AF-4009...
- Page 5 Model Cartridges and Filters Part No. A300 A600 PP 5micron inline fi lter for removing of dirts, rusts and sand particles down to 5 microns. GE PURTREX®, U.S.A. • • AF-3301 Life time > 12 months CTO inline fi lter For removing of chlorine, taste and odor and organic chemicals Omnipure®, U.S.A.
- Page 6 Parts of main body Solinoid vavle Post carbon Inline Filter Pressure Gage RO Housing (with RO membrane) 1st Housing (with PP Cartridge) 2nd Housing (with CTO Cartridge) 3rd Housing (with Resin Cartridge) Power box Solinoid valve Display Flush valve Post carbon Inline Filter Pressure Gage...
- Page 7 Display POWER Bulb is lightening as connecting power. WATER The system starts to function 20 seconds after plugging in. WORKING The system begins to produce water. FULL Pump stops when tank is full of pure water.
-
Page 8: Tubing Connection
Tubing connection Input water Faucet To Faucet To Tank Drain Out... -
Page 9: Installation
Installation Input water : Install water tank : 1. Screw in ball valve connector. To RO system 2. Take tubing white, connect it to the deliver valve and the inlet water to storage tank Deliver valve water source faucet pipe Install European ceramic Install drain saddle : faucet :... - Page 10 Cartridges replacement Turn off water Prepare a Switch off water source. housing wrench. tank. To RO system Open housings clockwise Unplug electricity. with a wrench. Drain out 1 Gallon of water Put the replacement fi lters in the to purify replacement fi lters. housings and double O’...
-
Page 11: Ro Membrane Replacement
RO membrane replacement Turn off water Switch off water Unplug electricity. source. tank. To RO system Remove the membrane Loose the Joco fi tting housing cap anticlockwise. anticlockwise. Remove the membrane Install the membrane by by a pincer. carefully pushing the spigot end into the socket at the far end of the housing until completely in. - Page 12 Operation guide 1. With everything connected, turn on the water, check for leaks. 2. Make sure the storage tank shut-off valve is “OFF”. Open the sink top faucet. 3. Within a few minutes (up to 15) the water will start to run from the faucet slowly. 4 Let the water run for at least 30 minutes.
- Page 13 Operation guide Plug into power. Turn on water source. To RO system Switch on water tank. Display signals are on. Let the water run for at least Pump starts to function. 30 minutes. This fl ushes the carbon fi lters on fi rst time use.
- Page 14 Q: What is the guarantee on the Allfyll water purifi er? The Allfyll water purifi er (excluding cartrifges and fi lters) is guaranteed for 1 year for material and workmanship. All defective parts will be replaced free within the fi rst year under normal breakdown.
-
Page 15: Spare Parts
Spare parts Spare Parts Part # PURTREX® 5 micron PP Cartridge, 20” AF-3301 Omnipure® CTO Cartridge, 20”, Long life AF-3302 Jarcobi® Resin Cartridge, 20”, Long life AF-3303 HYDROTEK® RO Membrane 300GPD AF-3015 Omnipure® Post Carbon Inline Filter, 12” AF-3305 Ultraviolet light (UV) 16W Kit AF-4002 RO Pump 300GPD 3/8”... -
Page 16: Maintenance Time Table
Maintenance time table Resin Post Carbon Date Cartridge Cartridge Cartridge Membrane Inline Filter lamp All For Your Long Life Allfyll (Thailand) Co., Ltd. 8 Thaiyanon 12, Nonthaburi 46, Muang-Nonthaburi, Nonthaburi 11000 Tel: +66 2950-2121-2 Fax: +66 2950-2120 Email: sales.th@allfyll.com Website: www.allfyll.com...
