- Page 1 All For Your Long Life RO Water Purifi er Series S Instruction Manual Introduction Specifi cation Components Cartridge and Filters Parts of main body Display Tubing connection Installation Cartridges replacement RO membrane replacement Operation steps Spare parts PRODUCT OF THAILAND...
-
Page 2: What Is Reverse Osmosis
Introduction Water purifi er with Reverse Osmosis (RO) Series S is for production of pure drinking water by Reverse Osmosis technology. It consists of 5-7 hight quality fi lters and a RO membrane which can removes particles down to 0.0001 micron up to 95%, ions, heavy metals, organic compounds and bacterias up to 99%. -
Page 3: Specification
Specifi cation Model Specifi cation Number of stages for water purifi cation Flowarte (gallons per day) Booster pump pressure 100 psi • • • • PP 5 micron cartridge (long life) • PP 5 micron cartridger • • • • CTO cartridge (long life) •... - Page 4 Components Standard accessories Part No Faucet AF-4004 3.2G water storage tank AF-4002 Housing wrench 10” AF-4005 Deliver-valve AF-4006 Water supply connector AF-4007 Tank ball shut-off valve AF-4008 Tubing, 3m AF-4009...
- Page 5 Model Cartridges and Filters Part No. S1 S2 SA SL SAL PP 5micron inline fi lter for removing of dirts, rusts and sand particles down to 5 microns Allfyll®, Thailand • AF-3101 Life time > 6 months GE PURTREX®, U.S.A.
- Page 6 Parts of main body Post carbon Inline Filter Display Pressure Gage 1st Housing (with PP Cartridge) 2nd Housing (with CTO Cartridge) 3rd Housing (with Resin Cartridge) Flush valve RO Housing (with RO membrane) Post carbon Inline Filter Display Pressure Gage...
- Page 7 Display POWER Bulb is lightening as connecting power. WATER The system starts to function 20 seconds after plugging in. WORKING The system begins to produce water. FULL Pump stops when tank is full of pure water.
-
Page 8: Tubing Connection
Tubing connection Connect the A tubing to the water supply connector. Connect the B tubing to the sink top faucet. Connect the C tubing to the drain saddle. Connect the D tubing to the storage tank. Faucet Input water Tank Drain... -
Page 9: Installation
Installation Input water : Install water tank : To RO system Hand tighten plastic shut-off valve to tank. Deliver Then connect valve color tubing. water source faucet pipe Install European ceramic Install drain saddle : faucet : Drill a 1/4” hole into the drain pipe. - Page 10 Cartridges replacement Turn off water Prepare a Switch off water source. housing wrench. tank. To RO system Open housings clockwise Unplug electricity. with a wrench. Drain out 1 Gallon of water Put the replacement fi lters in the to purify replacement fi lters. housings and double O’...
-
Page 11: Ro Membrane Replacement
RO membrane replacement Turn off water Switch off water Unplug electricity. source. tank. To RO system Remove the membrane Loose the Joco fi tting housing cap anticlockwise. anticlockwise. Remove the membrane Install the membrane by by a pincer. carefully pushing the spigot end into the socket at the far end of the housing until completely in. - Page 12 Operation guide 1. With everything connected, turn on the water, check for leaks. 2. Make sure the storage tank shut-off valve is “OFF”. Open the sink top faucet. 3. Within a few minutes (up to 15) the water will start to run from the faucet slowly. 4 Let the water run for at least 30 minutes.
- Page 13 Operation guide Plug into power. Turn on water source. To RO system Switch on water tank. Display signals are on. Let the water run for at least Pump starts to 30 minutes. This fl ushes the function. carbon fi lters on fi rst time use.
- Page 14 Q: What is the guarantee on the Allfyll water purifi er? The Allfyll water purifi er (excluding cartrifges and fi lters) is guaranteed for 1 year for material and workmanship. All defective parts will be replaced free within the fi rst year under normal breakdown.
-
Page 15: Spare Parts
Spare parts Spare Parts Part # PURTREX ® 5 micron PP Cartridge, 10” AF-3001 ® Allfyll 5 micron PP Cartridge, 10” AF-3101 ® CTO Cartridge, 10”, Long life AF-3002 ® Allfyll CTO Inline Filter, 10” AF-3102 ® Jarcobi Resin Cartridge, 10”, Long life AF-3003 ®... -
Page 16: Maintenance Time Table
Post Carbon Alkaline Date Cartridge Cartridge Cartridge Membrane Inline Filter Inline Filter lamp All For Your Long Life Allfyll (Thailand) Co., Ltd. 8 Thaiyanon 12, Nonthaburi 46, Muang-Nonthaburi, Nonthaburi 11000 Tel: +66 2950-2121-2 Fax: +66 2950-2120 Email: sales.th@allfyll.com Website: www.allfyll.com...
