Summary of Contents for Sealite BargeSafe
- Page 1 BargeSafe™ Solar 3nm LED Barge Light Installation & Service Manual Version 1.2...
- Page 2 BargeSafe™ Solar 3nm LED Barge Light Sealite's world-class sectored lens for UL 1104 certified and 1watt ultra-high COLREG-72 configurations as intensity LED well as 360o all round lights Automatic night activation Convenient ON/OFF switch Integrated handle 4 x 3watt (12 watts in total)
-
Page 3: Table Of Contents
BargeSafe™ Solar 3nm LED Barge Light COLREG-72 & UL 1104 Certified Table of Contents Introduction ..................Page 4 Operating Principle ................Page 4 Technology ...................Page 4 BargeSafe™ Solar 3nm Model ............Page 5 Application ...................Page 6 Installation ....................Page 7 Maintenance and Servicing ..............Page 9 Replacing the Battery ..............Page 9... -
Page 4: Introduction
The BargeSafe™ Solar 3nm Light utilises a small microprocessor to control the LED function and monitor the light levels to enable the light to turn on automatically at night. During the day, the BargeSafe™ Solar 3nm Light runs a number of self diagnostic functions. -
Page 5: Bargesafe™ Solar 3Nm Model
COLREG-72 & UL 1104 Certified BargeSafe™ Solar 3nm Model The Sealite BargeSafe™ Solar 3nm LED barge lights are certified to UL 1104 and COLREG-72 with >3nm visible range. The LED barge light is one of the most advanced in its class, and incorporates a host of innovative features designed to make the unit extremely user-friendly. -
Page 6: Application
COLREG-72 & UL 1104 Certified Application Please check with your local authority before installing the Sealite BargeSafe™ Solar 3nm lantern to ensure the position and range is appropriate for your requirements. • The Stern (White) Barge light provides an angle of 135°. -
Page 7: Installation
• Remove the BargeSafe™ Solar 3nm Light from the box and remove all protective packaging. • Switch the BargeSafe™ Solar 3nm Light on using the ON/OFF switch next to the Light Head. • The light will activate for 30 seconds. It will automatically switch off after exposure to 30 seconds of daylight. - Page 8 Low Battery Status The BargeSafe™ Solar 3nm will run for many nights on a single 12v 12Ah SLA Battery, as a number of battery brands may be used in this unit, the number of nights the BargeSafe™ Solar 3nm will operate for will vary.
-
Page 9: Maintenance And Servicing
Always discard old batteries in a safe manner. Long Term Battery Storage If the BargeSafe™ Solar 3nm is to be placed in storage for an extended period please follow the below information. The sealed lead acid batteries inside the lights must always be stored in a fully charged state. -
Page 10: How To Change The Regulator
BargeSafe™ Solar 3nm LED Barge Light COLREG-72 & UL 1104 Certified How to Change the Regulator Remove the 4 x M6 x 20 socket head cap screws (SHCS) and 4 x M6 nylon washers, then disconnect the light head from the chassis. -
Page 11: Solar Panel Replacement
COLREG-72 & UL 1104 Certified Solar Panel Replacement The BargeSafe Solar 3nm is built around an internal aluminium chassis. The solar panels can be user- replaced in the unlikely event that one is broken or damaged during the product’s life. -
Page 12: Trouble Shooting
BargeSafe™ Solar 3nm LED Barge Light COLREG-72 & UL 1104 Certified Trouble Shooting Problem Remedy Lantern will not activate. • Ensure lantern is in darkness. • Wait at least 60 seconds for the program to initialise in darkness. • Ensure battery is properly connected. - Page 13 BargeSafe™ Solar 3nm LED Barge Light COLREG-72 & UL 1104 Certified Notes Latest products and information available at www.sealite.com...
-
Page 14: Sealite Led Light Warranty
2. Online Registration - please complete the Online Registration Form at; www.sealite.com Sealite Pty Ltd will repair or replace your LED light in the event of electronic failure for a period of up to three years from the date of purchase. - Page 15 BargeSafe™ Solar 3nm LED Barge Light COLREG-72 & UL 1104 Certified 3. The customer must give Sealite Pty Ltd notice of any defect with the product within 30 days of the customer becoming aware of the defect. 4. Rechargeable batteries have a limited number of charge cycles and may eventually need to be replaced.
- Page 16 BargeSafe™ Solar 3nm LED Barge Light COLREG-72 & UL 1104 Certified Other Sealite Products Available Marine Lanterns Monitoring (1-12nm+) & Control Systems Bridge & Barge Lights Marine Buoys (up to 3mt in diameter) Area Lighting Mooring Systems & Accessories Head Office...
