LG multi V PLUS Service Manual page 41

Model
Cooling Capacity
Heating Capacity
Casing
Body
Dimensions (W*H*D)
Front Panel
Rows x Columns x FPI
Coil
Face Area
Type
Motor Output
Running Current
Fan Air Flow Rate(H/M/L)
Drive
Speed control
Temperature Control
Sound Absorbing Thermal Insulation Material
Safety Device
Liquid Side
Pipe Connections Gas Side
Drain Pipe(OD)
Net Weight
Noise Level(Sound Press, 1.5m, H/M/L)
Power Supply
Refrigerant Control
Power cable
Transmission cable
Panel Color
Stuffing Quantity Without S/parts
Notes:-
1. Capacities are based on the following conditions:
Cooling • Indoor temp. 27°C[80.6°F]DB/ 19°C[66.2°F]WB
• Outdoor temp. 35°C[95°F]DB/ 24°C[75.2°F]WB
• Interconnecting Piping Length 7.5m
• Level Difference of Zero
2. Capacities are net capacities
3. Due to our policy of innovation some specifications may be changed without notification
4. L.E.V.:Linear Expansion Valve
LRNV242TDA(C)0
Unit
7,000
W
6,019
kcal/h
Btu/h 23,885
-
W
kcal/h -
-
Btu/h
Galvanized Steel Plate
840*840*290
mm
33.0*33.0*11.4
inch
mm 950*950*30
37.4*37.4*1.2
inch
2*12*21
2*0.26
m 2
Turbo Fan
W 60
0.80
A
cmm 19/17/15
671/601/530
cfm
Direct
Phase Control
Microprocessor, Thermostat for cooling
Foamed polystrene
Fuse, Thermal Fuse for Fan Motor Fuse, Thermal Fuse for Fan Motor Fuse, Thermal Fuse for Fan Motor
mm(inch) Ø9.52(3/8)
Ø15.88(5/8)
mm(inch)
32.0
mm
32(70.5)
kg(lbs)
41/38/36
dBA±3
Ø / V / Hz 1 / 220 / 60
LEV
mm CV2.0 X 3C
2
CVV-SB 1.25 X 2C
mm 2
White
20/40ft 72/144
Cooling Only (60Hz)
LRNV282TDA(C)0
8,200
7,052
27,995
-
-
-
Galvanized Steel Plate Galvanized Steel Plate
840*840*290
33.0*33.0*11.4
950*950*30
37.4*37.4*1.2
2*12*21
2*0.26
Turbo Fan
60
0.80
23/21/18
813/742/636
Direct
Phase Control
Microprocessor, Thermostat for cooling Microprocessor, Thermostat for cooling
Foamed polystrene Foamed polystrene
Ø9.52(3/8)
Ø15.88(5/8)
32.0
32(70.5)
42/40/38
1 / 220 / 60
LEV
CV2.0 X 3C
CVV-SB 1.25 X 2C CVV-SB 1.25 X 2C
White
72/144
Conversion Formula
Kcal/h= kW x 860
Btu/h = kW x 3412
cfm = m
Service Manual 41
Specifications
LRNV362TDA(C)0
10,600
9,116
36,168
-
-
-
840*840*290
33.0*33.0*11.4
950*950*30
37.4*37.4*1.2
2*12*21
2*0.26
Turbo Fan
60
1.10
26/24/22
919/848/777
Direct
Phase Control
Ø9.52(3/8)
Ø19.05(3/4)
32.0
32(70.5)
43/41/39
1 / 220 / 60
LEV
CV2.0 X 3C
White
72/144
3 /min x 35.3
