USERS
MANUAL
EV8x8x Models
Firmware Version 1.2.0
Document Revision A
ETROVISION TECHNOLOGY
/
www.etrovision.com
/
+886-2-2655-1518
/
Technical Support: etrotech@etrovision.com
/
Sales Contact: etrosales@etrovision.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1080p/5M series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for EtroVISION 1080p/5M series

  • Page 1 USERS MANUAL EV8x8x Models Firmware Version 1.2.0 Document Revision A ETROVISION TECHNOLOGY www.etrovision.com +886-2-2655-1518 Technical Support: etrotech@etrovision.com Sales Contact: etrosales@etrovision.com...
  • Page 2: Table Of Contents

    CONTENT INTRODUCTION System – Local Storage System – Recording/Snapshot THE LIVE VIEW - Event-Triggered Recording Live View, Setup & Client Setup - Continuous Recording Client Setup - Snapshot Setting - Recording Path Cyclic Recording - Streaming Protocol System – ONVIF -...
  • Page 3 PTZ Control – Patrol PTZ Control – Auto Scan PTZ Control – Privacy Mask MOTION JPEG IN A BROWSER STREAMING VIDEO RTSP Streaming - Authentication Image Snapshot in a Browser ROUTER/FIREWALL CONFIGURATION 58 Streaming Router Configuration - Camera Router/Firewall - Clients only requiring streaming via HTTP -...
  • Page 4: Introduction

    Information contained in this document may be superseded by updates. No representation or warranty is given and no liability is assumed by Etrovision Technology with respect to the accuracy or use of the information, or infringement of patents or other intellectual property rights.
  • Page 5: The Live View

    THE LIVE VIEW The IP camera web interface is made up of two main pages: the Live View page and the Setup page. The Live View provides the current display from the IP camera along with selected settings, configuration and functionality.
  • Page 6: Live View, Setup & Client Setup

    The right hand panel (Information, Streaming, Audio, Control) can be hidden by clicking the small arrow bordering the video and Streaming panel. Click the arrow (highlighted in red) to hide/display the right side panel. Live View, Setup & Client Setup In the top right corner of the screen are three links.
  • Page 7: Client Setup

    Client Setup The Client Setup provides options to modify the recording path, streaming protocol and buffering time. Streaming protocol and buffering time relate to streaming settings for the web UI on the client PC. These settings are only applied for the browser session, and don’t persist after the browser is closed. Settings apply to a specific PC;...
  • Page 8: Controls And Status

    Controls and Status 3. Full 5. Digital In SnapShot Screen Alert 1. Adjust Record 2. Digital 4. SD 6. Motion Live View Card Detection Alert The View Size controls adjust the viewable screen size in Live View. The Zoom feature can be used, and Record and Snapshot will capture video/snapshots to the local hard drive.
  • Page 9: Digital Zoom

    Digital Zoom The Digital Zoom feature allows zooming in on a specific area. When using the View Size controls, a magnifying glass icon will replace the mouse pointer icon. To magnify a specific area, place the magnifying glass icon over the desired area and left click the mouse. Additional left mouse clicks will continue to magnify wherever the mouse is placed.
  • Page 10: Information

    Information Resolution and frame rate will be displayed in the Information pane. Streaming To toggle between different video streams, use the Stream drop down list. The number of ROI which are enabled in the Video Setting – Profile Setting will determine the number of streams available for viewing.
  • Page 11: N53 Panorama Mode

    N53 Panorama Mode The N53 fisheye model has some additional options for displaying video in the Live View. The N53’s wide panoramic view allows for displaying the image in multiple ways. The display options differ between the F and U models. The positioning of the views cannot be permanently set to display in a specific position when the Live View is opened.
  • Page 12: Speed Dome Ptz Control

     Speed Dome PTZ Control The speed dome cameras have some additional PTZ controls displayed in the Control panel. For more information about the speed dome PTZ functionality, see the section PTZ Dome Camera PTZ Control Settings. Home Go to Preset Set Preset Auto Focus Auto Scan...
  • Page 13: Ev8X8Xq-Md

     EV8x8xQ-MD The EV8x8xQ-MD models (Computar Zoom Lens) also have a Push Focus function which automatically determines the optimal focus for a given setting. The live view...
  • Page 14: Setup

    SETUP The web interface is made up of two main pages: the Live View page and the Setup page. The Live View page interface was introduced in the previous section. The Setup interface is primarily used for viewing and configuring the IP camera’s settings. From the Live View page, click the Setup link at the top right side: Below is a screenshot of the Setup page.
  • Page 15: System - Information

    To return to the Live View page, click the Live View link in the right hand corner. NOTE: Configuration changes in the Setup interface require clicking the SAVE button. Otherwise, changes will not be applied. The following discusses the different basic configuration options within the Settings page. System –...
  • Page 16: System - Generic Setting

    System – Generic Setting  Camera Name Enter a camera name if a specific name is desired.  System Time 3 options are available: Manual: insert time manually - PC Time: set to the current PC time - Network Time Server: periodically synchronizes with a time server -...
  • Page 17: Camera Lens

    The camera can be configured to reboot on a weekly basis if desired. Last Reboot displays the date and time of the last reboot.  Camera Lens (for EV8180 models only) Select the appropriate lens type for the camera. A mismatch between the Camera Lens setting and the actual lens type may result in color deviation.
  • Page 18: Http Port

    High = Active High: voltage turns on the external IR LED; no voltage turns off the IR LED  HTTP Port To use a non-default port, change the HTTP Port value. This port is used by the camera’s web server and HTTP streaming.
  • Page 19: System - Maintenance

    Users are assigned to a group (admin, operator or viewer). To edit or delete an account, highlight the account in the User List window and click the edit/delete button. After making changes, click SAVE to apply changes. System – Maintenance ...
  • Page 20: Upgrade Using Sd Card

     Upgrade using SD Card The SD card should be empty of any existing files before proceeding. 1. Rename the firmware file to ev-fw.bin, and copy the file to the SD card. 2. Insert the card into the camera’s SD card slot. 3.
  • Page 21 In the Manage Add-ons window, select “All add-ons” Scroll down and find Etrovision Technology, highlight one of the ActiveX controls, and click the More Information link. In the More Information window, click Remove to clear the ActiveX control from IE.
  • Page 22 Repeat this for the remaining Etrovision Technology ActiveX components. To clear the cache and browsing history, in the IE menu select Tools->Internet Options. Click the Delete button in Browsing History. Setup...
  • Page 23: Export/Import Camera

    Export/Import Camera Configuration  Export will save the camera’s configuration settings to the PC in an archive file. To import, first use Browse to select a camera’s exported configuration file. Next click Import to proceed with replacing the current camera settings with the settings in the configuration file. NOTE: Configuration settings can only be imported from a camera of the same model and using the same firmware version.
  • Page 24: System - Local Storage

    System – Local Storage Format will format the card. Note: contents of the SD card will be lost. Double click on folders to go up/down a directory level. Move up a Download Delete directory to PC Setup...
  • Page 25: System - Recording/Snapshot

    System – Recording/Snapshot There are 2 methods of recording: Event-Triggered and Continuous Recording. Both can be used simultaneously. Cyclic Recording offers options for whether to overwrite old recordings when space on the storage reaches capacity.  Event-Triggered Recording When recording is done via event triggers, Record Setting will define how the recording is performed. Stream Source will only display currently enabled video profile streams.
  • Page 26: Snapshot Setting

     Snapshot Setting Snapshot recording will record a group of snapshots. The maximum value for Pre-alarm and Post-alarm time is 5 seconds. Cyclic Recording The camera can be configured to overwrite the oldest existing recording on SD Card and Network Storage by checking the appropriate option.
  • Page 27: Network - Ip Setting

     WLAN Setting Currently only the EV8180 model has wireless functionality, and only wireless dongle from Etrovision is supported. Other manufacturers’ wireless dongles are not guaranteed to work. The EV8x8x models use a wireless dongle which is different from the EVxx5x models. Verify the appropriate wireless dongle (e.g.
  • Page 28 Manual can be used to directly configure WiFi settings. In the IP Setting tab, set the appropriate IP settings for the wireless network. After clicking Save, the camera will reboot with the new wireless settings. The camera will no longer be accessible via the wired network. Disabling WiFi or removing the WiFi USB antennae will enable the wired network port.
  • Page 29: Network - Streaming

    Network – Streaming The camera can stream using UDP, TCP or HTTP. The client application connecting to a camera can direct which protocol to use. The method of streaming will likely determine the need and extent of any router configuration that may be required. Enable username/password requirement rtsp://root:pass@10.1.21.3/rtpvideo1.sdp URL access name: rtsp://10.1.21.3/rtpvideo1.sdp...
  • Page 30: Network - Ddns

    Multicasting allows sending a message or data to a group via a single message. The multicasting parameters are only for configuring a camera to use multicasting. A networking environment that supports multicasting must be setup which is beyond the scope of this document. Network –...
  • Page 31: Network - Ip Probe

    IP addresses can be entered as a single IP, by network or a range of IP addresses. The network option uses the CIDR subnet mask format. Network – IP Probe IP Probe can be used to verify network connectivity between the camera and a PC/server. When enabled the camera will send ICMP messages to the server defined in the IP address field.
  • Page 32: Network - Snmp

    Network – SNMP Check the relevant version(s) to enable SNMP. Enter the appropriate passwords for Read/Write and Read Only community as needed. If using SNMP version 3, then fill in the relevant information for Read/Write and Read Only. Setup...
  • Page 33: Video/Audio - Video Setting

    Video/Audio – Video Setting Deflicker can be adjusted if flickering is present due to artificial lighting. This setting should be set to match the utility frequency for a given country.  TV Output TV Output can be enabled with SDTV or HDTV options available. SDTV = CVBS output -...
  • Page 34: Resolution Mode

     Resolution Mode (EV8x80F Models Only) For the F model series, Resolution Mode provides a variety of resolution formats. 5M will change Stream 1 to 5M (2592x1920) with a maximum 10fps for both Stream 1 and 2. The 5M option limits ROI to 2, and recording via the camera (e.g. SD card) is disabled. Minilux mode uses noise cancelation technology to provide clearer image quality in low lux conditions.
  • Page 35 The GOP (Group Of Pictures) can also be adjusted. The GOP is based on the FPS setting. For example, if the FPS is 20 and the GOP setting is 2, then the GOP is 40 frames. A GOP is comprised of one I frame and the remainder are P frames.
  • Page 36: Video/Audio - Audio Setting

    Video/Audio – Audio Setting Select the desired audio codec. The Bitrate is configurable for some codecs. Video/Audio – Color Setting  Day/Night Setting Day & Night setting configuration options are available. IR-Cut Filter: controls IR filter operation - B/W in night mode: deselect if black & white not desired in night mode -...
  • Page 37: Color & Sensor Settings

    Back to Day also provides a range (+2-+12) which adjusts the sensitivity of the switch from night to day. This value relates to the From Day to Night; the switch to day mode is based on the From Day to Night + Back to Day values.
  • Page 38 Brightness - Contrast - Saturation - Sharpness - Flip: flip horizontally (top to bottom) - Mirror: flip vertically (right to left) - AE Range Limit: enabling exposes an upper/lower limit list of exposure values for configuration - Enabling also disables AEC & AGC settings and hides the setting controls AEC: Automatic Exposure Control;...
  • Page 39: Video/Audio - Text Overlay

    Location: indoor/outdoor setting to provide more accurate exposure for an indoor or outdoor - environment BLC: Back Light Compensation; image EV (Exposure Value) can be increased to compensate for - background lighting WDR: Wide Dynamic Range; used for high contrast lighting; some camera models only have -...
  • Page 40 Check the box to the left to enable, then click Draw to set the mask area. The area handles can be used to adjust the size or move the mouse over the area and click/drag to move the mask. The masked area will be blocked from the image (and motion detection) with the color set in Color of Mask (black by default).
  • Page 41: Event Handle - Event Rule

    Event Handle – Event Rule The Event Rule page is used to define actions (e.g. record to SD card) in response to the triggering of an event (e.g. motion detection). The Add/Update rule screens contain the same fields. Rule Name is a user defined name for a user defined trigger/action. A trigger or action may require additional settings (e.g.
  • Page 42: Ev8280 Event Actions

    Digital Output has a Duration parameter which relates to the length of time the digital output should be triggered. TCP Notification and HTTP Notification have a Message Text parameter which is the text message that will be sent. Be sure to click SAVE in the main Event Rule screen to save any changes. ...
  • Page 43: Network Storage

    Enter the SMTP server for Server Address and all additional relevant details. The username may only contain alphanumeric characters and the underscore character, “_”.  Network Storage NFS and Samba are supported; if enabled then input relevant details.  FTP Server An FTP server can be used to receive image snapshots when an event is triggered.
  • Page 44: Tcp/Http Recipient

     TCP/HTTP Recipient The TCP and HTTP Recipient allows event notifications to be sent from the camera to a TCP or HTTP server. An event rule (in the Event Handle -> Event Rule configuration) needs to be configured to use either TCP Notification or HTTP Notification.
  • Page 45: Event Handle - Motion Detection

    Event Handle – Motion Detection To use motion detection, motion detection should be enabled and at least one motion detection area enabled. Checking the box for an Area (e.g. Area 1) enables it. To modify a Detect Area, select “Draw” and click & drag to resize the detection area (light area) . X=horizontal, Y=vertical, W=width, H=height.
  • Page 46: Ptz Control - Serial Setting

    Sensitivity runs from a scale of 0 to 100; 0 being the least sensitive and 100 being the most. Object size determines the size of an area that will trigger motion detection. The value represents percentage of the motion detection area which will result in motion detection. A motion detection icon sits below the live view image.
  • Page 47: System Log - View Log

    System Log – View Log The System Log displays system and event details. The System Log has information specifically related to basic system messages (e.g. startup, shutdown) while the Event Log contains information related to events triggered. System Log – Remote Log Setting The System and/or Event log data can also sent to another server.
  • Page 48: Ptz Dome Camera Control Settings

    PTZ DOME CAMERA CONTROL SETTINGS Various speed dome cameras come with built-in PTZ functionality. The PTZ Control settings in these models cater to the specific functionality available in this model. PTZ Control – General Setting  Home Function Home Function can define a PTZ function to be executed when the Home button in the Live View’s PTZ Control panel is clicked.
  • Page 49: Ptz Control - Patrol

    PTZ Control – Patrol Patrol can be used to automatically move from point to point. Up to 24 patrol paths can be configured. A preview window and PTZ Control panel are present in the top portion of the page. The PTZ Control panel has the same functionality as in the Live View.
  • Page 50 Up to 24 patrol paths Use to change the Use Run & Stop to view in the can be configured sequence of presets Patrol Setting viewing window A patrol path is comprised of several preset points. Enter a predefined preset point and the dwell time (duration at the specified point), then click Add.
  • Page 51: Ptz Control - Auto Scan

    PTZ Control – Auto Scan Auto Scan will pan along an axis. The scan can rotate 360° or pan between 2 points. PTZ dome camera control settings...
  • Page 52 The top of the page includes a preview window as well as Tilt and Zoom controls. The arrows at the bottom of the preview window can be used for viewing or setting left/right boundaries. If the 360-degree Circular Scan is checked, then the remaining settings related to the boundary scan will be disabled.
  • Page 53: Ptz Control - Privacy Mask

    PTZ Control – Privacy Mask A privacy mask can be applied to regions to hide areas from viewing and triggering motion detection. A preview window and PTZ Control panel are present in the top portion of the page. The PTZ Control panel has the same functionality as in the Live View.
  • Page 54 Up to 24 Mask Windows can be configured. Each can be given a name (default is MaskXX), and a Width and Height are required. Set Mask is used to save the mask window; the mask will automatically be centered in the preview window. There currently is no way to move the mask within the preview window, so the area to mask should be centered in the preview window.
  • Page 55: Motion Jpeg In A Browser

    MOTION JPEG IN A BROWSER Basic streaming from the camera to a browser can be done using the mjpg.cgi call. Microsoft IE does not support this function. IE doesn’t support the server-push implementation, so Firefox is recommended for use with mjpg.cgi. Other browsers (e.g. Chrome) may also work. First, configure the target video stream profile to use MJPEG encoding type.
  • Page 56: Streaming Video

    STREAMING VIDEO RTSP Streaming Video can be streamed to a video player (e.g. VLC) via RTSP protocol using the standard RTSP port number 554. The URL is in the following format: rtsp://[IP ADDRESS]/rtpvideo[1-4].sdp Replace with the appropriate IP address. rtpvideo1-4 represent video profiles with different characteristics. For more information on video profiles, see Video/Audio –...
  • Page 57: Authentication

    Click Play and video will begin streaming in the video player. WARNING: firewalls and other network security may prevent video streaming.  Authentication If Streaming authentication has been enabled in Network -> Streaming Then a username/password must be supplied with the RTSP URL rtsp://USERNAME:PASSWORD@[IP ADDRESS]/rtpvideo[1-4].sdp Image Snapshot in a Browser To view an image snapshot in a browser, the jpeg.cgi call will provide a snapshot based on video profile 1.
  • Page 58: Router/Firewall Configuration

    ROUTER/FIREWALL CONFIGURATIONA NOTE: Router/Firewall functionality and operation depends on the make/model, firmware, etc. The following screen shots related to router/firewall configuration are only for reference; functionality and operation may differ from your equipment. Please refer to your router/firewall documentation for additional information on functionality and operation.
  • Page 59: Clients Only Streaming Using Rtp

     Clients only streaming using RTP over UDP RTSP ports 6000+ (port usage starts in low 6000 and depends on number of connections – 6000-7000 could be specified) Sample router screenshots enabling port 80 and 554 for streaming. This would be used if clients stream either via HTTP or RTP over RTSP/TCP.
  • Page 60: Client Router/Firewall

    The firewall/DoS settings may also require some modification. The following shows a change made to facilitate streaming.  Client Router/Firewall A client PC or application may require router configuration as well. Although this usually isn’t required for HTTP or RTP over TCP, this will often be required when streaming via UDP. There are 2 ways to handle this situation: Place the PC in the DMZ -...
  • Page 61: Open Udp Port

     Open UDP Port Opening ports 1-65535 allows full web UI access.  Firewall/Security Settings The router firewall/security settings may need adjusting to permit access. PC firewall or virus scan software may also affect streaming. Below is an example of DoS settings; note some access is provided for permitting access. Router/firewall configuration...
  • Page 62: Adding A Camera To An Nvr

    ADDING A CAMERA TO AN NVR The following gives some basic guidance for adding cameras to an NVR system that supports RTSP streaming. Please refer to the NVR instructions for specific details on how to add and administer cameras for the NVR system. When adding a camera to an NVR, the NVR will likely require 3 configuration parameters from the camera: An RTSP URL -...
  • Page 63: Administrator User & Password

    To assign a specific profile stream to the NVR, then append the appropriate profile number to the access name: rtsp://[IP ADDRESS]/[ACCESSNAME][PROFILE#].sdp example: rtsp://10.1.21.38/rtpvideo3.sdp Administrator User & Password The administrator username is “root” and the default password is “pass”. Adding a camera to an NVR...
  • Page 64: Firefox

    FIREFOX While there is support for Firefox, the Live View interface will not have many of the controls available in IE. These controls are implemented using ActiveX which is only supported by IE. QuickTime player also is required to view video in Firefox. Installing QuickTime on a PC will provide the necessary plugin for Firefox.
  • Page 65: Digital Input/Output

    DIGITAL INPUT/OUTPUT The following provides additional electrical schema and specification information. Digital Input Ambient Temperature: 25º C - TTL signal only - External voltage source: 3-5Vdc ±10% - TTL signal high/low level: 3.3V - Max. current: 20mA - Digital Output Ambient temperature: 25º...
  • Page 66: Document Change Log

    DOCUMENT CHANGE LOG The following highlight modifications since the previous document version. Document Version Added: 3.7 System - ONVIF - Modified: 3.2 System – Generic Setting - Added Schedule Reboot section Modified: 3.20 Event Handle – Motion Detection - Added motion detection alert functionality Document change log...
