EtroVISION EV6356A Installation Manual

Ir outdoor ip camera
Hide thumbs Also See for EV6356A:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
EV6356A
IR Outdoor IP Camera
Installation Guide – Version 6.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EV6356A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EtroVISION EV6356A

Summary of Contents for EtroVISION EV6356A

  • Page 1 EV6356A IR Outdoor IP Camera Installation Guide – Version 6.2...

  • Page 2: About This Guide

    Information contained in this document may be superseded by updates. No representation or warranty is given and no liability is assumed by Etrovision Technology with respect to the accuracy or use of the information, or infringement of patents or other intellectual property rights.

  • Page 3: Table Of Contents

    Package Checklist........................8 Product CD ..........................8 Language Support........................8 Front and Side Camera Views....................9 Physical Connections ......................10 USING THE EV6356A FOR THE FIRST TIME ........11 Initial Requirements ......................11 Software Requirements........................11 Install EtroStation™ 3.0 ........................11 Physical IP Camera Connections ..................12 Connect to the Network ........................12...
  • Page 4 Quick Config Login...........................24 Quick Wizard - Network........................25 Manually Starting the Quick Config Wizard ..................27 Factory Default........................28 ADDITIONAL INFORMATION..............30...

  • Page 5: Product Overview

    PRODUCT OVERVIEW The EV6356A IR Outdoor IP Camera is a professional, IP66 waterproof camera with 12 piece IR LED providing 35M coverage. In addition to being durable, the EV6356A offers PoE support. With H.264 compression technology, the EV6356A delivers superior image quality while minimizing bandwidth requirements.
  • Page 6 Video/Audio Frame Rate Up to 30fps (NTSC) / 25fps (PAL) @ D1 Resolution NTSC: D1 (720x480), CIF(352x240), QCIF(176x120) Video Resolution PAL: D1 (720x576), CIF(352x288), QCIF(176x144) Bit Rate M-JPEG: 5 Video Quality Level Selectable; MPEG-4/H.264 : 64K~4Mbps Audio Input 8 kHz Stereo, ADPCM Audio Output 8 kHz Stereo, ADPCM Ethernet...

  • Page 7: Dual Streaming Capabilities

    1.2 Dual Streaming Capabilities The EV6356A Series supports dual streams simultaneously. Combination options include: Stream 1 Stream 2 H.264 H.264 H.264 M-JPEG H.264 MPEG-4 If users assign the same stream format for both Stream1 and 2, the image may be unable to achieve real-time performance.

  • Page 8: Package Checklist

    1.4 Package Checklist The EV6356A packaging will include the following materials.  EV6356A IP Camera x 1  Power Adapter x 1  EtroLink™ USB Configuration Cable x 1  Product CD x 1  Screws and Anchors x 4 ...

  • Page 9: Front And Side Camera Views

    1.7 Front and Side Camera Views...

  • Page 10: Physical Connections

    1.8 Physical Connections 1. Digital I/O Connector 2. Power Line Connector 3. Audio Line Input 4. Video Output BNC Connector 5. Audio Line Output 6. RJ-45 Ethernet Port...

  • Page 11: Using The Ev6356A For The First Time

    USING THE EV6356A FOR THE FIRST TIME 2.1 Initial Requirements Software Requirements Installation and configuration require the following:  Microsoft Windows 2000 or XP Operating System  Microsoft Internet Explorer version 6 or higher Other browsers (i.e. Mozilla Firefox) are not currently supported.

  • Page 12: Physical Ip Camera Connections

    Physical IP Camera Connections Connect to the Network Connect the EV6356A to network hub/switch via a standard CAT5 Ethernet cable with an RJ-45 connector. Please note that the PC must be on the same network domain as the IP camera.

  • Page 13: Initial Network Configuration

    2.3 Initial Network Configuration There are two methods for initially configuring the IP camera’s network settings: EtroScan™ and EtroLink™ USB Configuration Port. The remainder of this section and most of the document refers to configuration using EtroScan™. For more information on using the EtroLink™ USB Configuration Port please refer to the “ETROLINK™...

  • Page 14: Using Etroscan

    Using EtroScan™ EtroScan™ allows users to easily find an IP camera and configure the settings. After installing EtroStation™, EtroScan™ can be accessed via the MS Start button. Select EtroScan™ from the start menu to start.
  • Page 15 Press the Scan button to list the IP and MAC address list for IP cameras on the network. To refresh the list, press the Clear Table button and press Scan again. A new IP camera will display the factory IP address, 192.168.1.2. However, if multiple new devices are present on the network, then multiple instances of 192.168.1.2 will be listed.

  • Page 16: Change Network Setting Via Etroscan

    To identify a specific IP camera, use the MAC address which is located on the bottom of the camera. Below is an example of the label displaying the MAC address. Please note that a completed RMA (Return Merchandise Authorization) form must contain the serial number of the product.
  • Page 17 1. Double click on a specific IP address; the setting page will be displayed. 2. Click Change Setting… button at the bottom of the screen. Either method will display the network settings configuration. After altering the IP camera network settings, click Apply to apply the changes.
  • Page 18 A prompt for the administrator authentication will be displayed: The default password for the administrator account (root) is pass. Enter the default password and click OK to confirm the changes. The default password should be changed later after the initial configuration setup.

  • Page 19: Access The Ip Camera Web Interface

    2.4 Access the IP Camera Web Interface MS Internet Explorer is used to access and configure the IP camera. When accessing an IP camera using the web interface for the first time, some configuration for ActiveX controls may be required. 7.
  • Page 20 The error indicates the browser requires adding certain ActiveX controls for the viewer to work. Near the top of the browser page is a message regarding an add-on to run. The request is highlighted below in blue. Clicking on the add-on message will bring up options; choose Run Add-on to add.
  • Page 21 Wait for the add-on to complete and the page to attempt reloading. Most likely other ActiveX controls will be required. Repeat the above procedure of adding ActiveX controls until the no other add-on requests are displayed and the Live View page loads without error.

  • Page 22: Etrolink™ Configuration Port

    ETROLINK™ CONFIGURATION PORT The EtroLink™ USB Configuration Port provides an easy, alternate method of configuring network settings, restoring factory default settings and changing the administrator password. The EtroLink™ USB Configuration allows configuration using a Quick Config Wizard which requires no software installation. 3.1 OS Requirements The PC which will access the IP camera using the EtroLink™...

  • Page 23: Connecting The Ip Camera To The Pc

    Connecting the IP camera to the PC 3. Unplug the IP camera’s power cable and network cable 4. Connect EtroLink™ and PC via the mini USB cable. 5. Once the PC detects the IP camera, wait for a pop-up dialog prompting the user for a program choice.

  • Page 24: Quick Config Login

    Quick Config Login The default administrator login is: root Password: pass Use the default login if:  this is the initial configuration  a login after restoring factory settings  the password hasn’t been modified Otherwise, use the existing password if it has already been changed. Click the Login button;...

  • Page 25: Quick Wizard - Network

    Quick Wizard - Network The Quick Wizard button is used to configure network and DDNS settings. Clicking Quick Wizard will display Step 1. Step 1 The network configuration options include “Static IP”, “DHCP”, and “PPPoE”. Select an option and click Next.
  • Page 26 Step 2 Selecting “Static IP” and clicking Next will display the following Step 2 page: Selecting “DHCP” and Next will display the following Step 2 page: Selecting “PPPoE” and Next will display the following Step 2 page:...

  • Page 27: Manually Starting The Quick Config Wizard

    Enter all the relevant network settings, and click Next to proceed to Step 3. Step 3 Regardless of network connection type, step 3 and 4 are the same. Change the port information if applicable, then click Next. First a confirmation dialogue will be displayed.

  • Page 28: Factory Default

    2. Wait a moment for the PC to recognize the IP camera as a new drive. 3. Using Windows Explorer, find the IP camera represented as a new drive. The Etrovision logo should help identify the specific drive. 4. Highlight the drive (i.e. E:) to view he contents.
  • Page 29 Click OK to proceed. Another dialogue to disconnect the device will be displayed. Disconnect the IP camera from the PC and click OK. The IP camera can now be accessed via the factory default network settings.

  • Page 30: Additional Information

    For more information on configuring and using the EV6356A IR Outdoor IP Camera, please refer to the “EV6356A IR Outdoor IP Camera User’s Manual”. This manual is available on the product CD, or it can be downloaded from the Etrovision website, www.etrovision.com.
