EtroVISION EV6250A SERIES Assembly Manual

Speed dome ip camera
Hide thumbs Also See for EV6250A SERIES:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual, Installation Manual
EV6250A Series

Speed Dome IP Camera

Assembly Guide – Version 6.3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EV6250A SERIES and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EtroVISION EV6250A SERIES

Summary of Contents for EtroVISION EV6250A SERIES

  • Page 1: Speed Dome Ip Camera

    EV6250A Series Speed Dome IP Camera Assembly Guide – Version 6.3...

  • Page 2: About This Guide

    © 2011 Etrovision Technology. All rights reserved. Information contained in this document may be superseded by updates. No representation or warranty is given and no liability is assumed by Etrovision Technology with respect to the accuracy or use of the information, or infringement of patents or other intellectual property rights.

  • Page 3: Table Of Contents

    EV6250A-[B, C, D] OUTDOOR HOUSING ........4 Components Checklist ................4 Camera Components .................. 4 Additional Components ................4 Required Tools & Material ................4 Assembly Instructions ................. 4 Bracket Setup ....................4 Camera Assembly Instructions ..............6 EV6250A-[B, C, D] INDOOR HOUSING ......... 16 Components Checklist ................

  • Page 4: Ev6250A-[B, C, D] Outdoor Housing

    1 EV6250A-[B, C, D] OUTDOOR HOUSING 1.1 Components Checklist The packaging will include the following materials. Camera Components • Outer Housing • Inner Housing (includes a camera module fixed within the housing) • Dome Cover • Camera Additional Components • Power Adapter x 1 •...
  • Page 5 Align the screws and power box, and tighten the screws to connect the brackets and power box. Pole Mount Bracket Fix the bracket on the rear of the power box. Loop the stainless steel rings through the bracket slots to complete.

  • Page 6: Camera Assembly Instructions

    Pendant Mount Fix the iron tube on the top of the power box. Camera Assembly Instructions Insert the plastic, cable conduit into the opening in the power box. Using the accompanying plastic bolt, tighten bolt to secure the conduit.
  • Page 7 Affix the power box to the wall or mounting. To prevent water getting into the camera housing, apply the thread seal tape to the threading on the top of the outer housing. NOTE: Please follow the sequence of steps as outlined below. To avoid pulling cables loose during installation, do not connect cables to the camera board until the bracket arm and housing have been joined together.
  • Page 8 Insert the combo cable connectors into the top of the outer housing into the camera module.
  • Page 9 Screw the outer housing into the bracket arm by turning the housing from left to right.
  • Page 10 Using a hex key, secure the outer housing to the bracket arm. Within the outer housing, unscrew the fastening screw on the camera module’s faceplate. Gently pull open faceplate to expose the module.
  • Page 11 Connect the 30 pin connector to the 30 pin port. The connector has 2 slots on one side which must be aligned with the 2 ridges on the port. The 30 pin connector will have 2 additional connectors (both 2 pins) which must be connected to the J12 and J13 ports.
  • Page 12 Close the camera module and screw the fastening screw to secure the module’s faceplate. Remove all packaging material from the within the camera dome. Ensure all packaging has been removed; a failure to do so will prohibit camera movement and potentially damage the camera. Insert the camera into the inner housing.
  • Page 13 The housing’s camera saddle points are highlighted below.
  • Page 14 While not pushing too firmly, push down to make sure the connector is inserted into the port. Verify the camera mounts are settled properly into the saddle. Spin the camera dome to find the 2 slotted screw heads on the base inside of the camera;...
  • Page 15 Run the combo cable through the power box cable conduit. Using the two screws provided, screw shut bracket arm/power box housing. Connect the power cable to the combo cable power connector. The camera will perform a test scan movement during startup. If the camera doesn’t move or there is no power, then likely the camera module cabling needs to be verified.

  • Page 16: Ev6250A-[B, C, D] Indoor Housing

    2 EV6250A-[B, C, D] INDOOR HOUSING 2.1 Components Checklist The packaging will include the following materials. Camera Components • Outer Housing • Inner Housing (includes a camera module fixed within the housing) • Dome Cover • Camera Additional Components • Power Adapter x 1 •...
  • Page 17 Slide the anchor clips into the outer housing slots and secure the clasp. A gap should exist between the clip and the outer housing rim; this gap is where the clip will rest on the ceiling for support. Using the securing cable within the outer housing, secure the inner housing to the outer housing by affixing the securing cable to the loop on top of the inner housing.
  • Page 18 Within the inner housing, unscrew the fastening screw on the camera module’s faceplate. Gently pull open faceplate to expose the module. Insert the combo cable into the top of the inner housing into the camera module.
  • Page 19 Place the inner housing into the outer housing. Secure the inner housing to the outer using the 3 screws provided. Connect the 30 pin connector to the 30 pin port. The connector has 2 slots on one side which must be aligned with the 2 ridges on the port The 30 pin connector will have 2 additional connectors (both 2 pins) which must be connected to the J12 and J13 ports.
  • Page 20 can be used identify whether the cabling should use the J12 or J13 port. Find the board ports labeled J12 and J13.One side of the board has a J13 port and the other side has a J12 port. Close the camera module and screw the fastening screw to secure the module’s faceplate.
  • Page 21 Remove all packaging material from the within the camera dome. Ensure all packaging has been removed; a failure to do so will prohibit camera movement and potentially damage the camera. Insert the camera into the inner housing. The camera’s blue connector must be aligned with the blue port on the camera module’s faceplate within the inner housing.
  • Page 22 The housing’s camera saddle points are highlighted below. Push down gently to insert the connector into the port and verify the pins have settled properly into the mounts. Spin the camera dome to find the 2 slotted screw heads on the base inside of the dome camera.
  • Page 23 The camera will perform a test scan movement during startup. If the camera doesn’t move or there is no power, then likely the camera module cabling needs to be verified. Unplug the power before disassembling and verifying cabling. Slide the camera into the hole in the ceiling. Make sure the clips are set back far enough from the outer housing lip and ceiling to catch the ceiling and prevent the camera from falling through the hole.

  • Page 24: Ev6250A-[E, F, G] Outdoor Housing

    3 EV6250A-[E, F, G] OUTDOOR HOUSING 3.1 Components Checklist The packaging will include the following materials. Camera Components • Power Junction Box • Tube Arm • Outer Housing • PTZ Camera • Plastic Camera Cover Additional Components • RS-485/DI-DO Adapter Cable •...
  • Page 25 Run the cabling from the dome housing into the arm tube. Using the 4 screws, secure the tube and dome housing. Run cabling into the junction box.
  • Page 26 : Insure electrical power has been disconnected before proceeding with the electrical wiring and junction box configuration. Connect AC power to AC IN, ground, and camera power cable to power block terminal. Connect remaining cabling. The table below describes the DI/DO & RS485 cabling using the adapter.
  • Page 27 NONE Blue/White NONE Blue RS485- Brown/White RS485+ Brown The adapter should be connected to the black line. Using the 4 screws provided, secure tube arm to the junction box. If the device address requires modification, adjust the dip switch settings located on the base of the PTZ camera.
  • Page 28 Don’t Address ID Change Protocol and baud rate can be changed using the blue panel dip switch. Eyeview Pelco P-9600 Pelco P-4800 Pelco D-2400 Before installing the PTZ camera into the dome housing, remove the plastic pin from the base of the PTZ camera.
  • Page 29 Connect the safety catch wire from the dome house to the hook PTZ camera. Also connect the camera’s 6-pin connector to the dome housing. Insert the camera into the dome housing, turn the camera in the direction of “CLOSE” label to lock the camera into the dome housing. Remove the lens cover.

  • Page 31: Ev6250A-[E, F, G] Indoor Housing

    4 EV6250A-[E, F, G] INDOOR HOUSING 4.1 Components Checklist The packaging will include the following materials. Camera Components • Camera Base • PTZ Camera • Combo Cable • Plastic Cover Additional Components • Power Adapter x 1 • Product CD x 1 •...
  • Page 32 If the camera will be mounted in the hanging bracket, then use the drill hole template to drill pilot holes. The included screws, washers & nuts can be used for mounting the hanging bracket. Otherwise drill pilot holes to mount camera directly on the ceiling. Connect the combo cable and network cable.
  • Page 33 Orange/White Orange Green/White Green NONE Blue/White NONE Blue RS485- Brown/White RS485+ Brown The adapter should be connected to the black line. If the device address requires modification, adjust the dip switch settings located on the base of the PTZ camera. Refer to section 5 for dip switch settings.
  • Page 34 Don’t Address ID Change Protocol and baud rate can be changed using the blue panel dip switch. Eyeview Pelco P-9600 Pelco P-4800 Pelco D-2400 Before installing the PTZ camera into the dome housing, remove the plastic pin from the base of the PTZ camera.
  • Page 35 Connect the safety catch wire from the dome house to the hook PTZ camera. Also connect the camera’s 6-pin connector to the dome housing. Insert the camera into the dome housing, turn the camera in the direction of “CLOSE” label to lock the camera into the dome housing. Remove the lens cover.
  • Page 36 Affix the plastic dome cover on to the bottom on the dome housing, and remove the protective plastic covering.

  • Page 37: Ev6250A-[E, F, G] Id Configuration

    5 EV6250A-[E, F, G] ID CONFIGURATION Symbol “○” in the following tables denote setting “ON” 1 2 3 4 5 6 7 8...
  • Page 38 1 2 3 4 5 6 7 8...
  • Page 39 1 2 3 4 5 6 7 8...
  • Page 40 1 2 3 4 5 6 7 8...
  • Page 41 1 2 3 4 5 6 7 8...
