- Page 1 Stainless Steel Gas Grill USE AND CARE GUIDE MODEL NO.: 720-0145-LP ® FOR OUTDOOR USE ONLY PLEASE CONTACT 1-800-913-8999 FOR ASSISTANCE DO NOT RETURN TO PLACE OF PURCHASE...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SECTION ONE SECTION FIVE Safety Instructions…………………………1~5 Using the side burner…………………… Placement of the grill………………………5 Care & Maintenance ………………. Trouble Shooting………………………… SECTION TWO Check List …………………. Rotisserie mount installation………….….6 20~21 Side shelf Assembly…………………….7 SECTION SIX Side burner Assembly ……………………8 Lighting Illustrations………………………. -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS ***** WARNING ***** FOR YOUR SAFETY If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. Open Lid. 4. If odor continues, immediately call your gas supplier or your fire department. FOR YOUR SAFETY 1. - Page 4 SAFETY INSTRUCTIONS RECOGNIZED SAFETY SYMBOLS, WORDS AND LABELS WARNING Do not try lighting this appliance without first reading the “LIGHTING INSTRUCTIONS” section of this manual. DO NOT USE ALUMINUM FOIL TO LINE THE GRILL RACKS OR GRILL BOTTOM. This can severely upset combustion airflow or trap excessive heat in the control area.
- Page 5 SAFETY INSTRUCTIONS RECOGNIZED SAFETY SYMBOLS, WORDS AND LABELS WARNING: Always keep your face and body as far away from the burner as possible when lighting. WARNING: IMPORTANT! BEFORE LIGHTING… Inspect the gas supply hose prior to turning the gas “ON”. If there is evidence of cuts, wear, or abrasion, it must be replaced prior to use.
- Page 6 SAFETY INSTRUCTIONS CHILDREN SHOULD NOT BE LEFT ALONE OR TESTED IN ACCORDANCE WITH ANSI Z21.58b UNATTENDED IN AN AREA WHERE THE GRILL IS LATEST STANDARD 1.6b-2002 BEING USED. NEVER ALLOW THEM TO SIT, STANDARD FOR OUTDOOR COOKING GAS STAND OR PLAY ON OR AROUND THE GRILL AT APPLIANCES.
-
Page 7: Placement Of The Grill
SAFETY INSTRUCTIONS When using the grill, do not touch the grill rack, burner under unprotected combustible construction. Use only in well grate or immediate surroundings as these areas become ventilated areas. Do not use in buildings, garages, sheds, extremely hot and could cause burns. Use only dry breezeways or other such enclosed areas. -
Page 8: Rotisserie Mount Installation
ROTISSERIE MOUNT INSTALLATION 1. The screws for rotisserie mount are already screwed into the left side of the grill. Remove the screws and install the rotisserie motor mount as shown in the figure Below. -
Page 9: Side Shelf Assembly
SIDE SHELF ASSEMBLY 1. The screws used to attach the side shelf are already screwed into the two-side panel(see the figure below).remove the screws from the two-side panel, and put the side shelf to two-side panel, then tight screws for fixing strongly. -
Page 10: Side Burner Assembly
SIDE BURNER ASSEMBLY Open the grill lid and remove the side burner from the fire box. The screws used to attach the side burner are already screwed into the side panels. Remove the screws from the side panels. 3. Align the holes of the right side burner with those in the side panels, insert the screws and tighten. -
Page 11: Side Shelf Handle Assembly
SIDE SHELF HANDLE ASSEMBLY 1. The screws used to attach the side shelf handle are already screwed into the side shelf handle(see the figure below).remove the screws from the side shelf handle, align with the holes in the side shelf, and then secure into the holes on the right side shelf of the grill. -
Page 12: Spice Tray Assembly
SPICE TRAY ASSEMBLY 1. Hang up the spice tray into the holes on the left door as shown in the figure below. -
Page 13: Propane Tank Assembly
PROPANE TANK ASSEMBLY 1. Attach regulator to the propane tank by turning the regulator handle clockwise (FIGURE 1). 2. Turn off LP supply at cylinder when appliance is not in use. Put the gas tank into the gas tank pull-out tray. Then tighten up the gas tank fixed pole. -
Page 14: To Match Light The Grill
TO MATCH LIGHT THE GRILL 1. If the burner will not light after several attempts then the burner can be match lit. 2. If you’ve just attempted to light the burner with the igniter, allow 5 minutes for any accumulated gas to dissipate. Keep your face and hands as far away from the grill as possible. -
Page 15: Gas Hook-Up
Total gas consumption (per hour) of 720-0145-LP grill with CONNECTION: all burners on “HI”: Your grill is equipped with gas supply orifices for use only with liquid propane gas. -
Page 16: Leak Testing
LEAK TESTING GENERAL Should be visually checked. Although all gas connections on the grill are leak tested at the factory prior to shipment, a complete gas tightness check must be performed at the installation site due to possible mishandling in shipment, or excessive pressure unknowingly being applied to the unit. -
Page 17: Installer Final Check
INSTALLER FINAL CHECK Specified clearance maintained 24” from Unit tested and free of leaks. combustibles. User informed of gas supply shut off valve All internal packaging removed. location. Knobs turn freely. Burners are tight and sitting properly on orifices. PLEASE RETAIN THESE INSTRUCTIONS FOR Pressure regulator connected and set for 11.2”... -
Page 18: Operating Instructions
OPERATING INSTRUCTIONS General use of the grill and rotisserie The skewer for the rotisserie is assembled into the motor Each main burner is rated at 12,000 BTU/hr. The main grill assembly by placing the pointed end into the motor, and burners encompass the entire cooking area and are side then sliding the grooved bushing into the slot at the ported to minimize blockage from falling grease and debris. -
Page 19: Lighting Instructions
LIGHTING INSTRUCTIONS WARNING: IMPORTANT! these conditions exist call our customer service line. If the flame is yellow, it indicates insufficient air. If the BEFORE LIGHTING… flame is noisy and tends to lift away from the burner, it Inspect the gas supply hose prior to turning the gas indicates too much air. -
Page 20: Using The Side Burner
USING THE SIDE BURNER WARNING: IMPORTANT! control knob counterclockwise to the “HI” position. If USING THE SIDE BURNER: the burner does not light, turn the control knob to Inspect the gas supply hose prior to turning the gas “OFF”. If the smell of gas is detected and the igniter is “ON”. -
Page 21: Trouble Shooting
CARE & MAINTENANCE OF SIDE BURNER SIDE BURNER CLEANING: Clean the exterior of the burner with a wire brush. Clear any clogged burner ports with a straightened paper clip. Never enlarge the burner ports. Never use a wooden toothpick as it may break off and clog the port. -
Page 22: Check List
CHECK LIST PROBLEM SOLUTION When I light the grill it does not flame --Make sure you have turn on the gas immediately. --Make sure it has spark while you are trying to ignite the burner. --Push in for approximately 5 second before to turn and ignite the grill. - Page 23 Rotisserie motor will not turn --Check the voltage at the outlet. --If an extension cord is required, ensure it is a 16 gauges, grounded cord. --Ensure the on/off switch is on. --Ensure the load does not exceed the 40 pounds operational capacity.
-
Page 24: Lighting Illustrations
LIGHTING ILLUSTRATIONS Main Burner Lighting Illustration Rotisserie Burner Lighting Illustration 1.Make sure the lid is open 1. Push and turn the rotisserie knob to HI. 2. Push and turn one of main burner knobs 2. Press the electric igniter 3 to 4 to to HI position seconds light the rotisserie burner. -
Page 25: Exploded View
EXPLODED VIEW... -
Page 26: Parts List
MODEL 720-0145-LP PARTS LIST REF# DESCRIPTION Q’TY REF# DESCRIPTION Lid, Front Gas valve,Side burner Heat Indicator Gas hose connector Name Plate Frame,Cart Heater Insulating Spacer Magnet Handle Assembly, Lid heat insulation Bowl assembly Light Rod Spit Rod Door Assembly Shaft Collar... -
Page 27: Grilling Hints
GRILLING HINTS The doneness of meat, whether rare, medium, or well Use a spatula instead of tongs or a fork to turn the done, is affected to a large degree by the thickness of meat, as a spatula will not puncture the meat and let the cut. -
Page 28: Grill Cooking Chart
GRILL COOKING CHART FOOD WEIGHT OR FLAME APPROXIMATE SPECIAL INSTRUCTIONS THICKNESS SIZE TIME AND TIPS VEGETABLES Slice. with butter margarine. Wrap in heavy-duty foil. Grill, turning occasionally. Fresh: Beets Medium 12 to 20 minutes Grill, turning once. Brush Carrots occasionally with melted butter Turnips or margarine. - Page 29 Lamb Chops & Steaks Rare 1 inch High 10 to 15 minutes Remove excess fat from edge. Slash remaining fat at 2-inch intervals. Grill, turning once. 1-1/2 inch High 14 to 18 minutes Medium 1 inch Medium to 13 to 20 minutes 1-1/2 inch High 18 to 25 minutes...
-
Page 30: Grill Recipe Suggestion
GRILL RECIPE SUGGESTIONS BBQ SALMON 1 20 oz. Can pineapple chunks in juice aluminum foil. Bake covered 25 minutes 2 large salmon steaks drained In medium bowl, combine shrimp on medium with the lid of your BBQ grill 2 tbs. oil and scallops. - Page 31 ½ tsp. salt Bring marinade to boil on the side 1 chicken bouillon cube ½ tsp. celery salt burner in a saucepan. Add remaining 1 can beer for basting sauce tsp. garlic powder 1/3 c. water and peanut butter. Stir to ½...
-
Page 32: Limited Warranty
LIMITED WARRANTY MODEL 720-0145-LP STAINLESS STEEL OUTDOOR GAS GRILL Nexgrill Industries, Inc. warrants to the original consumer purchaser of each Outdoor Gas Grill that when subject to normal residential use, it is free from defects in workmanship and materials for the periods specified below. This warranty excludes grills used in rental or commercial applications.
