VADDIO CCU Image Controller Manual page 7

CCU Image Controller for CeilingVIEW HD-18 DocCAM
General Specifications:
CCU Image Controller P/N: 999-1105-023
Connectors:
LCD Display
RS-232 Cat-5e Cable
Distance
Baud Rate
Power Supply
Power Cables
Dimensions
Weight
Operating Range
Compatible Cameras
(Works with other
Vaddio Cameras)
Other General Information:
Care and Cleaning
Do not attempt to take this product apart at any time. There are no user-serviceable components inside.

Do not spill liquids or liquid type substances onto the device.

Keep this device away from food or liquid.

Clean the whiteboard regularly with a good quality whiteboard cleaner, but do not spray on the electronics

For smears or smudges on the devices, wipe with a clean, soft cloth.

Do not use any abrasive pads or caustic chemicals at any time on any Vaddio equipment.
Operating and Storage Conditions:
Do not store or operate the device under the following conditions:

Temperatures above 40°C (104°F) or temperatures below 0°C (32°F)

High humidity, condensing or wet environments

In inclement weather

Dry environments with an excess of static discharge

In outer space (under normal circumstances)

Under severe vibration

High humidity, condensing or wet environments or in a swimming pool

Dusty environments or outside in direct sunlight
CCU Image Controller for CeilingVIEW HD-18 DocCAM - Document 342-0197 Rev. A

Power Connector: 5.5mm OD x 2.5mm ID

RS-232 IN RJ-45: Accepts RS-232 from ProductionVIEW or other non-daisy-
chain control systems

RS-232 OUT RJ-45: Sends/Receives RS-232 to the CeilingVIEW HD-18
DocCAM

Tally: 2-Pin Phoenix type spring cage connector
2-Line Blue Back-lit Character Display
Up to 100' (30.48m), Note: Quick-Connect SR and Quick-Connect DVI/HDMI SR
will supply power to the camera and return video at 100' (30.48m).
9600 bps (9600 bps - best over distance)
12 VDC, 1.0 Amp Switching Power Supply
Worldwide Package includes North American, Euro and UK power cables
1-RU Rack Mount - 1.72" (43.69mm) H x 18.93" (480.82mm W x 6" (152.4mm) D
3.20 lbs (1.45149568 kg)
Temperatures above 40°C (104°F) or temperatures below 0°C (32°F)
CeilingVIEW HD-18 DocCAM with Quick-Connect SR Interface
CeilingVIEW HD-18 DocCAM with Quick-Connect DVI/HDMI SR Interface
ClearVIEW HD-18 PTZ Camera
ClearVIEW HD-20 PTZ Camera
ClearVIEW HD-18 PTZ Camera with Quick-Connect SR Interface*
ClearVIEW HD-18 PTZ Camera with Quick-Connect DVI/HDMI SR Interface*
ClearVIEW HD-20 PTZ Camera with Quick-Connect SR Interface*
ClearVIEW HD-20 PTZ Camera with Quick-Connect DVI/HDMI SR Interface*
*Also Compatible with Vaddio HD-18 and HD-20 cameras using the CeilingVIEW
HD HideAway motorized lift system and enclosure.
Page 7 of 12
