CCU Image Controller for CeilingVIEW HD-18 DocCAM
System Connectivity Example:
Interface, CeilingVIEW HD-18 Series CCU Image Controller & ProductionVIEW HD
Quick-Connect DVI/HDMI
SR Interface
HD
Monitors*
CCU Image Controller for CeilingVIEW HD-18 DocCAM - Document 342-0197 Rev. A
Featuring the CeilingVIEW HD-18 DocCAM, Quick-Connect DVI/HDMI SR
CeilingVIEW
HD-18
DocCAM
Cat-5e Cable:
Power to Camera - HSDS Video from CeilingVIEW HD-18
YPbPr
Up to 1080p/60
PREVIEW
RS-232
RAR
RS-232
Vaddio ProductionVIEW HD
HD YPbPr or
SD or RGBHV
*Simulated Video Feeds
RS-232
Two (2) Cat-5e Cables
Up to 100' (30.48m)
CCU Image Controller for CeilingVIEW
PROGRAM
Page 6 of 12
