- Page 1 Globalmediapro SMR-A4/7C/54/2C 16 by 4 / 12 by 4 / 8 by 4 / 4 by 4 3G-SDI Matrix Operation Manual Operation Manual...
-
Page 2: Table Of Contents
CONTENTS 1. Introduction ..........1 2. Applications ..........1 3. Package Contents ........1 4. System Requirements ........1 5. Features ............2 6. Operation Controls and Functions ..... 3 6.1 Front Panel ..........3 6.2 Rear Panel ..........4 6.3 Remote Control ........5 6.4 RS-232 Pin Assignment ......6 6.5 RS-232 Commands .........6 7. -
Page 3: Introduction
1. INTRODUCTION The 3G-SDI Matrix series allows SD-SDI, HD-SDI and 3G-SDI signals to be shown on SDI displays while ensuring high bit-rates of 2.970 Gbps to give you fast signal transmission without signal loss. For professionals, this means that it is now easier to switch multiple 3G-SDI signals and split display of them on up to four SDI-equipped displays simultaneously. -
Page 4: Features
5. FEATURES • 3G-SDI input sources can be selected and split or switched to four 3G-SDI displays simultaneously • Operation at 2.970 Gbps, 2.970/1.001 Gbps, 1.485 Gbps, 1.485/1.001 Gbps and 270 Mbps • Supports SMPTE 425M (Level A and Level B), SMPTE 424M, SMPTE 292M, SMPTE 259M-C •... -
Page 8: Rs-232 Pin Assignment
6.4 RS-232 Pin Assignment Pins definition of modem cable Remote Controller SMR-A4/7C/54/2C Definition Definition Baud Rate: 19200 bps Data bit: 8-bit Parity: None Stop bit: 1-bit Flow Control: None 6.5 RS-232 Commands Command Description poweron Power ON poweroff Power OFF... -
Page 10: Specifications
8. SPECIFICATIONS SMPTE Standard 425M Level A & B, 424M, 292M, 259M-C SDI Transmission Rates 2.970 Gbps and 2.970/1.001 Gbps, 1.485Gbps, 1.485/1.001 Gbps and 270 Mbps Input Ports 16/12/8/4×BNC (SD/HD/3G-SDI) Output Ports 4×BNC (SD/HD/3G-SDI) SDI Timing Support SD-SDI: SMPTE 259M-C, 270 Mbit/s HD-SDI: SMPTE 292M, 1.485 &... -
Page 11: Acronyms
9. ACRONYMS ACRONYM COMPLETE TERM Bandwidth 2.97Gbit/s ≈ 3G Bayonet Neill-Concelman Serial Digital Interface...
