Summary of Contents for Globalmediapro SM-2C
- Page 1 Globalmediapro SM-2C 3G-SDI 4 by 4 Switcher/Splitter Operation Manual Operation Manual...
-
Page 2: Table Of Contents
CONTENTS 1. Introduction ..........1 2. Applications ........... 1 3. Package Contents ........ 1 4. System Requirements ......1 5. Features ..........2 6. Operation Controls and Functions ..3 6.1 Front Panel ........3 6.2 Rear Panel .........4 6.3 RS-232 Protocols .......5 6.4 Remote Control ........6 7. -
Page 3: Introduction
1. INTRODUCTION The 3G-SDI 4 by 4 Switcher/Splitter allows SD-SDI, HD-SDI and 3G-SDI signals to be switched from up to four SDI sources and split to four simultaneous SDI outputs while ensuring high bit rates of 2.970 Gbit/s to give you high bandwidth signal transmission without signal loss over long distances and can be controlled via IR or RS-232. -
Page 4: Features
5. FEATURES • Switch between four 3G-SDI input sources and split the output to four 3G-SDI displays simultaneously • Operation at 2.970 Gb/s, 2.970/1.001 Gb/s, 1.485 Gb/s, 1.485/1.001 Gb/s and 270 Mb/s • Supports SMPTE 425M (Level A and Level B), SMPTE 424M, SMPTE 292M, SMPTE 259M-C •... -
Page 7: Rs-232 Protocols
6.3 RS-232 Protocols 6.3.1 Pin Assignment Pins definition of modem cable 3G-SDI 4 by 4 Switcher/ Remote Controller Splitter Definition Definition Baud Rate: 19200 bps Data bit: 8-bits Parity: None Stop bit: 1-bit Flow Control: None 6.3.2 Commands Command Action poweroff Power OFF poweron... -
Page 10: Specifications
8. SPECIFICATIONS SMPTE Standard 425M Level A & B, 424M, 292M, 259M-C SDI Transmission 2.970 Gbit/s and 2.970/1.001 Gbit/s Rates Input 4×BNC (SD/HD/3G-SDI) Output 4×BNC (SD/HD/3G-SDI) SDI Timing Support SD-SDI: SMPTE 259M-C, 270 Mbit/s HD-SDI: SMPTE 292M, 1.485 & 1.485/1.001 Gbit/s 3G-SDI: SMPTE 424M/425M-AB, 2.970 &... -
Page 11: Acronyms
9. ACRONYMS ACRONYM COMPLETE TERM Bandwidth 2.97Gbit/s ≈ 3G Bayonet Neill-Concelman HDMI High Definition Multimedia Interface Serial Digital Interface...
