How to reassemble the pressure packing

Figure.1
First match the standard notches on the Inner Pot lid with the standard points on the pressure packing following the numerical order (1, 2, 3, 4, 5, 6).
Then, press the outer rim of the packing to insert it into the groove. To reassemble the pressure packing follow the order described below:
As the Figure 1 shows, put the point #1 on the pressure packing with the standard
notch #1 on the Inner Pot lid together before pressing the outer rim of the packing
to insert it into the groove. Repeat with points #2 to # 6.
3

How to double check whether the packing is well assembled

Visual inspection

Normal
assembly
(look for parts sticking out of the inner)
Abnormal
assembly
How to double check whether the packing is well assembled.
Check if the pressure packing is thoroughly
put into the groove by rubbing the inside rim
of the packing with a finger around the entire
circumference as shown in the picture.

Water boiling test

Pour water in the Inner Pot up to water level 2 (for "Rice") and press the Menu/Selection button to select the self-cleaning mode.
Then push the Pressure Cook/Turbo button.
Within 10 minutes, the pressure regulator weight will start rattling and hissing while emitting steam. If there is no steam coming out from the
pot other than through the pressure regulator weight the packing is well reassembled.
If steam comes out from other parts, stop the test and pull out the power cord. Wait until the pot cools down before removing the pressure
packing from the lid and reassembling them again. Then start the water boiling test again.
For a more precise water boiling test, you can wrap plastic around the circumference of the closed Top Cover. By doing so, you can easily
check where the steam leakage is.
Normal
assembly
If you still have a problem with reassembling the packing, please contact our Customer Service.
Standard notches
on the Inner Pot lid.
After matching the standard points 1 to 6, press the rest of the packing into the
groove by pushing on its outer rim.
Since a badly assembled packing can cause the rice to be
half-cooked or burned by steam leakage, double check the
packing thoroughly as described below.
check the entire circumference carefully for any crack or damage between
the Inner Pot lid and the pressure packing.
(look for parts sticking out of outer rim)
Check if the pressure packing is properly put
into the groove of the Inner Pot lid by pushing
the outer rim with a finger around the entire
circumference as shown in the picture.
Abnormal
assembly
HOW TO CLEAN
Standard points
on the pressure packing.
(look for parts sticking out of damaged parts)
Check if the pressure packing is thoroughly
put into the groove by pushing the inside of
the rim packing with a finger around the entire
circumference as shown in the picture.
