vacuubrand DCP 3000 Instructions For Use Manual

Hide thumbs Also See for DCP 3000:
Table of Contents

Advertisement

Quick Links

Download this manual
page 1 of 64
Technology for Vacuum Systems

Instructions for use

DCP 3000
Vacuum gauge

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DCP 3000 and is the answer not in the manual?

Questions and answers

Related Manuals for vacuubrand DCP 3000

Summary of Contents for vacuubrand DCP 3000

  • Page 1: Instructions For Use

    1 of 64 Technology for Vacuum Systems Instructions for use DCP 3000 Vacuum gauge...
  • Page 2 2 of 64 Dear customer, Your VACUUBRAND vacuum gauges are designed to provide you with many years of trouble-free service with optimal performance. Our many years of practical experience allow us to provide a wealth of application and safety information. Please read these instructions for use before the initial operation of your vacuum gauge.
  • Page 3 page 3 of 64 Achtung: Die vorliegende Betriebsanleitung ist nicht in allen EU-Sprachen verfügbar. Der Anwender darf die beschriebenen Geräte nur dann in Betrieb nehmen, wenn er die vorliegende Anleitung versteht oder eine fachlich korrekte Übersetzung der voll- ständigen Anleitung vorliegen hat. Die Betriebsanleitung muss vor Inbetriebnahme der Geräte vollständig gelesen und verstanden werden, und alle geforderten Maß- nahmen müssen eingehalten werden.
  • Page 4 page 4 of 64 Bemærk: Denne manual foreligger ikke på alle EU sprog. Brugeren må ikke be- tjene apparatet hvis manualen ikke er forstået. I det tilfælde skal en teknisk korrekt oversættelse af hele manual stilles til rådighed. Manual skal være gennemlæst og forstået før apparatet betjenes og alle nødvendige forholdsregler skal tages.
  • Page 5 page 5 of 64 Figyelem! Ez a kezelési utasítás nem áll rendelkezésre az EU összes nyelvén. Ha a felhasználó nem érti jelen használati utasítás szövegét, nem üzemeltetheti a készüléket. Ez esetben a teljes gépkönyv fordításáról gondoskodni kell. Üzembe helyezés előtt a kezelőnek végig kell olvasnia, meg kell értenie azt, továbbá az üzemeltetéshez szükséges összes mérést el kell végeznie.
  • Page 6 page 6 of 64 Attentie: Deze gebruiksaanwijzing is niet in alle talen van de EU verkrijgbaar. De gebruiker moet niet met dit apparaat gaan werken als voor hem/haar de gebruiks- aanwijzing niet voldoende duidelijk is. Bij gebruik van deze apparatuur is het nood- zakelijk een technisch correcte vertaling van de complete gebruiksaanwijzing te hebben.
  • Page 7 page 7 of 64 Varning: Denna instruktion är inte tillgänglig på alla språk inom EU. Användaren får inte starta utrustningen om hon/han inte förstår denna instruktion. Om så är fallet måste en tekniskt korrekt instruktion göras tillgänglig. Instruktionen måste läsas och förstås helt före utrustningen tas i drift och nödvändiga åtgärder göres.

  • Page 8: Reset / Language Selection

    page 8 of 64 Reset / Language selection press both switch off D C P 300 0 V 2. 0 D eut s ch P ort u guê E ngl i sh Ρ yccк ий Fra nçai s P ol ski I t al i ano N eder l .

  • Page 9: Table Of Contents

    page 9 of 64 Contents Reset / Language selection ..........8 Safety information! ............11 Important information! ................11 General information ................13 Intended use..................13 Setting up and installing the equipment ..........14 Ambient conditions ................15 Operating conditions ................. 16 Safety during operation ..............
  • Page 10 page 10 of 64 Notes concerning the data logger function (recording and sending of data) ............44 Read commands ................46 Write commands ................48 Troubleshooting ............... 49 Accessories ..............51 Cleaning the pressure transducer ........52 Calibration in the factory ..........53 Readjustment of VSK 3000 ..........

  • Page 11: Safety Information

    Make operating personnel aware of dangers arising from the processed substances. VACUUBRAND disclaims any liability for inappropri- ate use of this equipment and for damage from failure to follow instructions contained in this manual. This manual is only to be used and distributed in its com- plete and original form.
  • Page 12 page 12 of 64 ➨ DANGER indicates a hazardous situation which, if not avoided, will result in death or serious injury. + WARNING indicates a hazardous situation which, if not avoided, could result in death or serious injury. • CAUTION indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.

  • Page 13: General Information

    13 of 64 General information To operate the vacuum gauge DCP 3000, at least one external pressure transducer (VSK 3000 or VSP 3000 or MPT 100) is required! Remove all packing material from the packing box. Re- NOTICE move the product from its packing-box and retain all pack- aging until the equipment is inspected and tested.

  • Page 14: Setting Up And Installing The Equipment

    page 14 of 64 + The equipment is designed for operation at ambient temperatures and gas temperatures at the pressure transducer between +50°F and +104°F (+10°C and +40°C), or for short periods up to +176°F (+80°C) at the pressure transducer (gas temperature). Periodical- ly check maximum temperatures if installing the equip- ment in a cabinet or a housing.

  • Page 15: Ambient Conditions

    page 15 of 64 • Check the power source and the equipment’s rating plate to be sure that the power source and the equipment match in voltage, phase, and frequency. • When working with residues, aggressive or condens- able media, install a gas washing bottle if necessary. The vacuum gauge is equipped with a short-circuit-proof NOTICE wide-range power supply with an integrated overload pro-...

  • Page 16: Operating Conditions

    page 16 of 64 • Adopt suitable measures in case of differences from recommended conditions, e.g., using the equipment outdoors, or in an atmosphere of conductive pollution or external condensation. • Do not operate this product near flames. To the best of our knowledge the equipment is in com- NOTICE pliance with the requirements of the applicable EC-direc- tives and harmonized standards (see ”Declaration of Con-...

  • Page 17: Safety During Operation

    page 17 of 64 Safety during operation ➨ Adopt suitable measures to prevent the release of dangerous, toxic, explosive, corrosive, noxious or pol- luting fluids, vapors and gases. + Never operate this vacuum gauge if it has a damaged cord or plug. If the vacuum gauge is not working prop- erly, has been dropped or has fallen into water, contact your service provider.

  • Page 18: Maintenance And Repair

    page 18 of 64 Maintenance and repair ➨ Switch off the vacuum gauge. Disconnect the power supply and wait five seconds before starting maintenance to allow the capacitors to discharge. ➨ Note: The equipment may be contaminated with chemicals, which have been processed during op- eration.

  • Page 19: Important Information: Equipment Marking (Atex)

    The overall category of the equipment depends on the connected com- ponents. If the connected components do not comply with the classifi- cation of the VACUUBRAND equipment, the specified category of the VACUUBRAND equipment is no longer valid. Vacuum pumps and vacuum gauges in category 3 are intended for con- nection to equipment in which during normal operation explosive atmo- spheres caused by gases, vapors or mists normally don’t occur;...
  • Page 20 page 20 of 64 The pumps are marked with ”X” (according to EN 13463-1), i.e., restric- tions of the operation conditions: • The equipment is designated for a low degree of mechanical stress and has to be installed in a way so that it cannot be damaged from outside.

  • Page 21: Technical Data

    21 of 64 Technical data Technical data of display unit Display unit DCP 3000 Display LCD graphic display, illuminated Pressure units / scale (selectable) Torr, mbar or hPa Measurement range with active pressure transducer: VSK 3000 795 Torr - 0.1 Torr (1060 mbar - 0.1 mbar)

  • Page 22: Technical Data Of Pressure Transducers

    page 22 of 64 Technical data of pressure transducers Type VSK 3000 VSP 3000 ceramic diaphragm thermal conductivity (alumina), capacitive, Pressure transducer according to Pirani, absolute pressure, gas type dependent gas type independent Measuring range 795 - 0.1 Torr 7.5*10 Torr - 1*10 Torr (absolute)
  • Page 23 page 23 of 64 Type VSK 3000 VSP 3000 Housing dimensions 2.4” (60 mm) 2.4” (60 mm) diameter length 2.4” (60 mm) 2.3” (58 mm) with small flange 3.7” (95 mm) 3.8” (97 mm) with hose nozzle 2.5” (63 mm) with connection for PTFE tube small flange KF 16 or...

  • Page 24: Wetted Parts

    page 24 of 64 Wetted parts Components Wetted materials VSK 3000 Sensor Aluminum oxide ceramic Sensor housing, measurement chamber PPS, glass fiber Seal at sensor Chemically resistant fluoroelastomer Hose nozzle Clamping ring Small flange Stainless steel VSP 3000 Sensor Aluminum oxide ceramic Sensor housing, measurement chamber, PBT, glass fiber / PUR small flange...

  • Page 25: Use And Operation

    Display and symbols When switching on the DCP 3000 for the very first time, a menu to select the language of the vacuum gauge’s menu is displayed. Select the de- sired language (e.g., ”English”) by turning the selection knob and press to confirm.
  • Page 26 page 26 of 64 VSK 1 VSP 1 1013 mbar mbar mbar VSK 1 / VSP 1 active pressure transducer (status line) venting valve switched on (if connected) warning notice (if necessary in combination with other symbols), flashing 1013.2 actual absolute pressure at the pressure transducer mbar Torr preselected pressure unit...
  • Page 27 • A short tap vents momentarily • Pressing longer than 2 seconds vents the system to atmospheric pressure. ON/OFF switch Rear side DCP 3000 jacks for connection of external pressure transducer and/or venting valve Connection plug of the power supply...

  • Page 28: Changing The Vacuum Connector At Pressure Transducer Vsk 3000

    page 28 of 64 Changing the vacuum connector at pressure transducer VSK 3000 Installing the hose nozzle: Unscrew the flange (using a 17 mm open-end wrench, if necessary) to expose the compression fitting (1). Slip the compression nut, and then the ferrule, onto the smooth end of the supplied hose nozzle (2).

  • Page 29: Notes On Operation

    page 29 of 64 Notes on operation Operation principle of the VSK 3000 The VSK 3000 is equipped with a capacitive pressure transducer with ceramic diaphragm to measure the actual pressure independent of the gas type and depending on the vacuum, i.e., absolute. The pressure value is displayed with a resolution of 0.1 Torr (mbar) in the pressure range from 0.1 to 795 Torr (0.1 to 1060 mbar).
  • Page 30 30m (~32yd) (extension cable VACUU•BUS 2m (6.6ft): order-no. 612552 / extension cable VACUU•BUS 10m (32.8ft): order-no. 2618493). Do not use more than one DCP 3000 within the same VACUU•BUS system. Several DCP 3000 in the same VACUU•BUS system will inter- fere with each other and result in error messages of the connected com- ponents (pressure transducers, valves).
  • Page 31 ➨ Connect the VSK 3000 or VSP 3000 gauge head by its connecting cable (VACUU•BUS line) to a jack at the rear side of the DCP 3000. ➨ Connect the gauge head to the vacuum chamber via either the small flange connection, the hose nozzle, or PTFE tubing.
  • Page 32 Connected components (valves, pressure transducers, etc.) are au- tomatically identified, used and monitored until the device is switched off. Reconfiguration is possible by switching the DCP 3000 off/on. Identi- cal components must be configured beforehand to different VACUU•BUS addresses (e.g., VSK 1 and VSK 2), see section “Connecting several pressure transducers”, pg.

  • Page 33: Menu Guide

    page 33 of 64 Menu guide pressure indication pressure indication with VSK 3000 with VSP 3000 VSK 1 VSP 1 1013 mbar mbar Configuration Adjustment 760 Torr RS-232 . . . Sensors . . . Display . . . Setpoint . . . Log Data - - - - - - - Graphic - - - - - - - - - - - - - - - Back - - - - - - - -...
  • Page 34 page 34 of 64 RS-232 Baud 19200 Parity 8-N-1 Handshake RTS-CTS Send Data Cancel - - - - - - - - Back - - - - - - - - Sensors VSK 1 750 Torr VSP 1 1.0E+2 Torr VSK 2 600 Torr VSP 2...

  • Page 35: Configuration

    In the ”Configuration” menu the device parameters are preselected. Preselections + Use the selection knob to select the parameters. ➨ Switch the DCP 3000 on. ➨ Press the selection knob. ➨ Turn the selection knob to choose a menu and confirm by pressing the selection knob.
  • Page 36 Maximum number of pressure transducers of the same type (VSK 3000 or VSP 3000 or VSK 3000 configured as reference) connected to one DCP 3000: four. You may replace up to four VSP 3000 pressure transducers by MPT 100 pressure transducers.

  • Page 37: Connecting Several Pressure Transducers

    (VSK 3000 or VSP 3000) connected to one DCP 3000: four. Alternatively connect one MPT 100 instead of one VSP 3000 (requires DCP 3000 software version 2.03 or higher) or up to four MPT 100 instead of VSP 3000 (requires DCP 3000 software version 2.22 or higher). That is a total of eight external pressure transducers at maximum.

  • Page 38: Automatic Switching Between Pressure Transducers Vsk 3000 And Vsp 3000

    3000 and VSP 3000 If both a pressure transducer VSK 3000 and VSP 3000 are connected to the vacuum gauge DCP 3000, the DCP 3000 automatically displays the readings of the pressure transducer more suitable in the current pressure range.

  • Page 39: Reconfiguring The Pressure Transducer Vsp 3000 Or Vsk 3000

    2. Preferably connect only the pressure transducer to be reconfigured to the DCP 3000. 3. Keep the ”VENT” key pressed and switch the DCP 3000 on (”ON/ OFF” key). Release the ”VENT” key. 4. Select the menu item ”Vacuubus” by turning and pressing the selec- tion knob.
  • Page 40 40 of 64 A configuration of more than one pressure transducer to the same VACUU•BUS address will result in error conditions at the DCP 3000 and must therefore be avoided! Do not configure a VSK 3000 as VSP 3000.

  • Page 41: Setpoints

    MPT 100 is connected to the DCP 3000 vacuum gauge (VACUU•BUS address ”VSK x”, ” VSP x” or ”MPT x”). - a valve or a digital I/O interface is connected to the DCP 3000 and con- figured to the according VACUU•BUS address ”SP x” to be operated by setpoints (see below on how to configure components for working with setpoints).

  • Page 42: Configuring Valves Or Digital I/O Interfaces For Operation With Setpoints

    2. Preferably connect only the component to be reconfigured to the DCP 3000. 3. Keep the ”VENT” key pressed and switch the DCP 3000 on (”ON/ OFF” key). Release the ”VENT” key. 4. Select the menu item ”Vacuubus” by turning and pressing the selec- tion knob.

  • Page 43: Interface Parameters

    43 of 64 Interface parameters The vacuum gauge DCP 3000 is equipped with a serial interface (RS 232C, nine-pin Sub-D-plug). + Plug-in or remove the cable (cable RS 232C) from the interface only if the equipment is switched off.

  • Page 44: Notes Concerning The Data Logger Function (Recording And Sending Of Data)

    page 44 of 64 Notes concerning the data logger function (recording and sending of data) • Maximum number of recordable readings: 32765. • A runtime is displayed during the recording. • The data of all connected pressure transducers are recorded, i.e., in case of two connected pressure transducers a maximum of 16382 readings per pressure transducer will be recorded.
  • Page 45 Example: Windows* HyperTerminal: Select ”Transfer menu - Capture text”. In the file box, type a descriptive name for the file, and then click ”Start”. Send command ”IN_PV_D” or select at the DCP 3000 ”RS 232 - Data - Send”. * Windows is a trade mark of Microsoft Corporation in the USA and other countries.

  • Page 46: Read Commands

    IN_PV_X nected pressure X.XXE±X X.XXE±X sure transducers transducers ...mbar/Torr/hPa* XXX.XX:XX:XX X IN_PV_D data readout read out data from DCP 3000 memory ...mbar/Torr/hPa* yXXXXXX y: 0..D: language (hexadecimal) X0XXXXX pressure unit mbar X1XXXXX pressure unit Torr X2XXXXX...
  • Page 47 page 47 of 64 Command Operation Response Description XXXX.X mbar/Torr/ hPa* IN_SP_1y setpoint On y: 1..4: setpoint On y X.XXE±X mbar/ Torr/hPa* XXXX.X mbar/Torr/ hPa* IN_SP_2y setpoint Off y: 1..4: setpoint Off y X.XXE±X mbar/ Torr/hPa* unit according to preselections ** Language: *** numbering corresponds to order 0: German...

  • Page 48: Write Commands

    OUT_VENT venting valve open valve venting until atmospheric pressure external pressure transducers (if con- OUT_SENSOR 1..8 nected) switch DCP 3000 off REMOTE switch DCP 3000 on XXXX.X mbar/ Torr/hPa* X.XXE±X mbar/ OUT_SP_1y setpoint On y: 1..4: setpoint On y Torr/hPa* or X.XXE±0X...

  • Page 49: Troubleshooting

    ✔ Plug in power supply. plugged in (wall plug)? Check mains fuse No power available? ➨ DCP 3000 switched ✔ Switch on DCP 3000. off? ➨ VACUU•BUS cable ✔ Plug in VACUU•BUS of power supply not cable at DCP 3000.
  • Page 50 page 50 of 64 Fault Possible cause Remedy ❑ Displayed pressure ➨ Position of the pressure ✔ Readjust pressure trans- value is fluctuating. transducer VSK 3000 ducer, if exact pressure has been changed (e.g. indication is required. from horizontal to verti- cal)? Fluctuation of the displayed pressure in the range of 0.2 - 0.4...

  • Page 51: Accessories

    VACUU•BUS Digital-I/O-Module ..............636228 (e.g., fault indicator) VACUU•BUS Analog-I/O-Module ..............636229 (for output of vacuum values as analog voltage) PC-Software VACUU•CONTROL ..............692920 Conversion of VACUUBRAND valve with DIN plug to VACUUBRAND valve with VACUU•BUS plug: VACUUBRAND-valve with DIN Conversion kit valve cable with plug VACUU•BUS plug...

  • Page 52: Cleaning The Pressure Transducer

    page 52 of 64 Cleaning the pressure transducer The vacuum gauge itself is maintenance free. Condensate and deposits will affect the measurement results and/or the adjustment of the pressure transducer. Attention: Never use a pointed or sharp-edged tool to NOTICE clean the pressure transducer.

  • Page 53: Calibration In The Factory

    Federal Republic of Germany for the field of metrology and certain sectors of safety engineering). To order DAkkS calibration of the DCP 3000 with external pressure transducer VSK 3000 / VSP 3000, order number: ................900215...

  • Page 54: Readjustment Of Vsk 3000

    ➨ head VSK 3000. Make sure that the pressure transducer is at atmo- spheric pressure. ➨ In ”Configuration” menu, select program ”Adjustment” at the DCP 3000. ➨ Use the selection knob to adjust the reading to the current atmospheric pressure. ➨ Press the selection knob to confirm.
  • Page 55 VSK 3000 to a pressure < 0.1 Torr (mbar) (e.g., by apply- ing a good two-stage rotary vane pump). ➨ In ”Configuration” menu, select program ”Adjustment” at the DCP 3000. + The reading is automatically adjusted to ”zero”. ➨ Press the selection knob to confirm.

  • Page 56: Readjustment Of Vsp 3000

    + During the first 20 minutes after having connected the pressure transducer VSP 3000 to a energized vacuum gauge DCP 3000, adjustment of the VSP 3000 is not possible. ”---- Torr” is displayed if adjustment is not possible in the actual pressure range.
  • Page 57 57 of 64 ➨ In ”Configuration” menu, select program ”Adjustment” at the DCP 3000. ➨ The reading is automatically adjusted to ”750 Torr” (”1000 mbar”). This value is fixed and cannot be changed. ➨ Press the selection knob to confirm.

  • Page 58: Notes On Return To The Factory

    page 58 of 64 Notes on return to the factory Repair - return - DAkkS calibration Safety and health of our staff, laws and regulations re- NOTICE garding the handling of dangerous goods, occupational health and safety regulations and regulations regard- ing safe disposal of waste require that for all pumps and other products, the “Health and safety clearance form”, pg.
  • Page 59 page 59 of 64 We submit repair quotations only on request and always at the customer’s expense. If an order is placed, the costs incurred for problem diagnosis are offset from the costs for repair or from the purchase price, if the customer pre- fers to buy a new product instead of repairing the defec- tive one.

  • Page 60: Warranty

    - You may authorize us to dispose of the equipment at your expense. Warranty VACUUBRAND shall be liable for insuring that this prod- uct, including any agreed installation, has been free of de- fects at the time of the transfer of risk.

  • Page 61: Health And Safety Clearance Form

    By our signature below, we acknowledge that we accept liability for any damage caused by providing in- complete or incorrect information and that we shall indemnify VACUUBRAND from any claims as regards damages from third parties. We are aware that as expressed in § 823 BGB (Public Law Code of Ger- many) we are directly liable for injuries or damages suffered by third parties, particularly VACUUBRAND employees occupied with handling/repairing the product.

  • Page 62: Ec Declaration Of Conformity Of The Machinery

    2004/108/CE. Vakuum-Messgerät / Vacuum gauge / vacuomètre Typ / Type / Type: DCP 3000 / DCP 3000 + VSK 3000 / DCP 3000 + VSP 3000 / DCP 3000 + MPT 100 Artikelnummer / Order number / Numéro d’article: 683171 / 683170 / 683190 / 683175 Seriennummer / Serial number / Numéro de série: Siehe Typenschild / See rating plate / Voir...
  • Page 63 page 63 of 64 This certificate is only valid for pumps with the respective mark (Li- censed Test mark) on the pump rating plate.
  • Page 64 Alfred-Zippe-Str. 4 · 97877 Wertheim / Germany T +49 9342 808-0 · F +49 9342 808-5555 info@vacuubrand.com · www.vacuubrand.com VACUUBRAND GMBH + CO KG - Technology for Vacuum Systems - © 2013 VACUUBRAND GMBH + CO KG Printed in Germany Manual-no.: 999162 / 09/03/2013...
