Reassembly
The above procedures may be reversed to reassemble the spreader.
Ensure that the friction washer is in place when reassembling the shutter lever assembly to the
frame.
When the delivery chute is installed it must be fixed in the same position as the original.
When the spinner has been installed the clearance between the spinner and the delivery chute
must be set to a maximum of 2.5mm.
Installing a New Agitator Flail
The flail assembly comes complete with retaining clips. Insert the new flail though the hole in the
agitator shaft.
Thread on the retaining clip so that the flail is held securely.
Using a pair of pliers, crush the clip onto the flail.
Ensure that the new flail cannot contact the wall of the hopper. Trim to length if required.
Spinner does not turn when the switch is turned on
Wiring not connected
Fuse has blown
Product has jammed agitator
Delivery chute touching spinner
Product jamming spinner
Fuse blows each time the spreader is operated
Spinner jammed
Product compacted around agitator
Application Rate too high
Wiring is damaged
Excessive load on motor
To avoid serious damage to the motor and wiring, never replace the fuse with one rated higher
Spinner is running, the shutter is open, but there is no product being spread
No product in hopper
Product is bridging across orifice
Choke is shut or adjusted too high
Shutter lever won't stay in position
Shutter friction incorrect
Product spread is uneven
The delivery chute is too far to
one side
Product build up in delivery chute
TROUBLE SHOOTING
- Check connections
- Check fuse
- Empty hopper and clear
- Adjust clearance gap
- Check shutter is closed and clear product
- Check the chute clearance gap to 2.5mm
- Check spinner/chute clearance gap, set to 2.5mm
- Remove compacted product or spin the
spinner by hand before applying power
- Increase the choke setting
- Check and repair as required
- Check agitator configuration
- Check product is not clogged in base of hopper
WARNING
than 20 Amps.
-Turn off and fill hopper
- Empty hopper and fill with fresh product
- Correctly calibrate choke
- Check that the friction washer is correctly
located between the lower lever arm and the
lower bracket on the frame.
- Adjust the chute to achieve even spread
- Clean product off spreader
14
