- Page 1 USer’S GUide SRX812P SRX815P SRX835P SRX818SP SRX828SP...
-
Page 3: Table Of Contents
CONTENTS Safety Instructions ............................ Declaration Of Conformity ......................... Quick Setup Guide ............................. SRX812P, SRX815P, SRX835P Back Panel ....................SRX828SP, SRX818SP Back Panel ......................Overview - SRX800 Family ........................SRX812P, SRX815P - Block Diagram ....................... SRX835P - Block Diagram ........................SRX818SP - Block Diagram ........................ -
Page 4: Safety Instructions
SafETy INSTruCTIONS Before You Begin - Important Safety Information Before using your SRX800 speaker system please review the following for important ® information on safety and protection of your investment in quality loudspeakers. 1. Read these instructions. 2. Keep these instructions. 3. -
Page 5: Declaration Of Conformity
DEClaraTION Of CONfOrmITy Safety And EMC Compliance Specifications Report No. Description EN 55103-1:2009 +A1:2012 EMC Compatibility – Product Family Standard for Audio, Video, Audio-Visual and Entertainment Lighting Control Apparatus for Professional Use, Part 1: Emissions EN 55103-1:2009 +A1:2012 Magnetic Field Emissions – Annex A @ 10cm and 20cm EN 61000-3-2:2006 +A1:2008 +A2:2009 Limits for Harmonic Current Emissions (equipment input current less than or equal to 16A EN 61000-3-3:2013 Limitation of Voltage Fluctuations and Flicker in Low-Voltage Supply systems Rated Current less than... -
Page 6: Quick Setup Guide
QuICk SETup GuIDE Congratulations on your purchase of JBL Professional SRX800 Series loudspeakers! We know you are anxious to get up and running as fast as possible, which is why you are reading this section. The following will help you get set up as soon as possible. -
Page 7: Power Button
Ethercon Connector CH2 Input CH2 Direct Out LINK Link LED DATA SERIAL NO. JBL PROFESSIONAL NORTHRIDGE, CA USA A HARMAN INTERNATIONAL COMPANY DESIGNED AND ENGINEERED IN THE USA Data LED MADE IN MEXICO Locking IEC Inlet Power it on way before plugging in your audio source. Turn CH1 and/or CH2 Encoders to the left until the level reads “- 100”... -
Page 8: Srx812P, Srx815P, Srx835P Back Panel
SrX812p, SrX815p, SrX835p BaCk paNEl LCD Screen Power LED Power Button Master Encoder MAIN MENU PRESET MAIN CH1 Direct Out AUTO DIM AUTO SLEEP POWER METERS MASTER LEVEL Back Button CH1 Input BACK CH1 Encoder MIX OUT Mix Out CH2 Encoder... - Page 9 SrX812p, SrX815p, SrX835p BaCk paNEl LCD Screen Master Encoder Allows users to access presets and basic controls for the system without a Controls the master volume of the unit. By turning the knob counter-clockwise network connection. Controlled with the Master Encoder and the Back Button.
-
Page 10: Srx828Sp, Srx818Sp Back Panel
CH1 Input BACK NETWORK Ethercon Connector CH2 Input CH2 Direct Out LINK Link LED DATA SERIAL NO. JBL PROFESSIONAL NORTHRIDGE, CA USA A HARMAN INTERNATIONAL COMPANY DESIGNED AND ENGINEERED IN THE USA Data LED MADE IN MEXICO Locking IEC Inlet... - Page 11 SrX828Sp, SrX818Sp BaCk paNEl LCD Screen Master Encoder Allows users to access presets and basic controls for the system without a Controls the master volume of the unit. By turning the knob counter-clockwise network connection. Controlled with the Master Encoder and the Back Button. you will be lowering the overall volume of the speaker.
-
Page 12: Overview - Srx800 Family
SRX800 boasts an array of premium features that make it the very best system in its class. Drawing on JBL’s long history of groundbreaking technology and innovative loudspeaker design, the SRX800 Series meets the needs of the most demanding applications where high performance, comprehensive control and legendary JBL sound are required. -
Page 13: Srx812P, Srx815P - Block Diagram
SrX812p, SrX815p - BlOCk DIaGram... -
Page 14: Srx835P - Block Diagram
SrX835p - BlOCk DIaGram... -
Page 15: Srx818Sp - Block Diagram
SrX818Sp - BlOCk DIaGram... -
Page 16: Srx828Sp - Block Diagram
SrX828Sp - BlOCk DIaGram... -
Page 17: Srx812P Specifications
(L x W x H): 16.87” x 16.31” x 25.11” (429mm x 415mm x 638mm) Weight: 58.0 lbs (26.4kg) Shipping Weight: 67 lbs (30.5kg) *For exact specifications including precise placement of suspension points and frequency response curves for JBL presets, find spec sheets at http://www.jblpro.com/www/products/portable-market/srx800-series 428 mm 16.87 in 414 mm 16.31 in... -
Page 18: Srx815P Specifications
63.0 lbs (28.6kg) 638 mm Shipping Weight: 73.0 lbs (33.2kg) 25.11 in *For exact specifications including precise placement of suspension points and frequency response curves for JBL presets, find spec sheets at http://www.jblpro.com/www/products/portable-market/srx800-series SRX812P 479 mm 18.82 in 458 mm 18.03 in... -
Page 19: Srx835P Specifications
691 mm Weight: 85.0 lbs (38.6kg) 27.20 in Shipping Weight: 97.0 lbs (44.0kg) *For exact specifications including precise placement of suspension points and frequency response curves for JBL presets, find spec sheets at http://www.jblpro.com/www/products/portable-market/srx800-series SRX815P 476 mm 18.74 in 544 mm 21.40 in... -
Page 20: Srx818Sp Specifications
87.0 lbs (39.5kg) SRX815P Shipping Weight: 103 lbs (46.8kg) 476 mm 18.74 in *For exact specifications including precise placement of suspension points and frequency response curves for JBL presets, find spec sheets at 544 mm http://www.jblpro.com/www/products/portable-market/srx800-series 21.40 in 984 mm 38.74 in... -
Page 21: Srx828Sp Specifications
984 mm Weight: 145.0 lbs (65.9kg) 38.74 in Shipping Weight: 165.0 (75.0kg) *For exact specifications including precise placement of suspension points and frequency response curves for JBL presets, find spec sheets at http://www.jblpro.com/www/products/portable-market/srx800-series SRX835P 684 mm 683 mm 26.92 in 26.89 in... -
Page 22: Purposeful Product Design
purpOSEful prODuCT DESIGN Portability made easy The SRX800 series was designed as a versatile all-in-one solution for a variety of applications including touring and permanent installations. Special attention was given to the needs of consumers who require a high level of ruggedness, reliability, and portability. -
Page 23: Component Elements
Harman Professional in one easy to use, high performing platform. 2432H HF Driver High frequencies are handled by the JBL 2432H 3” voice-coil Compression Driver - the only 3” voice coil in this class. In addition to the weight reduction... - Page 24 400mHz Sharc DSP includes 20 PEQs, up to 2 seconds of delay, signal generators, input mixing, amplifier monitoring, and 50 User Presets. In addition, the system features 96kHZ FIR filters, LevelMax™ Limiting, and is compatible with V5 JBL Tunings, providing compatibility with our flagship Vertec and VTX touring systems. Crown DriveCore Technology Amplification Each model is powered by Crown Proprietary Front-End DriveCore technology featuring a massive 2000W Power Rating, the highest power rating in this...
-
Page 25: Back Panel Lcd
BaCk paNEl lCD INTRO Introduction JBL SRX815P INTRO The LCD Screen on the back panel of the speaker allows basic control of the system, as well as INTRO JBL SRX815P access to presets and network settings. JBL SRX815P INTRO JBL SRX815P Plug in the system and power it on. - Page 26 METERS AUTO SLEEP MAIN MENU AUTO DIM input MEters METERS PRESET MAIN AUTO SLEEP INPUT METERS AUTO DIM input MEters METERS BaCk paNEl lCD AUTO SLEEP INPUT METERS input MEters METERS INPUT METERS input MEters INPUT METERS input MEters Meters INPUT METERS NETWORK MENU 1 - IP input MEters...
-
Page 27: Srx Presets
These are the tunings to use with the SRX818SP and SRX828SP when they are used with full range systems other This is an ideal preset for speech intelligibility on the SRX812P, than the SRX812P, SRX815P, and SRX835P. Depending on the... - Page 28 SrX prESETS Preset Crossovers Presets are included to use SRX with a variety of different full range speakers and subwoofers. This chart details which presets to use in which systems to achieve optimal performance. Generic Top Box Generic Top Box Generic Top Box Generic Top Box SRX 812/815...
-
Page 29: Premium Dsp Technology
The onboard suite of user controllable DSP featured in SRX800 allows users to set up and fine tune their systems with an extremely high degree of ease and precision. In addition to the JBL engineered application presets, users can define and recall their own presets for use in a variety of settings and applications. -
Page 30: Networking
NETwOrkING SRX800 Speakers feature an Ethernet connector so that they can be controlled via Audio Architect (version 1.60 or later) or SRX Connect. The latest versions of both of these programs can be found at http://www.jblpro.com/www/products/portable-market/ srx800-series. When a connection is established, the LINK LED on the back panel of the speaker will illuminate. The DATA LED will also light to indicate that the speaker is sending and receiving information via the network. - Page 31 NETwOrkING SRX800 Speakers can be used in Audio Architect version 1.60 and later. Audio Architect can be used to control all DSP parameters of SRX800. Some functions, such as building and saving DSP presets in the speakers themselves, are only available through Audio Architect.
-
Page 32: Smart Device App
SmarT DEvICE app Introduction For ease of use, SRX800 can be controlled via a proprietary app, SRX Connect, which is available for Android and iOS devices. It may be found at http://www.jblpro.com/www/products/portable-market/srx800-series. Once the speakers are online and connected to the network, connect your device to that same network and the app will find the speakers. -
Page 33: Loudspeaker Placement And Suspension
Stand speakers upright for PA - Lay speakers on their side for stage monitoring. Use the full range speakers in upright stance for even coverage over a wide area. SRX815P and SRX812P speakers are also designed with a slanted position for stage monitoring applications. Rest the speaker on the side with rubber feet for use as a stage monitor. Two SRX835Ps can be splayed side by side for wide coverage for large audiences. -
Page 34: Troubleshooting
TrOuBlESHOOTING Symptom Likely Cause What to do Speaker not connected Verify that speaker is connected and that the circuit is on No sound to active AC power Power not switched on Switch on power and verify that power LED is on No sound, speaker is connected Speaker power cable is faulty •... -
Page 35: Warranty Information
Who Pays For What? JBL will pay all labor and material expenses for all repairs covered by this warranty. Please be sure to save the original shipping cartons because a charge will be made if replacement cartons are requested. Payment of shipping charges is discussed in the next section of this warranty. -
Page 36: Contact Information
Pacific Coast Time in the U.S.A. (800) 8JBLPRO (800.852.5776) www.jblproservice.com On The World Wide Web: www.jblpro.com Professional Contacts, Outside the USA: Contact the JBL Professional Distributor in your area. A complete list of JBL Professional international distributors is provided at our U.S.A. website: www.jblpro.com... - Page 38 Part Number: 5032132 03/15 8500 Balboa Boulevard Northridge, CA 91329 USA www.jblpro.com...
