Instruction manual
For the
Olympus TL-Lite
Intervalometer
If you need help contact me via my eBay ID "SteveMRI". Booklet Version 1.2w ©June2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TL-Lite and is the answer not in the manual?

Questions and answers

Summary of Contents for Olympus TL-Lite

  • Page 1 Instruction manual For the Olympus TL-Lite Intervalometer If you need help contact me via my eBay ID “SteveMRI”. Booklet Version 1.2w ©June2012...
  • Page 2 The TL-Lite is a Intervalometer or time lapse timer for Olympus range of IR enabled cameras. The TL-Lite measures (65x35x24mm) weighs 30 grams and is powered by one 3 volt CR2032 battery. Battery life over 300 hour’s continuous use with the unit set at one shutter trigger every 4 seconds.
  • Page 3 Three preset ranges and five memories The TL-Lite is pre programmed with 15 delay values ranging from 1 second to 8 minutes organised into 3 preset ranges. Plus two user programmable ranges. Range one 1 to 960 seconds with a resolution of 0.125 of a second.
  • Page 4 Selecting a preset Press and hold the centre and right buttons then press and release the left button. The led will now flash 3 times with a rapid pulse. Releasing the centre and right buttons during the first flash will select preset 1. Releasing the centre and right buttons during the second flash will select preset 2.
  • Page 5 Example 1 (shutter trigger every second) Press and hold the centre and right buttons. Press and release the left button then release the centre and right buttons during the first led rapid flash. This will load preset 1 delay times into the memories. Memory 1 is selected by default.
  • Page 6 Example 4 (shutter trigger every 8 minutes) Press and hold the centre and right buttons. Press and release the left button then release the centre and right buttons during the third led rapid flash. This will load preset 3 delay times into the memories. Press and hold the centre button then press and release the left button.
  • Page 7 Remove both screws from the back of the remote then remove the back cover. Remove the old battery from the holder fit a new CR2032 battery then refit cover and screws. Camera compatibility The Olympus TL-Lite is compatible with cameras that use the RM-1 Olympus camera remote. Olympus compatible cameras...
