Hardware Replacement Guide
Lenovo 3000 J Series
Types 8453, 8454, 8455, 8458, 8459, 8460

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Lenovo 3000

  • Page 1 Hardware Replacement Guide Lenovo 3000 J Series Types 8453, 8454, 8455, 8458, 8459, 8460...
  • Page 3 Lenovo 3000 J Series...
  • Page 4 RESTRICTED RIGHTS. Use, duplication or disclosure by the Government is subject to the GSA ADP Schedule contract with Lenovo Group Limited, if any, or the standard terms of this commercial license, or if the agency is unable to accept this Program under these terms, then we provide this Program under the provisions set forth in Commercial Computer Software–Restricted Rights at FAR 52.227-19, when applicable, or under Rights in...
  • Page 5: Table Of Contents

    Locating the connectors on the rear of your computer 2 Locating components Identifying parts on the system board . © Lenovo 2005. Portions © IBM Corp. 2005. Chapter 2. Replacing hardware ..7 Removing the cover .
  • Page 6 Hardware Replacement Guide...
  • Page 7: Overview

    Troubleshooting information v Parts information v Downloads and drivers v Links to other useful sources of information v Support phone list To access this information, point your browser to http://www.lenovo.com/support © Lenovo 2005. Portions © IBM Corp. 2005. ™...
  • Page 8: Tools Required

    Tools required To replace some parts in your computer, you might need a flat-blade or Phillips screwdriver. Handling static-sensitive devices Static electricity, although harmless to you, can seriously damage computer components and parts. When replacing a part, do not open the static-protective package containing the new part until the defective part has been removed from the computer and you are ready to install the new part.
  • Page 9: Chapter 1. Locations

    7. Locating the connectors on the front of your computer The following illustration shows the location of connectors on the front of the computer. USB connector Headphone connector © Lenovo 2005. Portions © IBM Corp. 2005. Microphone connector USB connector...
  • Page 10: Locating The Connectors On The Rear Of Your Computer

    Locating the connectors on the rear of your computer The following illustration shows the location of connectors on the rear of the computer. Standard mouse connector Parallel connector Ethernet connector Audio line in connector Power cord connector Voltage selection switch PCI adapter connectors AGP adapter connector Hardware Replacement Guide...
  • Page 11: Locating Components

    Locating components The following illustration will help you locate the various components in your computer. Optical drive Diskette drive bay Memory modules Power supply PCI adapter connector AGP adapter connector Chapter 1. Locations...
  • Page 12: Identifying Parts On The System Board

    Identifying parts on the system board The system board (sometimes called the planar or motherboard) is the main circuit board in your computer. It provides basic computer functions and supports a variety of devices. The following illustration shows the locations of parts on the system board for some computer models.
  • Page 13 The following illustration shows the locations of parts on the system board for some computer models. Microprocessor and heat sink Fan connector Memory connector 1 Memory connector 2 Power connector Diskette drive connector PATA secondary IDE connector PATA primary IDE connector Battery SATA IDE connectors Clear CMOS/Recovery jumper...
  • Page 14 Hardware Replacement Guide...
  • Page 15: Lenovo 2005. Portions © Ibm Corp

    Quick Reference that was included with your computer or in the Hardware Maintenance Manual (HMM) for the computer. To obtain copies of the Quick Reference or HMM, go to http://www.lenovo.com/support. Note: Use only the parts provided by Lenovo. Removing the cover Important Turn off your computer and wait 3 to 5 minutes to let the computer cool before removing the computer cover.
  • Page 16: Replacing A Memory Module

    Quick Reference that was included with your computer or in the Hardware Maintenance Manual (HMM) for the computer. To obtain copies of the Quick Reference or HMM, go to http://www.lenovo.com/support. This section provides instructions on how to replace a memory module.
  • Page 17 3. Remove the two screws at the front of the chassis securing the drive bay assembly. 4. Slide the drive bay assembly forward until the drive bay assembly is aligned with the two slots on the sides of the chassis and remove the drive cables from the system board.
  • Page 18: Replacing A Pci Adapter

    Quick Reference that was included with your computer or in the Hardware Maintenance Manual (HMM) for the computer. To obtain copies of the Quick Reference or HMM, go to http://www.lenovo.com/support. This section provides instructions on how to replace a PCI adapter.
  • Page 19: Replacing A Keyboard

    Quick Reference that was included with your computer or in the Hardware Maintenance Manual (HMM) for the computer. To obtain copies of the Quick Reference or HMM, go to http://www.lenovo.com/support. This section provides instructions on how to replace a keyboard.
  • Page 20: Replacing A Mouse

    Quick Reference that was included with your computer or in the Hardware Maintenance Manual (HMM) for the computer. To obtain copies of the Quick Reference or HMM, go to http://www.lenovo.com/support. This section provides instructions on how to replace a mouse.
  • Page 21 7. To update the configuration, see “Starting the Setup Utility” in the Quick Reference that was included with your computer. Note: In most areas of the world, Lenovo requires the return of the defective CRU. Information about this will come with the CRU or will come a few days after the CRU arrives.
  • Page 22 Hardware Replacement Guide...
  • Page 23: Appendix. Notices

    Web sites. The materials at those Web sites are not part of the materials for this Lenovo product, and use of those Web sites is at your own risk.
  • Page 24: Television Output Notice

    Macrovision Corporation. Reverse engineering or disassembly is prohibited. Trademarks Lenovo is a trademark of Lenovo in the United States, other countries, or both. IBM is a trademark of the International Business Machines Corporation in the United States, other countries, or both.
  • Page 26 Part Number: 41T3789 Printed in USA (1P) P/N: 41T3789...
