- Page 1 Instruction Manual IT-1 Infrared Thermometer...
-
Page 2: Safety Information
IT-1 Infrared Thermometer English SECTION 1 – SAFETY INFORMATION Safety Information Understand and follow operating instructions carefully. Use the tester only as specified in these instructions otherwise, the protection provided by the tester may be impaired. To ensure safe operation and service of the tester, follow these instructions. - Page 3 IT-1 Infrared Thermometer English Symbols as marked on the tester and instruction manual Battery See instruction card Do not apply directly to or around bare HAZARDOUS LIVE conductors AC measurement Conforms to EU directives Dispose of in accordance with local regulations.
- Page 4 IT-1 Infrared Thermometer English Tester Description Torch Laser Torch Key Test Key Battery Indicator ℃ / ℉ Laser Indicator NCV Indicator Battery Cover Operating Instructions Power On / Off press Press the key until the display activates Auto Power Off : 3 minutes.
-
Page 5: Temperature Measurement
IT-1 Infrared Thermometer English Temperature Measurement When powered on, press the key, the tester will show the temperature of the measured target. Then release the key, the LCD will hold the reading for 10 seconds. p r e s s... - Page 6 IT-1 Infrared Thermometer English °C / °F Selection Press the key and the key for 2 seconds at the same time to switch the temperature tester between oC and oF Notes on making Temperature Measurements For accurate temperature measurements, allow the tester to acclimatize to the ambient temperature for 30 minutes.
- Page 7 IT-1 Infrared Thermometer English To prevent thermal effects interfering with the measurement accuracy: Do not put the fingers on the housing for long periods of time • Do not cross the “B” line: The tester cannot measure through transparent materials such as glass; remove the barrier between the tester and the target surface.
- Page 8 IT-1 Infrared Thermometer English 50mm@400mm 100mm@800mm 30mm@240mm 1.2 @ 9.6 ” ” 2 @ 16 ” ” 4 @ 32 ” ” 1. The measured area cannot be bigger than target area, or the reading will be incorrect. 2. The minimum measurement area is 3.75 cm (1.5”) diameter.
-
Page 9: High Voltage
IT-1 Infrared Thermometer English Emissivity Most organic materials and painted surfaces have an emissivity of 0.95 (pre-set in the tester). Inaccurate readings will result from measuring shiny or polished metal surfaces. To compensate, cover the surface to be measured with masking tape or matt black paint. -
Page 10: Maintenance
IT-1 Infrared Thermometer English Safety Information The Volt Sense function should only be used to test insulated wire. Testing high voltage wire should keep a distance of 20mm, or it might cause danger. insulated wire high voltage Maintenance Do not attempt to repair this tester. - Page 11 IT-1 Infrared Thermometer English Cleaning Periodically wipe the case with a dry cloth and detergent. Do not use abrasives or solvents. Do not immerse the tester in water. Periodically wipe the lens with a cotton swab and rubbing alcohol. Do not use abrasives or any other solvents.
-
Page 12: Specifications
IT-1 Infrared Thermometer English Specifications Temperature -30°C ~ 500°C (-22°F ~ 932°F) -30°C ~ 0°C (-22°F ~ 32°F) : ± 3°C (± 6°F ) 1°C ~ 10°C (34°F ~ 50°F) : ± 1.5°C (± 3°F ) Accuracy at 11°C ~ 40°C (52°F ~ 104°F) : ± 1°C (± 2°F ) 23°C ±... - Page 13 IT-1 Infrared Thermometer English Europe RS Components UK PO Box 99, Corby, Northants., NN17 9RS United Kingdom Tel: 004 (0)1536 201234 Fax: 004 (0)1536 405678 rswww.com Asia RS Components 460 Alexandra Road, #15-01A PSA Building Singapore 119963 www.rs-components.com South America Av.
