SM1200 & SM1600
Upright Vacuum
Operating Instructions and Repair Parts List
READ THIS BOOK
This book has important information for the use and safe operation of this machine. Failure to read
this book prior to operating or attempting any service or maintenance procedure to your
N.A.C.E.machine could result in injury to you or to other personnel; damage to the machine or to other
property could occur as well. You must have training in the operation of this machine before using
it. If your operator cannot read English, have this manual explained fully before attempting to operate
this machine.
Si Ud. no pueden leer el Inglés, se hagan explicar este manual completamente antes de tratar el
manejo o servicio de esta máquina.
All directions given in this book are as seen from the operator's position at the rear of the machine.
For new books write to: NACECARE SOLUTIONS, 1205 Britannia Road East, Mississauga,
Ontario, Canada L4W iC7
Form No. 70676N
3/04
NACECARE SOLUTIONS
Printed in the U.S.A.
Advertisement
Table of Contents
Related Manuals for Nacecare SM1200
Summary of Contents for Nacecare SM1200
- Page 1 All directions given in this book are as seen from the operator’s position at the rear of the machine. For new books write to: NACECARE SOLUTIONS, 1205 Britannia Road East, Mississauga, Ontario, Canada L4W iC7 Form No.
-
Page 2: Table Of Contents
Wiring Diagram ....................... 13 Base Assembly Drawing ..................14 Base Assembly Part List ..................15 Handle and Filter Bag Assembly Drawing ..............16 Handle and Filter Bag Assembly Parts List ............17 Page N.A.C.E. Operator's Manual - SM1200 & SM1600... -
Page 3: Operator Safety Instructions
14. This vacuum cleaner creates suction and contains a revolving brush. Keep hair, loose clothing, fingers and all parts of body away from openings and moving parts. 15. Do not pick up anything that is burning or smoking, such as cigarettes, matches or hot ashes. Page N.A.C.E. Operator's Manual - SM1200 & SM1600... -
Page 4: Save These Instructions
17. Do not use to pick up flammable or combustible liquids such as gasoline, or use in areas where they may be present. SAVE THESE INSTRUCTIONS Page N.A.C.E. Operator's Manual - SM1200 & SM1600... -
Page 5: Grounding Instructions
WARNING: If you use an extension cord, use an extension cord with minimum wire size 16 AWG. Do not use an extension cord longer than 50 feet. Do not join two extension cords. Page N.A.C.E. Operator's Manual - SM1200 & SM1600... -
Page 6: Consignes De Sécurité De L'utilisateur
15. Cet aspirateur crée de la succion et contient une rouleau-brosse tournant. Tenez les parties mobiles et les ouvertures loin des cheveux, du linge, des doigts et de toute partie du corps. Page N.A.C.E. Operator's Manual - SM1200 & SM1600... - Page 7 17. Les poulies de la courroie peuvent devenir chaudes pendant l'utilisation normale. Pour prévenir des brûlures, évitez de toucher la poulie lors de l'entretien de la courroie. CONSERVEZ CES INSTRUCTIONS Page N.A.C.E. Operator's Manual - SM1200 & SM1600...
-
Page 8: Instructions Visant La Mise A La Terra
AVERTISSEMENT: Si vous utilisez une rallonge, celle-ci doit avoir un calibre de fil minimum de 16 AWG. Ne pas utiliser de rallonge qui dépasse 50 pieds (15 mètres) de long. Ne pas raccorder deux rallonges ensemble. Page N.A.C.E. Operator's Manual - SM1200 & SM1600... -
Page 9: How To Prepare The Machine For Operation
To stop vacuum, raise handle to upright position. For handle positions, see figure 3. Figure 2 Store Operate Clean Under Figure 3 Page N.A.C.E. Operator's Manual - SM1200 & SM1600... -
Page 10: Maintenance
"What to Do about the Wear of the Brush." 8. Put a new belt around the pulley on the brush. Align the brush roll pulley with the belt guide. See figure 5. Page -10- N.A.C.E. Operator's Manual - SM1200 & SM1600... - Page 11 Press the center of the plate against the base of the machine. Turn the cam latches to fasten the plate to the base. See figure 8. Figure 7 Cam Latch Figure 8 Page -11- N.A.C.E. Operator's Manual - SM1200 & SM1600...
-
Page 12: Steel Core Brush
Do not oil the motor at any time. Electrical Maintenance WARNING: Electric repairs and maintenance must be done by authorized personnel only. Return the machine to a N.A.C.E.Authorized repair location. Page -12- N.A.C.E. Operator's Manual - SM1200 & SM1600... -
Page 13: Trouble Shooting Guide
4) Replace switch. Brush roll vibrates. 1) Ball bearing worn out. 1) Replace brush roll. 2) Ball bearing holder damaged. 2) Replace ball bearing holder. N.A.C.E. SM1200 & SM1600 Wiring Diagram 3/04 Page -13- N.A.C.E. Operator's Manual - SM1200 & SM1600... -
Page 14: Base Assembly Drawing 3/04
N.A.C.E. SM1200 & SM1600 Base Assembly Drawing 3/04 Page -14- N.A.C.E. Operator's Manual - SM1200 & SM1600... -
Page 15: Base Assembly Part List
Screw, M4 x .7 x 18 PnSt 30153B Front Wheel 51365A Carbon Brush 51352B Plate, Front Axle Support NI * 51366A Impeller 51261A Clamp, Front Axle NI * 51367A Motor Pulley *NI = Not illustrated Page -15- N.A.C.E. Operator's Manual - SM1200 & SM1600... -
Page 16: Handle And Filter Bag Assembly Drawing 3/04
N.A.C.E. SM1200 & SM1600 Handle and Filter Bag Assembly Drawing 3/04 Page -16- N.A.C.E. Operator's Manual - SM1200 & SM1600... -
Page 17: Handle And Filter Bag Assembly Parts List 3/04
Seat, Handle Socket 51358A Nut, Handle Tube (M4) 30154A Clamp, Handle Socket Cam 52363N Cloth Filter Bag Assembly 51263A Spring Bag 51262A Clip, Bag Coupling 30148A Bag Coupling 30149A Gasket, Bag Coupling Page -17- N.A.C.E. Operator's Manual - SM1200 & SM1600... - Page 18 NACECARE SOLUTIONS reserves the right to make changes or improvements to its machine without notice. 1205 Britannia Road East Mississauga, Ontario, Canada L4W IC7 PH. 1-800-387-3210 FAX 1-800-709-2896 Page -18- N.A.C.E. Operator's Manual - SM1200 & SM1600...
