DM1400 & DM1800
Upright Vacuum
Operating Instructions and Repair Parts List
READ THIS BOOK
This book has important information for the use and safe operation of this machine. Failure to read
this book prior to operating or attempting any service or maintenance procedure to your N.A.C.E.
machine could result in injury to you or to other personnel; damage to the machine or to other property
could occur as well. You must have training in the operation of this machine before using it. If your
operator cannot read English, have this manual explained fully before attempting to operate this
machine.
Si Ud. no pueden leer el Inglés, se hagan explicar este manual completamente antes de tratar el
manejo o servicio de esta máquina.
All directions given in this book are as seen from the operator's position at the rear of the machine.
For new books write to: NACECARE SOLUTIONS, 1205 Britannia Road East, Mississauga,Ontario,
Canada L4W iC7
Form No. 70720N
3/04
NACECARE SOLUTIONS
Printed in the U.S.A.
Advertisement
Table of Contents
Related Manuals for Nacecare DM1400
Summary of Contents for Nacecare DM1400
- Page 1 All directions given in this book are as seen from the operator’s position at the rear of the machine. For new books write to: NACECARE SOLUTIONS, 1205 Britannia Road East, Mississauga,Ontario, Canada L4W iC7 Form No.
-
Page 2: Table Of Contents
Parts List #1 Upper Canister Assembly .................... 21 Drawing #2 Brush Housing Assembly ....................22 Parts List #2 Brush Housing Assembly .................... 23 Parts List #3 Hose Wand and Handle Assembly ................24 Page N.A.C.E. Operator's Manual - DM1400 & DM1800... -
Page 3: Operator Safety Instructions
14. This vacuum cleaner creates suction and contains a revolving brush. Keep hair, loose clothing, fingers and all parts of body away from openings and moving parts. 15. Do not pick up anything that is burning or smoking, such as cigarettes, matches or hot ashes. Page N.A.C.E. Operator's Manual - DM1400 & DM1800... -
Page 4: Save These Instructions
17. Do not use to pick up flammable or combustible liquids such as gasoline, or use in areas where they may be present. 18. Unplug the machine before servicing the belt or brush. The brush may start suddenly and cause injury. SAVE THESE INSTRUCTIONS Page N.A.C.E. Operator's Manual - DM1400 & DM1800... - Page 5 15. Cet aspirateur crée de la succion et contient une rouleau-brosse tournant. Tenez les parties mobiles et les ouvertures loin des cheveux, du linge, des doigts et de toute partie du corps. Page N.A.C.E. Operator's Manual - DM1400 & DM1800...
- Page 6 évitez de toucher la poulie lors de l'entretien de la courroie. 18. Débrancher la machine avant de faire l'entretien de la courroie ou de brosse. La brosse peut démarrer soudainement et causer des blessures. CONSERVEZ CES INSTRUCTIONS Page N.A.C.E. Operator's Manual - DM1400 & DM1800...
-
Page 7: Introduction & Machine Specifications
INTRODUCTION The DM1400 & DM1800 are upright vacuums for cleaning carpet. These machines are used to remove dry material from carpet. These machines are intended for commercial use. MACHINE SPECIFICATIONS Model DM1400 DM1800 Power Supply 120V-60 Cycle 120V-60 Cycle Vacuum Motor... -
Page 8: Grounding Instructions
WARNING: If you use an extension cord, use an extension cord with minimum wire size 16 AWG. Do not use an extension cord longer than 50 feet. Do not join two extension cords. Page N.A.C.E. Operator's Manual - DM1400 & DM1800... - Page 9 AVERTISSEMENT: Si vous utilisez une rallonge, celle-ci doit avoir un calibre de fil minimum de 16 AWG. Ne pas utiliser de rallonge qui dépasse 50 pieds (15 mètres) de long. Ne pas raccorder deux rallonges ensemble. Page N.A.C.E. Operator's Manual - DM1400 & DM1800...
-
Page 10: How To Assemble The Machine
5, item A). This insures the handle is Figure 3 properly seated. c. Push handle latch into lock position (see figure 5, item B). Mark on handle tube. Figure 4 Figure 5 Page -10- N.A.C.E. Operator's Manual - DM1400 & DM1800... - Page 11 To attach hose properly, depress lock on canister (see figure 7, item B). 8. Snap the crevice (B) and upholstery (C) tools into the tool retainer on rear of canister housing (see figure 6). Figure 6 Figure 7 Page -11- N.A.C.E. Operator's Manual - DM1400 & DM1800...
-
Page 12: The Controls
The wand has a suction control sleeve (see figure 10). For normal vacuuming keep suction control sleeve closed. To reduce suction, when cleaning drapes or furniture, open suction control sleeve. Figure 9 Figure 11 Figure 10 Page -12- N.A.C.E. Operator's Manual - DM1400 & DM1800... - Page 13 The cord storage hooks are on the back of the canister Figure 12 housing. The lower cord hook is also a carrying handle. The lower cord hook rotates to provide a quick cord release and to ease cord removal. Figure 13 Page -13- N.A.C.E. Operator's Manual - DM1400 & DM1800...
-
Page 14: How To Operate The Machine
NOTE: The machine comes with a filter bag installed in the canister housing. Use the DM1400 & DM1800 as a carpet cleaner or as an upholstery cleaner. To operate the machine as a carpet cleaner, follow this procedure: 1. -
Page 15: Maintenance
Figure 18 e. Make sure the cardboard is pushed all the way on the bag adapter (figure 19) or the door will not latch. f. Close the canister housing. Figure 19 Page -15- N.A.C.E. Operator's Manual - DM1400 & DM1800... -
Page 16: How To Clean The Filter Cartridge
5. Install the new brush assembly. 6. Install the nozzle plate. 7. Put the machine on its wheels. WARNING: To reduce the risk of injury from moving parts, unplug before servicing. Figure 22 Page -16- N.A.C.E. Operator's Manual - DM1400 & DM1800... -
Page 17: How To Change The Drive Belt
If the motor over heats, the thermal overload will stop the motor. If the motor stops, let the motor cool before restarting the machine. Check filters. If the motor continues to stop, consult an authorized service person. Page -17- N.A.C.E. Operator's Manual - DM1400 & DM1800... -
Page 18: Brush Performance Indicator Lights
Restart the machine. • If the brush height was too low, raise the brush height setting. • If the brush was jammed, unplug the vacuum and clear the brush. Page -18- N.A.C.E. Operator's Manual - DM1400 & DM1800... - Page 19 DM1400 & DM1800 Upright Vacuum Repair Parts List Page -19- N.A.C.E. Operator's Manual - DM1400 & DM1800...
-
Page 20: Drawing #1 Upper Canister Assembly 3/04
N.A.C.E. DM1400 & DM1800 Drawing #1 Upper Canister Assembly 3/04 Page -20- N.A.C.E. Operator's Manual - DM1400 & DM1800... -
Page 21: Parts List #1 Upper Canister Assembly 3/04
Upholstery Tool w/Brush 53262N Wand Assembly 53253A Handle, Cord Hook 53254N Swivel, Cord Hook 53255A Retainer, Hose 53290N Clamp, Asm. Handle (incl. 53210A & 53273A) 53253A Bag Full Indicator 53225N Hose Assembly Page -21- N.A.C.E. Operator's Manual - DM1400 & DM1800... -
Page 22: Drawing #2 Brush Housing Assembly 3/04
N.A.C.E. DM1400 & DM1800 Drawing #2 Brush Housing Assembly 3/04 Page -22- N.A.C.E. Operator's Manual - DM1400 & DM1800... -
Page 23: Parts List #2 Brush Housing Assembly 3/04
53249A Pedal, Foot Latch 53326A Circuit Board 120V 53275A Pin, Support Pivot 53333A Spring (include with #36) 53241A Support Asm., Canister Pivot (includes #13, 34, 35) 53293A Rear Axle (includes #7) Page -23- N.A.C.E. Operator's Manual - DM1400 & DM1800... -
Page 24: Parts List #3 Hose Wand And Handle Assembly
N.A.C.E. DM1400 & DM1800 Electrical Schematic 3/04 Page -24- N.A.C.E. Operator's Manual - DM1400 & DM1800... - Page 25 NOTES Page -25- N.A.C.E. Operator's Manual - DM1400 & DM1800...
- Page 26 NACECARE SOLUTIONS U.S. LIMITED WARRANTY This N.A.C.E. Industrial/Commercial Product is warranted to be free from defects in materials and workmanship under normal use and service for a period of one year from the date of purchase, when operated and maintained in accordance with N.A.C.E.
