5.0
VENTILATION ( ( continued)
solution. Any ventilation fitted must comply with BS 5871 part 2 and BS 5440 part 2.
Spillage detected during commissioning is almost always a result of poor flue performance, which cannot be cor-
rected by any amount of ventilation.
For Republic of Ireland ventilation may be required, see IS 813, ICP3, IS 327, and any other rules in force.
6.0
UNPACKING T T HE A A PPLIANCE
Stand the carton the right way up, cut the strapping bands and remove the top end cap. Read all the instructions
before continuing to unpack or install this appliance.
Remove the box containing the hearth and fireframe, the box containing the ceramic logs, and the box contain-
ing the burner unit. Remove the cardboard packing pieces, and any bags containing other fittings or parts.
When all loose parts have been removed, the outer sleeve may be lifted off to reveal the appliance. Check that
the components supplied correlate with the checklist given in section 7.0.
Please dispose of the packaging materials at your local recycling centre.
7.0
COMPONENT C C HECKLIST
QUA A NTITY
1
1
1
1
1
8
6
1
1
1
1
1
1
4
1
1
8.0
PREPARING T T HE A A PPLIANCE
Note: E E ns s ure t t hat t t he g g as s s s upply i i s s i i s s olated b b efore c c ommenc c ing g i i ns s tallation o o f t t he a a pplianc c e.
The fireplace opening and environment must be in compliance with the specifications laid down in the
appropriate sections of these instructions. Remove the firebox and burner unit from their cartons and stand upon
a dust sheet or similar. Place the stone effect frame, ceramic logs and fixings safely to one side.
Knockout holes are provided in the rear of the firebox for use where concealed pipework is required. Where
necessary, knock out the appropriate hole with a sharp tap from a hammer, and fit the rubber grommet supplied.
A small incision can how be made in the rubber to slip snugly around the outside of the pipe and sleeving. Do
not i i ns s tall o o r u u s s e t t he a a pplianc c e w w ithout t t he s s eals s i i n p p lac c e. If a hole is inadvertently opened, reseal with an intact
grommet. Failure to fit the seal correctly will cause flue suction to act upon the area under the burner, resulting
in poor performance and intermittent cutting out of the burner.
DESCRIPTION
Firebox assembly.
Burner unit assembly.
Decorative frame, one of several finishes.
Hearth unit, one of several finishes.
Moulded ceramic fibre log support.
Individual large ceramic logs.
Individual small ceramic logs.
Bag of Pebbles (glass/pebble option only)
Bag of vermiculite
Bag of glass crystals (glass/pebble option only)
Set of manufacturers instructions and warranty card.
Cable fixing kit comprising; 2 cables, 2 tensioners, 2 clamps, 4 fixing eyes, 4 fibre rawl plugs.
Self tapping screw pack.
Lengths of self adhesive sealing strip.
Rubber grommet.
Fitting kit comprising; 1 Inlet restrictor cock, 1 allen key, 2 cable ties.
4
